DIRECTV HD DVR
User's Guide
The On-Screen Menus and the Remote Control
Arrow Buttons
®
'
To navigate the DIRECTV
HD DVR
s on-screen menus, use
'
the remote control
s arrow buttons to move the highlight bar
onto the option you want, then press SELECT.
The LEFT arrow button often takes you to a previous screen.
Select
Two Types of On-Screen Arrows
The arrows that appear beside or near
the highlight bar show possible
directions. For example, on this screen,
you could press the RIGHT arrow to
highlight Options or the DOWN arrow to
"
"
highlight
Edit Keyword WishList.
When you see page up or page
down arrows at the top or
bottom of the screen (or a list),
Page Up
press the CHAN UP/DOWN
Arrow
button to jump to more items
an entire page at a time.
Page Down
Arrow
Highlight Bar
Arrows Near
Highlight Bar
CHAN UP/DOWN
Chan
Button
