Directed Video VC2010 Owner's Installation Manual

Directed electronics video cassette recorder owner's guide installation guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
O W N E R ' S G U I D E
INSTALLATION GUIDE
Video Cassette Recorder
MODEL VC2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC2010 and is the answer not in the manual?

Questions and answers

Related Manuals for Directed Video VC2010

Summary of Contents for Directed Video VC2010

  • Page 1 O W N E R ’ S G U I D E INSTALLATION GUIDE Video Cassette Recorder MODEL VC2010...

  • Page 2: Limited One-Year Warranty

    Limited One-Year Warranty For a period of ONE YEAR from the date of purchase, Directed Electronics, Inc. ("DIRECTED") promises to the original purchaser to repair or replace, free of cost, with a comparable reconditioned model any VIDEO CASSETTE RECORDER (hereafter the "UNIT”), which...

  • Page 3: Important Safeguards

    Follow Instructions - Follow all operating and usage instructions. Cleaning - Use dry cloth only; do not use liquid or aerosol cleaners. © 2001 Directed Electronics, Inc. Attachments and Connections - Do not use attachments or make any connections other than those recommended by the manufacturer.

  • Page 4: Important Information

    Make sure you receive the warranty registration from your dealer. It is also neces- sary to keep your proof of purchase, which expressly reflects that the product was installed by an au- thorized dealer. © 2001 Directed Electronics, Inc.

  • Page 5: Table Of Contents

    Specifications ........... .15 © 2001 Directed Electronics, Inc.

  • Page 6: Features

    ACCESSORIES VCR. Remote infrared (IR) sensor (Optional part). Remote control. AA Batteries for remote. Power harness. Mounting brackets (2). Mounting hardware. 4 machine screws. 4 sheet metal screws. Sticker sheet to cover unused holes. © 2001 Directed Electronics, Inc.

  • Page 7: Front Panel

    The VCR can be mounted vertically, horizontally, or at any angle using the optional mounting brackets. The VCR cannot be mounted upside down or on its side. The VCR is sensitive to dirt and other contaminants. Do not mount the unit © 2001 Directed Electronics, Inc.

  • Page 8: Rear Panel/Tv Connection/Av Power

    Rear Panel/TV Connection/AV Power To connect the VCR and TV, use cable type (A/V RCA-type) appropriate to your TV. Connect the VCR and TV as shown: VIDEO OUT - Connects to TV video input. VIDEO IN - Connects to a second VCR for recording or video camera for recording.

  • Page 9: Remote Control

    Remote Control Always aim the remote control directly at the VCR or the remote sensor eye. Remote Control Battery Install/Replace Slide battery compartment cover out from back of remote control. Insert two AA batteries as diagrammed. Slide battery compartment cover back in.

  • Page 10: Playing A Tape

    Press REC; the REC button will light. To pause recording, press STILL/SLOW. To resume recording, press REC. To end recording, press STOP. © 2001 Directed Electronics, Inc.

  • Page 11: Videocassette Tapes

    VCR. Do not take apart any cassette you plan to use again. © 2001 Directed Electronics, Inc. To record a tape that has the Record Protect Safety Tab removed, place a piece of cellophane tape over the space from which the tab was removed.

  • Page 12: Using Special Features

    IMPORTANT! DO NOT INSERT ANY OBJECTS INTO THE CABINET SLOTS; CONTACT WITH A VOLTAGE POINT INSIDE THE VCR CAN CAUSE DANGEROUS SHOCK OR MAY SHORT OUT PARTS AND CAUSE FIRE OR ELECTRIC SHOCK. STILL AND FRAME ADVANCE While in Play mode, press STILL/SLOW to stop on a single still frame.

  • Page 13: Setting The Main Menu

    Auto Repeat function. Press the ENTER button to switch Auto Repeat ON or OFF. Press the MENU button to exit. © 2001 Directed Electronics, Inc. AUDIO OUTPUT The Audio Output function allows you to select four different types of audio output. Press the MENU button on the remote control to access the on-screen menu.

  • Page 14: Troubleshooting

    Make sure the VCR is on and connected to an operating power source; check the remote for “good” batteries. Press EJECT to see if a cassette is already in the VCR. Make sure the videocassette is window-side up, with the arrow pointing toward the VCR.

  • Page 15: Specifications

    Audio output Signal-to-noise ratio Power source Power consumption Dimensions Fuse Weight © 2001 Directed Electronics, Inc. VHS 1/2 inch (12.7mm) Rotary Double azimuth four-head helical scanning DA-4 rotary heads Linear : 1 stationary Hi-Fi : 2 rotary 1 stationary 1 full track; 1 audio track 6 hours with T-120 in SLP mode Video IN terminal (RCA)1.0 Vp-p...
  • Page 16 The recipient of more than 20 patents in the field of advanced electronic technology, Directed is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world. Call (800) 274-0200 for more information about our products and services.
