NOVAK SS4300 - INSTRUCTION ADDENDUM Instruction

•SUPER SPORT ADDENDUM•
THIS ADDENDUM CONTAINS UPDATES TO THE 'SPECIFICATIONS'
& 'GEAR SELECTION' SECTIONS OF THE SUPER SPORT MANUAL
SS5800 MOTOR SPECS
Motor Diameter
Motor Length
Motor Weight
Motor Power Rating
Motor Kv
Motor Kt
Motor Commutation
Motor Magnet Material
SS4300 MOTOR SPECS
Motor Diameter
Motor Length
Motor Weight
Motor Power Rating
Motor Kv
Motor Kt
Motor Commutation
Motor Magnet Material
GENERAL TECH NOTE:
The blue status LED will remain ON solid whenever
Program 5 or 6 is active in the Super Sport ESC.
NOVAK CUSTOMER SERVICE
M-Th: 8am-5pm (PST) • Fr: 8am-4pm
©2004 Novak Electronics, Inc. • All Rights Reserved • No part of these instructions may be reproduced without the written permission of Novak Electronics, Inc. • All Novak motors are
designed & assembled in the U.S.A.
Printed in the U.S.A. 5/2004
1.41" [35.8 mm]
2.08" [52.8 mm]
6.40 ounce [181.4 grams]
196 Watts
5800 RPM/Volt DC
0.45 Inch-Ounce/Amp
Sensor-Based Electronic
Neodymium
(1pc/multi-pole)
1.41" [35.8 mm]
2.08" [52.8 mm]
6.40 ounce [181.4 grams]
175 Watts
4300 RPM/Volt DC
0.45 Inch-Ounce/Amp
Sensor-Based Electronic
Neodymium
(1pc/multi-pole)
• (949) 833-8873 • FAX (949) 833-1631 • e-mail: cs@teamnovak.com • web: www.teamnovak.com
(closed every other Friday)
GEAR SELECTION (Important)
SS5800 Motor
With the SS5800 motor start with 2 teeth lower pinion gear
than you would use with a 27 turn "stock" brush-type motor.
SS4300 Motor
With the SS4300 motor start with 3 teeth lower pinion gear
than you would use with a 27 turn "stock" brush-type motor.
Because of the broader power band of the brushless motor, you can
go with a 1 to 3 tooth higher pinion than the above recommendations
for more top speed, but remember that going with 3 or more
teeth higher will produce excessive speed control heating. Be sure
to check the operating temperature of the ESC after making any
gearing adjustments--the Super Sport ESC is designed to operate
comfortably from160ºF-180ºF (warmer than typical brush-type ESC).
If you had a low turn modified brush-type motor in vehicle before
switching to the Super Sport system, and you do not change gearing,
you will be under-geared and the vehicle will be slow at top speed!
You will want the final drive ratio in the vehicle to be:
7.30 : 1
9.00 : 1 for Off-Road Buggies
12.30 : 1 for Off-Road Stadium Trucks
Higher final drive ratios will give longer run time at the expense of top
speed, while lower ratios will result in higher ESC temperatures--too low
may result in overheating and thermal shut-down.
VEHICLE SPUR SS5800 PINION SS4300 PINION
Losi XXX-BK2 Buggy 78
Losi XXX Buggy 78
Losi XXX-4 Buggy 94
Losi XXX-TMF2 Truck 86
Losi XXX-T Truck 86
Assoc. TC3 Sedan 72
Assoc. B4 Buggy 81
Assoc. B3 Buggy 81
Assoc. T4 Truck 87
Assoc. T3 Truck 87
Traxxas Rustler Truck 84
Traxxas Stampede Truck 84
Traxxas Bandit Buggy 78
Traxxis 4-Tec Sedan 87
Note: Above chart shows basic starting points for gearing on larger tracks
with stdandard size tires--See our website for extended gearing chart.
for Touring Cars
22-23 21-22
21-22 20-21
21-22 20-21
18-19 17-18
17-18 16-17
24-25 23-24
22-23 21-22
21-22 20-21
18-19 17-18
17-18 16-17
18-19 17-18
17-18 16-17
22-23 21-22
24-25 23-24
