Projector Monitoring Software Starter Guide
Only works with REALiS Series Mark II and Mark II D projectors and Canon LV-Series projectors with a network port.
D
DISCLAIMER
1. This is a EXAMPLE of how to use the Canon's Projector Monitoring Software.
2. You will need to change the projector's IP address to match your network settings.
3. Please make sure your computer meets the following System Requirements.
Category
OPERATING SYSTEM
CPU
MEMORY
.NET FRAMEWORK
SUPPORTED LANGUAGES:
ACROBAT READER
I
CHANGING THE IP ADDRESS ON REALiS PROJECTORS
Step 1: To find the default IP address of the REALiS
projector, PRESS the Menu button.
Step 2: PRESS the right-arrow button and scroll
over to the Information tab. Here is where
you will find the projector's default IP address.
NOTE: In order to change the projector's IP
address, your computer's IP address
must be in the same network as the
projector.
Step 3: Open up Internet Explorer and TYPE in the
projector's default IP Address.
Step 4: The REALiS web page will open up.
TYPE in the following:
User Name: root (all lower case)
Password: system (all lower case)
Step 5: CLICK on the OK button.
Essential Requirements
Microsoft Windows XP Professional SP2 or later /
Microsoft Windows Vista Ultimate
Intel Pentium 4 2.4 GHz or better
1 GB or more
Windows XP: .NET Framework 2.0 SP1 or more /
Windows Vista : .NET Framework 3.0 or more
English and Japanese
7.0 or higher
Step 3
Step 2
Step 4
Step 5

Advertisement

   Related Manuals for Canon LV-7275

   Summary of Contents for Canon LV-7275

  • Page 1

    Projector Monitoring Software Starter Guide Only works with REALiS Series Mark II and Mark II D projectors and Canon LV-Series projectors with a network port. DISCLAIMER 1. This is a EXAMPLE of how to use the Canon’s Projector Monitoring Software.

  • Page 2

    Step 6: CLICK on the Settings button. Step 6 Step 7: CLICK on the TCP/IP tab. TCP/IP Step 9 Step 8: Change the IP Address and Subnet Mask to Step 8 IP address 192.168.254.254 a NEW IP Address within your network. Subnet mask 255.255.255.0 I address...

  • Page 3

    CHANGING THE IP ADDRESS ON LV-SERIES PROJECTORS Step 1: To find the default IP address on LV-projector, Step 1 PRESS the Menu button. PRESS the right-arrow button and scroll over to the Reset tab. Step 2 Step 2: Scroll down and SELECT Network settings, then PRESS the OK button.

  • Page 4

    REGISTERING / DISCOVERING REALiS PROJECTORS First: The following is an EXAMPLE on how Step 1 to register and monitor Canon projectors using the Projector Monitoring Software. REALiS SERIES PROJECTORS Step 1: DOUBLE-CLICK on the Projector Monitoring Software icon located on your desktop (or where ever you saved it).

  • Page 5

    REGISTERING / DISCOVERING LV-SERIES PROJECTORS LV-SERIES PROJECTORS Step 1: CLICK on the Options tab, scroll down and to Discovery settings and SELECT LV-Series Step 1 Step 2: In the IP address tab, CLICK on the New Step 2 button. Step 3 Step 3: TYPE in the previously set IP address of the LV-Projector.

  • Page 6

    OPTIONAL: PROJECTOR STATUS INTERVAL Step 1: CLICK on the Options tab, scroll down and Step 1 SELECT Polling intervals. Step 2: Polling Intervals allows the user to Get projector status and Discover projector Step 2.1 status during different time intervals 1.
