Adcom GFA-555SE Brochure page 2

• High Current Amplifier
• Bridgeable
• Stable to 1-ohm output impedance
• 16 discrete output transistors
• Custom 700 watt toroidal transformer
• 60,000uF total storage capacitance
• Ultra-Stable Bias Circuitry
• Direct-Coupled Input & Output Circuitry
• No Current Limiting
• No Output Inductor
• Balanced and Single-Ended Inputs
Specifications
GFA-555se
Dimensions: 7 1/4" x 17" x 12 3/16"
Weight: 35 lbs (16kg)
Power: 120VAC/230VAC / 50-60Hz
SNR: "A" Weighted. > 110dB
Frequency Resp. @ 1watt, 8-ohms:
- 10Hz to 20kHz +0, -0.25dB
Power Bandwidth (-3dB):
- 1.7Hz to 100kHz
The classic award winning amplifier design of the original GFA-555mkII has been reborn. Externally, the chassis footprint and
front panel design are identical to the original. Internally, all circuitry has been upgraded to meet ETL/ETLc, FCC, LVD and CE/
EMC requirements using UL approved FR-4 printed circuit boards. High performance component selectons include ultra low ESR
electrolytic capacitors. The result of these improvements is lower distortion, better dynamic range, improved damping factor and
greater stability and separation of individual instruments on the sound
diam nosto con ea ad ero ecte conse dolendigna am, qui tet iriure del
GFA-555se
stage.ore del ulluptat nulput deleseq uipsusc ipisim
GFA-555se
Input Impedance:
- 100k ohms unbalanced
- 10k ohms balanced
Output Power:
- 200 watts/channel 8-ohms
- 600 watts, bridged
- 325 watts/channel 4-ohms
- 900 watts, bridged
Advanced Sound & Image, LLC
8541 East Anderson Drive, #101
Scottsdale, Arizona 85255 USA
PH: 480.607.2277
FAX: 480.348.9876
www.adcom.com
