Owner's Manual
Before using this unit, carefully read the sections entitled: "USING
THE UNIT SAFELY" (p. 6–8), "IMPORTANT NOTES" (p. 9–10), and
"An Important Notice Regarding the Software" (p. 60–63).
These sections provide important information concerning the proper
operation of the unit. Additionally, in order to feel assured that you
have gained a good grasp of every feature provided by your new unit,
Owner's Manual should be read in its entirety. The manual should be
saved and kept on hand as a convenient reference.
Copyright © 2008 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any
form without the written permission of ROLAND CORPORATION.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Edirol F-1

Summary of Contents for Edirol F-1

  • Page 1 Owner’s Manual Before using this unit, carefully read the sections entitled: “USING THE UNIT SAFELY” (p. 6–8), “IMPORTANT NOTES” (p. 9–10), and “An Important Notice Regarding the Software” (p. 60–63). These sections provide important information concerning the proper operation of the unit. Additionally, in order to feel assured that you have gained a good grasp of every feature provided by your new unit, Owner’s Manual should be read in its entirety.

  • Page 2: Confirm The Contents Of The Package

    Confirm the Contents of the Package The F-1 includes the following items. Please take a moment to confirm that all of these items have been included with the F-1. If you find that any item is missing, contact the nearest authorized EDIROL/Roland distributor in your country.

  • Page 3: Main Features

    F-1 can be shown. ● Connect directly to a USB mass storage device to copy materials Connect the F-1 to a handy USB memory device or USB hard disk to extract data from the F-1. ● Network support Since there is an onboard LAN connector, materials can be copied to a PC via a local Ethernet network, and the unit can even be controlled remotely by a PC.

  • Page 4: Table Of Contents

    Connecting the F-1 to a PC ..................29 Connecting the Removable Storage to a PC............... 30 Disconnecting the PC ....................31 The “F-1 Utility” ......................32 Copying F-1 Materials over a Network................33 Remotely Controlling the F-1 from the PC (F-1 Net Control)........34...
  • Page 5 Table of Contents Advanced Use Arranging Materials ......................35 Regarding Folders ....................... 35 Deleting Material Files ....................36 Managing the Removable Storage ................. 37 Inserting/Removing...................... 37 Deleting All Data / Initializing (Formatting) ..............38 Scanning (Internal Drive Check).................. 39 Using USB Mass Storage ....................40 Backing Up All Material Files..................

  • Page 6: Using The Unit Safely

    Also, make sure the to do so). Refer all servicing to your line voltage at the installation matches the retailer, the nearest EDIROL/Roland input voltage specified on the AC adaptor’s Service Center, or an authorized Roland body.
  • Page 7 ●Before using the unit in a foreign country, material, coins, pins); or liquids of any kind (water, soft drinks, etc.) to penetrate the consult with your retailer, the nearest unit. EDIROL/Roland Service Center, or an authorized Roland distributor, as listed on .................. the “Information” page. 012b ●Immediately turn the power off, remove the...
  • Page 8 USING THE UNIT SAFELY 101b 103b ●The unit and the AC adaptor should be ●At regular intervals, you should unplug the located so their location or position does AC adaptor and clean it by using a dry not interfere with their proper ventilation. cloth to wipe all dust and other ..................

  • Page 9: Important Notes

    Memory Backup could occur when receiving or initiating a call, or 501a ●When there is no battery power to the F-1, the while conversing. Should you experience such date/time settings can be saved for up to about problems, you should relocate such wireless thirty days.
  • Page 10 In such instances, data temporarily. We also recommend that you consult your dealer or the nearest EDIROL/ back up important performance and image data Roland Service Center. Note, however, that it may...

  • Page 11: Making A Recording

    Making a Recording Capturing by Connecting a HDV/DV Camera Connect an HDV/DV camera to the F-1 with the i.LINK cable, and capture the camera output. Preparations Install the removable storage included with the F-1. * Make sure to switch off the power before installing the removable storage. Failure to do so may result in damage to the contents of the removable storage.
  • Page 12 Making a Recording Connect the F-1 and HDV/DV camera with the i.LINK cable. i.LINK connector i.LINK connector i.LINK cable * There are two types of i.LINK cable connectors: 6-pin and 4-pin. Make sure to use the i.LINK cable that matches the device that you are using.

  • Page 13: Capturing Video And Audio

    Please connect the device after verifying the wiring configuration. The figure at left shows the AUDIO IN connector wiring. Set the switch on the side panel of the F-1. Use one of the following settings for the connected device. Switch...
  • Page 14 * If you hear acoustic feedback (a squealing sound) while using the mic, try changing the direction of the mic, moving it away from the speakers, or lowering the speaker volume. Press the [ (REC)] button on the F-1 to start capturing video and audio. Press the [ (STOP)] button to stop capture.

  • Page 15: Checking Captured Video And Audio

    If the formats do not match, then the stream cannot be played on the F-1. There are also cameras that have a mode that automatically switches the HDV/DV format. Even if this mode is set, you may not be able to play the stream on the F-1.

  • Page 16: Panel Descriptions

    CH3/4 Lamp This lights when the [CH3/4] switch on the side panel is set to “ON.” Display (p. 20) This displays the F-1’s operation status and menu screens. [DISPLAY] Button (p. 20) Switches the display between screens. (STOP)] Button (p. 12, 14, 15) Stops capture.
  • Page 17 Panel Descriptions [MENU] Button (p. 27) Shows the Menu screen on the display. The Menu screen switches between hide/show each time the [MENU] button is pressed. )] Button Current Screen Operation Home Screen Selects the previous file in the same folder. Audio Level Screen Menu Screen Selects the previous menu item.

  • Page 18: Rear Panel

    * Only the F-1’s removable storage “F1-HD120” can be inserted. Side Panel LAN Connector (p. 34) This is used to connect to a PC via a network using a LAN cable. F-1 materials can be copied to a PC connected to the network. Cooling Fan Vent The internal cooling fan regulates temperature increases inside the F-1.
  • Page 19 (continued) DISPLAY OUT Connector (p. 44) This connector outputs an RGB signal (fixed SVGA format) The data in the F-1 (folder or file) can be viewed when a VGA display is connected. AUDIO IN Connector (CH3, CH4); XLR-type (p. 13) Audio is input here.

  • Page 20: Display

    Panel Descriptions Display This shows various information and messages, such as the current status or function settings, according to the operation. The display shows the following three screens. Displayed Screen Operation Home Screen The screens change as follows each time the [DISPLAY] button is pressed. Audio Level Screen Home screen Home screen...
  • Page 21 Playback Remaining Space in Removable Storage Displays the remaining free space on the removable storage mounted on the F-1 unit. * A low memory warning message is displayed when the remaining space on the removable storage falls too low. If capture continues with low memory, the capture will stop eventually.

  • Page 22: Audio Level Screen

    Panel Descriptions Audio Level Screen Total Time During Capture Displays the elapsed time for capture. During Standby/ Displays the length of the material currently selected. Playback Audio Level Meter Displays the level of audio input to the AUDIO IN connector. The audio level is adjusted with the [AUDIO IN Level] knob on the front panel.

  • Page 23: Basic Operations

    The POWER lamp lights when power is turned on. Please wait until the Home screen is displayed. * The F-1 is equipped with a protection circuit. A brief interval (a few seconds) after power up is required before the unit will operate normally.

  • Page 24: Using Batteries

    * When there is no battery power to the F-1, the date/time settings can be saved for up to about thirty days. If batteries are inserted as a backup power supply, the date/time settings can be maintained for a longer period.

  • Page 25: Inserting The Batteries

    Please insert the batteries as shown in the figure, taking care to orient the positive and negative terminals correctly. Replace the battery case into the F-1. Do not allow any foreign metal objects to touch the terminals of the battery case. Doing so may cause the batteries to short and the battery case may overheat or catch fire.

  • Page 26: Setting Battery Type

    Basic Operations Setting Battery Type Select the type of battery to be used. * Incorrect battery settings can cause a problem in operation due to voltage drops. Please check the batteries and make the proper settings. Press the [MENU] button to access the Menu screen, and select the “Battery Type.”...

  • Page 27: Operating The Menu

    Basic Operations Operating the Menu The Menu screen appears when the [MENU] button is pressed. Various F-1 settings, such as capture and playback settings and date/time settings, are done from the Menu screen. * The Menu screen cannot be displayed during capture.

  • Page 28: Connecting To A Pc

    *c3.wav: Monaural WAV file for CH3 *c4.wav: Monaural WAV file for CH4 *.sph This file is needed to play back material on the F-1. This file does not need to be copied when using the “*.m2t” and “*.wav” files on non-linear software. *.vif * Copy with the “F-1 Utility”...

  • Page 29: Copying F-1 Materials To A Pc

    Copies F-1 materials to a PC connected via USB. • Please use the included AC adaptor when connecting with a PC. • Please do not format the F-1’s removable storage with the PC. The removable storage may become unusable. Supported OS...

  • Page 30: Connecting The Removable Storage To A Pc

    Connecting to a PC Connecting the Removable Storage to a PC F-1 materials can be copied to a PC by connecting the F-1’s removable storage directly to the PC using a USB cable. Please do not format the F-1’s removable storage with the PC. The removable storage may become unusable.

  • Page 31: Disconnecting The Pc

    Disconnects the F-1 and PC connected by USB. Follow the procedure below to disconnect, and then unplug the USB cable. Please do not turn F-1 power off or unplug the USB cable while the F-1 and PC are connected. Windows Close all applications and windows, such as Explorer, that reference the F-1’s...

  • Page 32: The "F-1 Utility

    * Please carefully read the instruction manual included with the “F-1 Utility” before using the “F-1 Utility.” * The “F-1 Utility” will not run if an F-1 or removable storage (F1-HD120) is not connected to the PC. See “Connecting the F-1 to a PC” (p. 29) for connection details.

  • Page 33: Copying F-1 Materials Over A Network

    Here’s how to copy F-1 materials to a PC connected to the network. Cautions Regarding File Sharing The F-1 cannot have a password set for “File Sharing.” For this reason, please do not use the PC file sharing feature on a network environment where unexpected access to the internet may occur.

  • Page 34: Remotely Controlling The F-1 From The Pc (F-1 Net Control)

    After reviewing “F-1 Folder Structure” (p. 28), please copy the necessary files to the PC. * Please do not unplug the LAN cable or turn off the F-1 while files are being copied (transferred). Failure to do so may result in the files being corrupted.

  • Page 35: Advanced Use

    Advanced Use Arranging Materials Regarding Folders The files of captured material are saved in “folders.” When shipped, one folder has already been created. Folders can be freely created, so use them to arrange the material files. Creating folders Press the [MENU] button to access the Menu screen, and select the “Create New Folder.”...

  • Page 36: Deleting Material Files

    Advanced Use Deleting Material Files Deletes the currently selected material files. Select the material to delete. With the Home screen or Audio Level screen shown, select the material to be deleted with the [ ( )] [ ( )] buttons. The name of the currently selected material file is displayed Material file name on the Home screen.

  • Page 37: Managing The Removable Storage

    Advanced Use Managing the Removable Storage Inserting/Removing The removable storage (included) is required to perform capture with the F-1. The removable storage can be exchanged with the separately available removable storage (F1-HD120). Please turn off power before removing or inserting the removable storage. Failure to do so may result in damage to the contents of the removable storage.

  • Page 38: Deleting All Data / Initializing (Formatting)

    • After initialization or deleting all data, all the data stored on the removable storage is erased. Please back up important data on a PC or USB mass storage device (p. 29, 33, 40, 41). • Please do not format the F-1’s removable storage with the PC. The removable storage may become unusable.

  • Page 39: Scanning (Internal Drive Check)

    Advanced Use Initializing (Formatting) Initializes (formats) the removable storage in NTFS format. * When the removable storage is initialized, a new folder is automatically created. Press the [MENU] button to access the Menu screen, and select the “Disk Utility.” Select the “Disk Utility” with the [ ( )] [ ( )] buttons, and then press the [...

  • Page 40: Using Usb Mass Storage

    Backing Up All Material Files Back up (copy) all F-1 material files to a USB mass storage device. * The “material” folder in the removable storage is backed up. See “F-1 Folder Structure” (p. 28) for details. Connect the USB mass storage device to the USB (HOST) connector.

  • Page 41: Copying The Currently Selected Material Files

    Advanced Use Copying the Currently Selected Material Files Copies the currently selected material files (*.m2t / *.dv, *.wav) to the USB mass storage device. Connect the USB mass storage device to the USB (HOST) connector. Press the [MENU] button to access the Menu screen, and select the “Disk Utility.”...

  • Page 42: Initializing (Formatting)

    Advanced Use Initializing (Formatting) Initializes (formats) the USB mass storage device in NTFS format. * Mac USB mass storage devices that have been initialized in NTFS format are read-only on Macs. * Initialization may not be possible depending on the USB mass storage device. •...

  • Page 43: Scanning (Usb Check)

    Advanced Use Scanning (USB Check) Scans for corrupted files on the USB mass storage device and repairs them. When the USB check is performed, files that have problems are repaired, and the frequency of errors can be reduced. Press the [MENU] button to access the Menu screen, and select the “Disk Utility.”...

  • Page 44: Operating By Connecting A Vga Display And Mouse

    Advanced Use Operating by Connecting a VGA Display and Mouse If a VGA display and mouse are connected to the F-1, basic operations can be performed while still in the field. Connecting Connect the VGA display/mouse to the F-1 as shown in the figure below The screen and mouse pointer are shown on the VGA display.

  • Page 45: File Information

    Displayed when a video-format WAV file is created. • WAV.Stereo: Stereo WAV file • WAV.MonoX2: Monaural WAV files F-1 Panel Displays the F-1 panel. File Information Displays the information of the currently selected file. Folder Folder save location File File name...

  • Page 46: Configuration Settings

    Starting Capture by Linking to a Camera You can synchronize the recording of the F-1 with a connected camera (Synchro Record Feature). * For material files created by using the Synchro Record feature, the capture starts a few seconds before the camera begins recording.

  • Page 47: Setting Peak Hold For The Audio Level Meter

    Configuration Settings Setting Peak Hold for the Audio Level Meter The Audio Level Meter on the Audio Level screen can display a temporary hold on the peak level (Peak Hold Feature). When the Peak Hold Feature is used, you can easily check the maximum audio level input from the AUDIO IN connector.

  • Page 48: Delaying Audio Output (Audio Delay)

    Configuration Settings Delaying Audio Output (Audio Delay) When video that was captured with a connected HDV/DV camera is played back, a delay occurs for the video because of the processing time. When matched to captured audio, the timing of the output is slightly off because the audio is output before the video. By delaying the audio output, the output timing gap between audio and video can be corrected.

  • Page 49: Setting The Date And Time

    Sets the internal clock. This is used as the date and time for when the capture material file is created. * When there is no battery power to the F-1, the date/time settings can be saved for up to about thirty days. If batteries are inserted as a backup power supply, the date/time settings can be maintained for a longer period.

  • Page 50: Setting Material File Playback Mode

    Configuration Settings Setting Material File Playback Mode The playback method for material files can be changed. Press the [MENU] button to access the Menu screen, and select the “Play Mode.” Select the “Play Mode” with the [ ( )] [ ( )] buttons, and then press the [ (ENTER)] button.

  • Page 51: Setting The Time Until The Display Turns Off (Display Timer)

    Configuration Settings Setting the Time until the Display Turns Off (Display Timer) To reduce power consumption, the display can be set to automatically turn off if there are no operations for a fixed period of time. Press the [MENU] button to access the Menu screen, and select the “Display Timer.”...

  • Page 52: Setting The Lamp Illumination Method

    Setting the Lamp Illumination Method The “POWER Lamp,” “REC Lamp,” and “Status Lamp” on the front panel light according to the F-1’s status. These lamps can also be set so they don’t light. Press the [MENU] button to access the Menu screen, and select the “LED.”...

  • Page 53: Setting The Language For Display

    (ENTER)] button. Restoring the Factory Defaults (Factory Reset) The F-1’s settings can be reset to the factory default settings. * See “Menu List” (p. 54) for details on the factory default settings. Press the [MENU] button to access the Menu screen, and select “Factory Reset.”...

  • Page 54: Appendices

    Appendices Menu List * The default value (factory setting) is printed in bold characters. Number Menu Item Value Sync Rec Disable, Sync Capture begins and is synchronized to the recording operation of the camera linked to the i.LINK connector. Audio Sync 0–17–30 Sets the delay for captured audio to correct the synchronization gap between audio and video (*.m2t or *.dv).
  • Page 55 Sets the subnet mask. Gateway (*1) 0.0.0.0–255.255.255.255 Sets the gateway. Port Number 50000–50003 Sets port number to remotely control the F-1 from a PC. Check Host Name — Displays the F-1’s host name. Display Brightness Level: 0–5–7 Adjusts the display brightness.

  • Page 56: Troubleshooting

    Troubleshooting If you suspect a malfunction, please check the following points. If this does not resolve the problem, contact a nearby EDIROL/Roland Service Center. Power Supply Problem Cause and Action ● The power won’t turn on Are you using an AC adaptor other than the one supplied? ➔...

  • Page 57: Audio Problems

    Could you have turned on the power to the F-1 after the PC and the F-1 using USB were already connected using USB? ➔ First turn on power to the F-1, then connect the PC and F-1 using USB (p. 29). ● *.dv files do not play on Is QuickTime™ installed on your PC? ➔...

  • Page 58: Other Problems

    Enter the following in Explorer on the PC. \\(IP address of the F-1)\F1DRIVE Example: \\169.254.78.100\F1DRIVE → * Verify the IP address of the F-1 using the menu items “Network Setting” “IP Address.” Other Problems Problem Cause and Action ●...
  • Page 59 If the unit does not operate normally when the power is turned on again, it may mean that the hard disk has been damaged. In such instances, consult your dealer or the nearest EDIROL/Roland Service Center. Note, however, that it may not be possible to recover any data from the removable storage once it has been lost.

  • Page 60: An Important Notice Regarding The Software

    An Important Notice Regarding the Software Before you use this product, you must read the following “Notice regarding the software included with this product.” Your use of this product shall be taken to indicate your consent to this notice. Microsoft Software License Terms for: ®...
  • Page 61 An Important Notice Regarding the Software 3. Scope of License. The software is licensed, not sold. This agreement only gives you some rights to use the software. Roland SG Corporation and Microsoft reserve all other rights. Unless applicable law gives you more rights despite this limitation, you may use the software only as expressly permitted in this agreement.
  • Page 62 An Important Notice Regarding the Software • Digital Certificates. The software uses digital certificates. These digital certificates confirm the identity of Internet users sending X.509 standard encrypted information. The software retrieves certificates and updates certificate revocation lists. These security features operate only when you use the Internet.
  • Page 63 An Important Notice Regarding the Software 9. Not Fault Tolerant. The software is not fault tolerant. Roland SG Corporation installed the software on the device and is responsible for how it operates on the device. 10.Restricted Use. The Microsoft software was designed for systems that do not require fail- safe performance.

  • Page 64: Main Specification

    860 g / 1 lb 91 oz (including HDD, excluding AC Adaptor and batteries) Operation Temperature +5 to +40 degrees Celsius +41 to +104 degrees Fahrenheit Bundled Software F-1 Utility / F-1 Net Control Functions File Browser, Remote Control via Network System OS:Windows XP SP2 or later, Windows Vista SP1 or later...

  • Page 65: Dimensions

    Main Specification Dimensions Dimensions are shown in millimeters.

  • Page 66: Optional Accessories

    The following products are offered as optional accessories. V-Mount Kit F1-VMK1 When the F1-VMK1 V-Mount Kit is installed on the F-1, the F-1 can be attached to devices that support V-Mount. In addition, the Endura Battery (V-Mount type) from IDX Company, Ltd. can also be used.

  • Page 67: Index

    ........Creating ........Connecting ........Deleting ........Copying ........Selecting ........ Disconnecting ........Structure ....... F-1 Net Control ........Format Int. Drive ........F-1 Utility Formatting ......Network connection ......Removable storage ......Network settings ......USB mass storage ......
  • Page 68 Optional accessories .......... HDV lamp ................Home screen Connecting ........Copying ......... Disconnecting ............... i.LINK cable F-1 Net Control ........Initializing (Formatting) F-1 Utility ........... Removable storage Network connection ............USB mass storage Network settings ...............
  • Page 69 Index Scanning ......Removable storage ......USB mass storage ........Select Folder ........Set Time & Date ..........sph file ........Stereo WAV file Storage See Removable storage See USB mass storage ........Subnet Mask ......Synchro record feature ........... Sync Rec ..........
  • Page 70 For EU Countries For China...
  • Page 71 For EU Countries This product complies with the requirements of EMC Directive 2004/108/EC. For the USA FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 72: Information

    Information When you need repair service, call your nearest EDIROL/Roland Service Center or authorized EDIROL/Roland distributor in your country as shown below. CZECH REP. HUNGARY CENTRAL/LATIN OCEANIA ASIA Roland East Europe Ltd. CZECH REPUBLIC AMERICA Warehouse Area ‘DEPO’ Pf.83 DISTRIBUTOR s.r.o...
