- Page 1 PARTS LIST N1095 SERIES PANEL DOOR MODELS N1095 N1095IM N1095IMV N1095V WRAPPED DOOR MODELS N1095BK M1095BKV N1095IMBK N1095SS N1095IMSS N1095WH * * WHITE WRAPPED MODELS NO LONGER PRODUCED PART NO. 624870 NORCOLD 10/15/2010...
- Page 2 UPPER DOOR (FREEZER) - MODEL SERIES N1095 - PANEL TYPE N1095 PANEL DOOR MODELS N1095V PART # DESCRIPTION N1095 N1095IM N1095IMV 619558 PANEL RETAINER-UPPER DOOR/BLACK/WDL 623943 PANEL RETAINER-UPPER DOOR/PANEL/BLACK/SDL 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL 619671 HINGE BUSHING-DOOR/WARM GRAY/WDL/SDL 619627 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/WDL 623945 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/SDL 618160...
- Page 3 LOWER DOOR (FRESH FOOD) - MODEL SERIES N1095 - PANEL TYPE N1095 PANEL DOOR MODELS N1095V PART # DESCRIPTION N1095 N1095IM N1095IMV 619560 PANEL RETAINER-LOWER DOOR/8’/BLACK/WDL 623760 PANEL RETAINER-LOWER DOOR/8’/BLACK/SDL 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL 619671 HINGE BUSHING-DOOR/WARM GRAY (2 PER DOOR) 619631 DOOR LINER ASSY-LOWER/8’/PANEL/BLACK FRAME/WDL 623942...
- Page 4 UPPER DOOR (FREEZER) - MODEL SERIES N1095 - WRAP TYPE N1095 WRAPPED DOORS PART # DESCRIPTION BLACK STAINLESS WHITE 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL 619671 HINGE BUSHING-DOOR/WARM GRAY/WDL/SDL 625874 DOOR ASSY-UPPER/WRAP/BLACK/WDL 627121 DOOR ASSY-UPPER/WRAP/BLACK/SDL (USE 632732) 632732 DOOR ASSY-UPPER/AT/WRAP/BLACK/SDL (FROM 07/10/08 TO S/N 12965198) 634065 DOOR ASSY-UPPER/ANCO/WRAP/BLACK/SDL (SERIAL # 12965199 &...
- Page 5 LOWER DOOR (FRESH FOOD) - MODEL SERIES N1095 - WRAP TYPE N1095 WRAPPED DOORS PART # DESCRIPTION BLACK STAINLESS WHITE 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK/WDL 619671 HINGE BUSHING-DOOR/WARM GRAY/WDL/SDL 625875 DOOR ASSY-LOWER/8’/WRAP/BLACK/WDL/POWDER COAT 627129 DOOR ASSY-LOWER/8’/WRAP/BLACK/SDL (USE 634067) 632738 DOOR ASSY-LOWER/8’/WRAP/AT/BLACK/SDL (FROM 07/10/08 TO S/N 12965198) (USE 634067) 634067 DOOR ASSY-LOWER/8’/WRAP/ANCO/BLACK/SDL (SERIAL # 12965199 &...
- Page 6 CABINET AREA (FRONT VIEW) - MODEL SERIES N1095 N1095 SERIES PARTS LIST - PAGE 6...
- Page 7 CABINET AREA (FRONT VIEW) - MODEL SERIES N1095 PART # DESCRIPTION N1095 N1095IM 620915 KIT-INSTALLATION/BLACK (TRIM PIECES/SCREWS) 625184 BRACKET FOAM TAPE ASSY-TOP/MOUNTING 623550 HINGE-CABINET/TOP/BOTTOM/(PANEL/WDL)(WRAP/SDL) 626659 HINGE-CABINET/TOP/BOTTOM/PANEL/SDL 619335 HINGE-CABINET/3 POINT/TOP RH/BTM LH/BLACK/WDL 623771 HINGE-CABINET/3 POINT/TOP RH/BTM LH/PANEL/BLACK/SDL 624785 HINGE-CABINET/3 POINT/TOP RH/BTM LH/WRAP/BLACK/SDL 619336 HINGE-CABINET/3 POINT/TOP LH/BTM RH/BLACK/WDL 623772...
- Page 8 CABINET AREA (REAR VIEW/COOLING UNIT) - MODEL SERIES N1095 PART # DESCRIPTION N1095 N1095IM 632316 NSC SYSTEM PACK-COOLING UNIT/N1095/ (BACKER HEATER) 2M0802 KIT-THERMAL SWITCH/BRACKET ASSY (SEE NOTE) 618111 BAFFLE DIFFUSER/WIRE ASSY-COOLING UNIT (NOT SHOWN) 622391 DRAIN HOSE ASSY 622546 DRIP CUP-REAR/PLASTIC 61712637 COVER ASSY-BURNER BOX 61695322...
- Page 9 CONTROLS (REAR VIEW) - MODEL SERIES N1095 PART # DESCRIPTION N1095 N1095IM 618186 BASE-POWER BOARD (9045737 & BELOW) 628674 BASE-POWER BOARD (9045738 & ABOVE) 621269001 KIT-POWER BOARD (9045737 & BELOW) 628661 POWER BOARD (9045738 & ABOVE) 618185 COVER-POWER BOARD (9045737 & BELOW) 628677 COVER-POWER BOARD (9045738 &...
- Page 10 INTERIOR LIGHT AND THERMISTER ASSY - MODEL SERIES N1095 PART # DESCRIPTION N1095 N1095IM 61629722 LAMP BRACKET ASSY 632545 LAMP-DC LIGHT BULB 621827 COVER-LAMP BRACKET 620875 CLIP-THERMISTER MOUNTING/ADHESIVE BACK 620871 LAMP THERMISTER WIRE ASSY N1095 SERIES PARTS LIST - PAGE 10...
- Page 11 MODEL SERIES N1095 ICE MAKER AREA - (ICE MAKER MODELS) PART # DESCRIPTION N1095IM 61656822 COVER-FRONT/ICE MAKER 633324 KIT-ICE MAKER 621429 WATER TUBE/HEATER ASSY/FOR ICE MAKER 61346822 BUSHING-SNAP 620951 FITTING-WATER TUBE 618407 WIRING HARNESS-IM 621484 BRACKET-IM MOUNTING 633325 KIT-WATER VALVE-SINGLE PORT 618169 SPACER-WATER VALVE/NYLON 61679622...
- Page 12 FAN SYSTEM COMPONENTS - MODEL SERIES N1095 NOTE: LOWER FAN POSITION - MODELS WITH SERIAL # BELOW 9056492 HIGH VELOCITY HIGH VELOCITY WITHOUT ICE PART # DESCRIPTION WITH ICE MAKER WITHOUT ICE WITH MAKER MAKER MAKER 618857 BRACKET-DC FAN 619016 BRACKET-FAN SUPPORT 61417922 CABLE TIE-NYLON...
