The MF ACTIVA Combine; cost-effective harvesting flexibility
7200
7200
7200
MF
MF
Now 6 models, with 5 or 6 straw walkers
Advertisement
Related Manuals for MASSEY FERGUSON 7200 ACTIVA - BROCHURE 176-275
Summary of Contents for MASSEY FERGUSON 7200 ACTIVA - BROCHURE 176-275
- Page 1 7200 7200 7200 176-275 176-275 The MF ACTIVA Combine; cost-effective harvesting flexibility Now 6 models, with 5 or 6 straw walkers VISION INNOVATION LEADERSHIP QUALITY RELIABILITY SUPPORT PRIDE COMMITMENT VISION INNOVATION LEADERSHIP QUALITY RELIABILITY SUPPORT PRIDE COMMITMENT...
- Page 2 Straightforward combines that simply get the job done Massey Ferguson’s enlarged ACTIVA range of combine harvesters are built using proven technology, drawn from over 40 years experience of designing and engineering harvesting equipment. They provide growers with a highly cost-effective and flexible harvesting solution.
- Page 3 The ACTIVA range Model Horsepower Straw walkers Grain tank capacity MF ACTIVA 7240 5200 MF ACTIVA 7244 7000 MF ACTIVA 7245 7000 MF ACTIVA 7245 S 7000 MF ACTIVA 7245 S AL 7000 MF ACTIVA 7246 7500 MF ACTIVA 7247 S 8800...
- Page 4 A smooth first contact The multi-crop FreeFlow cutting tables on MF ACTIVA combines are designed for high capacity and long-term durability. Available in widths from 4.2 to First contact with the standing All reel adjustments are made 7.6 metres, the FreeFlow cutting crop is made by a high using the hydro lever in the cab, tables are engineered down to the...
- Page 6 Threshing system – the heart of the combine Massey Ferguson’s design engineers have applied meticulous attention to this critical area of operation. A strongly constructed cylinder, • Its angle of operation can be This also ensures that a high straw...
- Page 8 Achieving the best possible sample One of critical factors in the harvesting process is to maintain a consistently good grain sample. Massey Ferguson’s threshing, separation and cleaning system helps to ensure this goal is achieved – in all harvesting conditions.
- Page 10 Handling residues to cut cultivation costs All MF ACTIVA models are equipped with a multi-adjustable straw chopper, designed to give unmatched chopping/spreading capability, and making these combines ideal for subsequent min-till operations. The straw chopper is engaged A chaff spreader is an option on all The double serrated rotating knives automatically and simultaneously models.
- Page 12 Ease of unloading With grain tank capacities of up to *8800 litres, these combines unload at an impressive rate of 85 litres/sec and the 4.0m auger provides more than enough unloading height (4.20m) and reach to fill high-sided trailers. *on the new MF ACTIVA 7247 S model The ACTIVA S benefits from a 4 quality and tank level, and there’s With grain tank capacities of up to...
- Page 14 Designed for quick and easy maintenance and moved around the combine to and the simplicity of the drives All ACTIVA combines are simple reach other components. means belts can be replaced and straightforward to maintainas the number of drives has been quickly without the need for designed to a minimum.
- Page 16 Maximum comfort for a stress-free harvest High levels of operator comfort column and comfortable training of functions such as drum speed, and safety, together with seat (not on the MF 7240). concave position and fan speed. thoughtful positioning of controls, a panoramic view and a constant The AgritronicPlus monitor and flow of harvesting information,...
- Page 18 The wonder of Auto Level The MF 7245 S AL ACTIVA model comes with the innovative full machine levelling system as standard.
- Page 19 This ingenius system levels the customers and contractors where of working in, combine harvesters combine rump across slopes with Auto Level can be fitted with a there is marginal land to be by pivoting the front final drives. powered rear axle to give genuine harvested.
- Page 20 The new MF 7240 ACTIVA This new introduction to the ACTIVA range aims to meet the requirements of smaller scale arable enterprises and mixed farms whilst still offering high-powered, quality harvesting.
- Page 21 The MF 7240 ACTIVA combine All the main functions are Like all Massey Ferguson combines, boasts a straight-forward, monitored by a clear and concise the ACTIVA 7240 is equipped with a uncomplicated design and electronic display. For added turret unloading auger that empties...
- Page 22 MF 7200 ACTIVA features 09 Grain Tank 01 FreeFlow Table The grain tank maintains clean grain discharge, adequate To improve cutting in difficult conditions, the table angle volume and prevents water from entering. can be altered. Working with the high-speed Schumacher knife, crop can be gathered easily by the large diameter 10 Engine auger fitted with full length retractable fingers.
-
Page 24: Customer Support
Customer support Dedicated service Massey Ferguson is a true, Year round distinction global brand with machines Naturally we recognise that and dynamic operating all over the world, and supporting our harvest equipment behind every Massey Ferguson goes beyond the harvest period. -
Page 26: Our Promise To You
Our promise to you Our mission at Massey Ferguson, since the company was founded, has been to design, engineer and manufacture reliable, trustworthy and innovative machinery. Machinery that people recognise the world over. VISION RELIABILITY Our vision for the world of agricultural machinery We don’t let a Massey Ferguson machine out of our... - Page 28 Cutting table MF 7240 MF 7244 MF 7245 MF 7246 Cutting width 4.20 - 5.40 4.20 - 7.60 4.20 - 7.60 4.80 - 7.60 Terra Control cutting height control – Auto Level table guidance Cutting frequency (stroke/min.) 1220 1220 1220 1220 Feed type No.
- Page 29 Cutting table MF 7245 S MF 7245 S AL MF 7247 S Cutting width 4.20 - 7.60 4.20 - 7.60 4.80 - 7.60 Terra Control cutting height control Auto Level table guidance Cutting frequency (stroke/min.) 1220 1220 1220 Feed type Power Feed Roller No.
- Page 30 Grain tank MF 7240 MF 7244 MF 7245 MF 7246 Capacity 5200 7000 7000 7500 Unloading rate (l/sec) Unloading type Turret unloading Swivel angle of unloading auger degrees Max. unloading height 4.20 4.20 4.20 4.20 Engine Engine type make IVECO NEF Cubic capacity Power (kW/ hp)
- Page 31 Grain tank MF 7245 S MF 7245 S AL MF 7247 S Capacity 7000 7000 8800 Unloading rate (l/sec) Unloading type Turret unloading Swivel angle of unloading auger degrees Max. unloading height 4.20 4.20 4.20 Engine Engine type make IVECO NEF AGCO SISU POWER Cubic capacity Power...
- Page 32 Massey Ferguson’s threshing, separation and The NEW MF 7240 ACTIVA combine boasts cleaning system helps to ensure a consistently a straight-forward, uncomplicated design and good grain sample –...
