125 PSI Oil-Lube 26 Gallon Tank Air Compressor
OPERATOR'S MANUAL
Caution
:
l
Before using your air compressors, please read this manual carefully to understand the proper use
of your unit
l
Keep this manual handy
WARNING: This product and dust created by its use may contain chemicals,
including lead, known to the State of California to cause cancer, birth defects, or
other reproductive harm. Wash hands after handling. For more information, visit
www.P65warnings.ca.gov.
Model: GYC6260
DO NOT RETURN TO STORE!
HAVE QUESTIONS OR NEED SERVICE?
1-866-591-8921
support@pulsar-products.com
Advertisement
Related Manuals for Goodyear GYC6260
Summary of Contents for Goodyear GYC6260
- Page 1 Model: GYC6260 125 PSI Oil-Lube 26 Gallon Tank Air Compressor OPERATOR'S MANUAL Caution Before using your air compressors, please read this manual carefully to understand the proper use of your unit Keep this manual handy DO NOT RETURN TO STORE!
- Page 2 Preparation & Installation…………………………………5 Parts List……………….……………….……….……………..12 Operation……………………………………………….…….6 Introduction Thank you for choosing this Goodyear Air Compressor. Safety Definitions This manual provides instructions on operating and using your air compressor safely and correctly; be sure to read and This manual contains important information regarding understand this manual before using your air compressor.
- Page 3 Safety Instructions Hazard Warnings Rick of Moving Parts WARNING This product may expose you to chemicals, including Risk of Burns lead and DEHP, which are known to the State of California to cause cancer, birth defects, or other reproductive harm. Wash your hands thoroughly after handling.
- Page 4 Safety Instructions WARNING Risk Of Falling The air compressor must always be operated in a stable What could happen: position. Never use the compressor on a rooftop or any elevated surface where it could fall or tip over. For Abrasive tools such as sanders and grinders, rotating elevated tasks, use additional air hose instead.
- Page 5 Safety Instructions Risk Of Electric Shock Risk of Bursting Always drain the air compressor tank daily or after each WARNING use. If the tank develops a leak, replace the air compressor immediately. Never use the air compressor What could happen: after a leak is detected, nor attempt to repair or modify the tank.
- Page 6 Preparation & Installation Parts Air Intake Filter: Provides clean air to the pump and must always be kept free of debris. Inspect daily before each use. Check Valve: An internal component that closes when the pump is not in operation to retain air pressure inside the tank.
- Page 7 Preparation & Installation Operation Extension Cord Use CAUTION Use only a 3-wire extension cord equipped with a 3- This product contains an electric motor that may blade grounding plug and a 3-slot receptacle produce arcs and sparks during operation. Do not use compatible with the product's plug.
- Page 8 Maintenance Operation NOTICE Turn on the Compressor: Switch on the compressor and allow it to reach the cut-out pressure before use. Any service procedures not outlined in the maintenance schedule must be performed by qualified Test Operation: Check the functionality of connected service personnel.
- Page 9 Maintenance Storage Instructions Air Filter Cleaning Follow these steps when storing the air compressor: Occasionally, the air filter should be removed and cleaned. Follow these steps: Turn Off and Unplug: Switch off the unit and unplug the power cord from the receptacle. Charge the Tank: Charge the tank with compressed air, then turn off the compressor and unplug it.
- Page 10 Troubleshooting Guide Problem Possible Causes Probable Solutions Power source issue, blown Check if the power cord is properly plugged in. fuse, or tripped circuit Verify outlet functionality. Reset circuit breaker or COMPRESSOR FAILS TO START breaker replace fuse with a time-delay type. Avoid using extension cords.
- Page 11 Specifications Product Description 26 Gallon Oil-lube Air Compressor Oil Type Oil-lube Configuration Vertical Tank Capacity (gallon) SCFM @ 90PSI SCFM @ 40PSI Peak Power (hp) Rated Power (hp) Max Pressure (psi) Cut-in Pressure (psi) Cut-out Pressure (psi) Pressure Gauges Quick Connect Coupler 1PC, Universal, NPT1/4 Wheels 10"...
- Page 12 Exploded View...
- Page 13 Parts List Num# Part # Specification 45.014 Bolt M8x105 45.229 Spring Washer M8 03.100 Cylinder Head 35.006A Gasket of Cylinder Head 11.004 Valve Plate 35.006B Gasket of Cylinder Upper 10.004 Cylinder 35.006C Gasket of Cylinder Lower 29.021 Piston Ring 46.005 Circlip 12 28.003 Piston...
- Page 14 46.010 Circlip 14 45.079A Nut M6 45.139 Screw M6x16 45.203 Screw M4x6 45.058 Lock Washer M4 40.002C Exhaust Elbow 45.044 Bolt M8x30 45.064 Washer M8 45.291 Nut M8 36.016 Rubber Pad 21.011A Pressure Switch 23.006 Pressure Gauge NPT1/4 23.004 Pressure Gauge NPT1/8 42.028 Connect NPT1/4X48 24.010...
- Page 15 1-866-591-8921 or email support@pulsar-products.com. Goodyear (and Winged Foot Design) are trademarks of or licensed to The Goodyear Tire & Rubber Company or Goodyear Canada Inc. used under license by Pulsar Products Inc., 8676 Rochester Ave., Rancho Cucamonga, CA 91730. © 2024 The...
