- Page 1 EN User Manual | Hob KGS7524SX...
- Page 2 Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................11 5.
- Page 3 • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. • If the appliance has a child safety device, it should be activated.
- Page 4 • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. • If the supply cord is damaged, it must be replaced by the manufacturer, an authorized Service or similarly qualified persons in order to avoid a hazard.
- Page 5 under the appliance to prevent access to fuses removed from the holder), earth the bottom. leakage trips and contactors. • The electrical installation must have an 2.2 Electrical Connection isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact WARNING! opening width of minimum 3 mm.
- Page 6 CAUTION! WARNING! The use of a gas cooking appliance Risk of damage to the appliance. results in the production of heat, moisture • Do not keep hot cookware on the control and products of combustion in the room panel. in which it is installed. Ensure that the •...
- Page 7 use abrasive products, abrasive cleaning • Contact your municipal authority for pads, solvents or metal objects. information on how to dispose of the • Do not clean the burners in the appliance. dishwasher. • Disconnect the appliance from the mains supply.
- Page 8 Rigid connection: Carry out connection by using metal rigid pipes (copper with mechanical end) (UNI-CIG 7129). Flexible connection: Use a flexible pipe in stainless steel (UNI-CIG 9891) with a maximum length 2 m. WARNING! When installation is complete, make sure that the seal of each pipe fitting is correct.
- Page 9 Make sure that the cable section is applicable WARNING! to the voltage and the working temperature. The yellow / green earth wire must be Make sure the flame does not go out approximately 2 cm longer than the brown (or when you quickly turn the knob from the black) phase wire.
- Page 10 CAUTION! Install the appliance only on a worktop with flat surface. 3.8 Installing hob under the hood If you install the hob under a hood, please see the installation instructions of the hood for the minimum distance between the appliances. 3.9 Possibilities for insertion The panel installed below the hob must be easy to remove and let an easy access in...
- Page 11 4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Semi-rapid burner Rapid burner Auxiliary burner Control knobs 4.2 Control knob Symbol Description Symbol Description ignition position / maximum gas supply no gas supply / off position minimum gas supply 5. DAILY USE A.
- Page 12 2. Keep the control knob pushed for equal or less than 10 seconds. This lets the thermocouple warm up. If not, the gas If the burner accidentally goes out, turn supply is interrupted. the control knob to the off position and try 3.
- Page 13 CAUTION! Burner Diameter of Make sure that the pots are placed cookware (mm) centrally on the burner in order to get the Rapid 180 - 260 maximum stability and a lower gas consumption. Semi-rapid 120 - 240 Auxiliary 80 - 180 6.2 Diameters of cookware Use cookware with diameters applicable to the size of burners.
- Page 14 stains, shiny metallic discoloration. Clean the hob with a moist cloth and a non- abrasive detergent. After cleaning, wipe the hob dry with a soft cloth. • To clean the enamelled parts, caps and crowns, wash them with warm soapy water and dry them carefully before you put them back on.
- Page 15 8.2 If you cannot find a solution... instructions about the Service Centre and conditions of guarantee are in the guarantee If you cannot find a solution to the problem booklet. yourself, contact your dealer or an Authorised Service Centre. Give the data from the rating 8.3 Labels supplied with the plate.
- Page 16 NOMINAL GAS FLOW g/h POWER kW POWER kW MARK G30 28-30 G31 37 mbar mbar Rapid 0,95 Semi-rapid Auxiliary 0,33 10. ENERGY EFFICIENCY 10.1 Product information according to EU 66/2014 Model identification KGS7524SX Type of hob Built-in hob Number of gas burners ENGLISH...
- Page 17 Help protect the environment and human health by recycling waste of electrical and Electrolux Appliances AB - Contact Address: electronic appliances. Do not dispose of Al. Powstancow Slaskich 26, 30-570 Krakow, appliances marked with the symbol...
- Page 20 867345253-F-372023...
