48TC units for installation in the United States contain use of Carrier's Staged Air Volume (SAV™) 2-speed

indoor fan control system. This complies with the U.S. Department of Energy (DOE) efficiency standard of

2018.

48TC units for installation outside the United States may or may not contain use of the SAV 2-speed indoor fan

control system as they are not required to comply with the U.S. Department of Energy (DOE) efficiency

standard of 2018.

For specific details on operation of the Carrier SAV 2-speed indoor fan system, refer to the Variable Frequency

Drive (VFD) Factory-Installed Option 2-Speed Motor Control Installation, Setup, and Troubleshooting manual.

CONTENTS

SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . 1

GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Rated Indoor Airflow (cfm) . . . . . . . . . . . . . . . . . . . . . 3

INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Job-Site Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Step 1 — Plan for Unit Location . . . . . . . . . . . . . . . . 17

• ROOF MOUNT

Step 2 — Plan for Sequence of Unit Installation . . . 17

• ROOF CURB MOUNT

• PAD-MOUNTED INSTALLATION

• FRAME-MOUNTED INSTALLATION

Step 3 — Inspect Unit . . . . . . . . . . . . . . . . . . . . . . . . 18

Step 4 — Provide Unit Support . . . . . . . . . . . . . . . . . 18

• SLAB MOUNT

• ROOF CURB MOUNT

• ALTERNATE UNIT SUPPORT (IN LIEU OF SLAB OR

CURB MOUNT)

Step 5 — Rig and Place Unit . . . . . . . . . . . . . . . . . . . 18

• POSITIONING ON CURB

Step 6 — Field Fabricate Ductwork . . . . . . . . . . . . . 23

Step 7 — Horizontal Duct Connection . . . . . . . . . . . 23

Step 8 — Install Outside Air Hood (Factory-

Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Step 9 — Install Flue Hood and Combustion Air

Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Step 10 — Install Gas Piping. . . . . . . . . . . . . . . . . . . 24

• GAS SUPPLY LINE

• FACTORY-OPTION THRU-BASE CONNECTIONS

Step 11 — Install External Condensate Trap and

Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Step 12 — Make Electrical Connections . . . . . . . . . 27

• FIELD POWER SUPPLY

• UNITS WITHOUT FACTORY-INSTALLED NON-

FUSED DISCONNECT

• UNITS WITH FACTORY-INSTALLED NON-FUSED

DISCONNECT

• TO FIELD INSTALL THE NFD SHAFT AND HANDLE

• ALL UNITS

• CONVENIENCE OUTLETS

• FACTORY-OPTION THRU-BASE CONNECTIONS

Humidi-MiZer® Control Connections . . . . . . . . . . . . 31

• HUMIDI-MIZER – SPACE RH CONTROLLER

Staged Air Volume (SAV™) with Variable Frequency

Drive (Factory-Installed Option) . . . . . . . . . . . . . . 34

EconoMi$er® X (Factory-Installed Option) . . . . . . . 34

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.

Catalog No. 04-53480269-01

Single Package Rooftop with Gas Heat/Electric Cooling

Horizontal Air Flow Unit with Puron

Installation Instructions

Printed in U.S.A.

Form 48TC-18-29-H-04SI

• PRODUCT DESCRIPTION

• SYSTEM COMPONENTS

• SPECIFICATIONS

• INPUTS

• OUTPUTS

• ENVIRONMENTAL

• ECONOMIZER MODULE WIRING DETAILS

• S-BUS SENSOR WIRING

• CO2 SENSOR WIRING

• INTERFACE OVERVIEW

• USER INTERFACE

• KEYPAD

• MENU STRUCTURE

• SETUP AND CONFIGURATION

• TIME-OUT AND SCREENSAVER

• ENTHALPY SETTINGS

• TWO-SPEED FAN OPERATION

• CHECKOUT

• TROUBLESHOOTING

PremierLink™ Control . . . . . . . . . . . . . . . . . . . . . . . 47

RTU Open Control System. . . . . . . . . . . . . . . . . . . . 47

Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Smoke Detectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

• RETURN AIR SENSOR TUBE INSTALLATION

• SMOKE DETECTOR TEST MAGNET

• ADDITIONAL APPLICATION DATA

Step 13 — Adjust Factory-Installed Options . . . . . 61

• ECONOMI$ER IV OCCUPANCY SWITCH

Step 14 — Install Accessories . . . . . . . . . . . . . . . . . 61

Step 15 — Check Belt Tension . . . . . . . . . . . . . . . . 61

• BELT FORCE — DEFLECTION METHOD

• BELT TENSION METHOD

Pre-Start and Start-Up . . . . . . . . . . . . . . . . . . . . . . . 62

START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . CL-1

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can be

hazardous due to system pressure and electrical components. Only

trained and qualified service personnel should install, repair, or

service air-conditioning equipment.

Untrained personnel can perform basic maintenance functions of

cleaning coils and filters and replacing filters. All other operations

should be performed by trained service personnel. When working

on air-conditioning equipment, observe precautions in the litera-

ture, tags and labels attached to the unit, and other safety precau-

tions that may apply.

Follow all safety codes, including ANSI (American National Stan-

dards Institute) Z223.1. Wear safety glasses and work gloves. Use

Pg 1

8-19

WeatherMaker

48TC 18-29

(R-410A) Refrigerant

Replaces: 48TC-18-29-H-03SI
