- Page 1 User’s manual – A S Fitness Trampoline hexagon REBO Fitness Trampoline hexagon blue/red AR-HE-FT48HB/ AR-HE-FT48HR Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting in AREBOS.
- Page 2 User’s manual – A S Fitness Trampoline hexagon REBO Contents 1. Security instructions ..........3 1.1 Explanation of symbols ........... 3 1.2 General safety instructions ..........3 2. Use ................ 4 2.1 Before first use ............... 4 2.2 Important instructions before the assembly ....4 3.
- Page 3 User’s manual – A S Fitness Trampoline hexagon REBO Please read and save these instructions. Read through this user’s manual carefully before using this product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property.
- Page 4 User’s manual – A S Fitness Trampoline hexagon REBO • Start training slowly and increase training intensity. Excessive or improper use may increase the risk of damage to the trampoline or endanger the health of the user. • The trampoline is intended for people who are fit and healthy. Do not use the trampoline after eating food, alcoholic beverages or narcotics.
- Page 5 User’s manual – A S Fitness Trampoline hexagon REBO • Do not attach anything to the trampoline. • Do the exercises only on the trampoline. Do not jump over the trampoline. • This trampoline can be used both inside and outside. It is not recommended to store the trampoline outdoors.
- Page 6 User’s manual – A S Fitness Trampoline hexagon REBO 3. Parts list Description Part Quantity Elastic mat Frame segments Legs with rubber caps Elastic cords Handle and upper half handle bar Lower half handle bar Crossbar Locking screw Hexagon bolts (short) Hexagon bolts (long) Long screws with rubber buffers, nuts and...
- Page 7 User’s manual – A S Fitness Trampoline hexagon REBO 4.1 Assembly of the frame • Put the frame segments together. • One of the frame parts shows a small recess. This is where you insert the handle in the later procedure.
- Page 8 User’s manual – A S Fitness Trampoline hexagon REBO 4.2 Assembly of the bungee ropes • After the frame has been built, attach the jump mat to it. Place the mat on the floor with the hooks facing upwards. These hooks are used to attach the bungee ropes. •...
- Page 9 User’s manual – A S Fitness Trampoline hexagon REBO • Now pull the elastic bungee rope under the frame bar through.
- Page 10 User’s manual – A S Fitness Trampoline hexagon REBO • Guide the bungee rope around the frame bar and hook the opposite side into the fastening hooks as well. Use the same procedure for the edge cover. • If the loop of the bungee rope is twisted, open the connection and thread the rope again as shown.
- Page 11 User’s manual – A S Fitness Trampoline hexagon REBO 4.3 Assembly of the legs...
- Page 12 User’s manual – A S Fitness Trampoline hexagon REBO • Insert the legs into the screw necks. Twist each leg into its screw neck until it is firmly connected. Do not proceed with installation until the legs are firmly attached to the frame. 4.4 Assembly of the handle...
- Page 13 User’s manual – A S Fitness Trampoline hexagon REBO • Put the trampoline on its legs. Position the lower half of the handlebar next to the middle of the crossbar and frame. Insert the upper handlebar and adjust the locking wheel to the required height.
- Page 14 User’s manual – A S Fitness Trampoline hexagon REBO • Finally, secure the handle with the hexagon head screw and the Allen key. 5. Specifications Model AR-HE-FT48HB/ AR-HE-FT48HR Handlebar height 90-140 cm User weight max. 120 kg Weight 12,5 kg...
- Page 15 User’s manual – A S Fitness Trampoline hexagon REBO 6.Storage and maintenance • Clean the trampoline only with warm water and mild soap. Do not use aggressive or sharp detergents or soaps as this may cause serious damage to the mat. •...
- Page 16 Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 97074 Würzburg You can find the return address in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 The court of entry in the commercial register is Würzburg, HRB 10082 WEEE-Reg.-Nr. DE 61617071...
