User's Manual – A
S Standard Trampoline 8/10/12 Feet
REBO
Standard Trampoline 8/10/12 Feet
AR-HE-TR244/305/366cm
*Picture may vary depending on variant
Please follow all security measures in this user´s manual to ensure a secure use.
Thank you for trusting in AREBOS.
1
Advertisement
Related Manuals for AREBOS AR-HE-TR244cm
Summary of Contents for AREBOS AR-HE-TR244cm
- Page 1 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO Standard Trampoline 8/10/12 Feet AR-HE-TR244/305/366cm *Picture may vary depending on variant Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
- Page 2 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO Table of Contents 1. Safety Instructions ......3 1.1 Explanation of the symbols ......................3 1.2 General safety instructions ......................4 2. Assembly ..........5 2.1 Structure ............................5 2.2 Content of delivery ........................5 2.3 Assembly............................
- Page 3 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO Please read and save these instructions. Read through this user’s manual carefully before using this product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property.
- Page 4 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO 1.2 General safety instructions Your trampoline is designed for family outdoor use on soft ground (grass, sand, etc.). This trampoline is designed for one person at a time and weighs less than 100kg (Ø305cm) or 150kg (Ø366cm). The user must have bare feet or wear socks.
- Page 5 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO 2. Assembly Time needed: About 90 minutes. Be sure you have all of the following parts before you start the assembly. 2.1 Structure Frame 8ft - Ø 244cm Frame 10ft - Ø 305cm Height 230cm Height...
- Page 6 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO leg tube(4pcs); frame pad(1pc); 12 ft. Package 2 spring(36*2pcs); ladder(1pc) pole tube(16pcs); safety net(1pc); 12 ft. Package 3 long bolt(16pc); anchor kit(4pc) 2.3 Assembly Warning: Two adults in good physical condition are required for this installation. For your safety, wear suitable footwear and clothing to avoid injury.
- Page 7 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO 3. Connect the bent bars to form a circle. The second person presses against the circle at 180° to join the last joint. 4. Lift the circle and connect the legs. The two holes must fit together so that the bars can be added later (step...
- Page 8 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO 5. Place the jumping mat inside the circle using the springs and the hooks. Start in opposite directions at 90°/180°. Counting the spring slots helps to find the opposite position. 6.
- Page 9 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO 7. For the upper part of the trampoline, the safety net, start by connecting the upper and lower bars together. Place them on the jumping mat. 8. Lay out the bars in the safety net. Note: The zip must be at the bottom of the protective padding.
- Page 10 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO Lower bar Leg extension Set up as shown with the flat wedge. Push the screw through the lower bar, the plastic clasp and the leg extension. Use the washer before tightening the nut.
- Page 11 User’s Manual – A S Standard Trampoline 8/10/12 Feet REBO 3. Maintenance Check your trampoline regularly for defects or premature wear. Your trampoline has been manufactured using an anti-rust treatment. However, if rust marks appear after prolonged exposure, it is recommended that you remove them immediately with regular anti-rust treatment. 4.
- Page 12 Authorised representative for the technical documentation: Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
