Grizzly T34328 Instructions Manual

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The Model T34328 is an air-cooled WP17 TIG
torch designed for use with the Grizzly Model
T34311 3-in-1 Welder. This lightweight, lift-start
torch comes complete with two back caps, two
collets, a ceramic shield, and more than six feet
of cable to make moving around a workpiece easy
and straightforward.
Figure 1. Model T34328 TIG Torch.
Specifications
Cable Length .............................................. 79 in.
Maximum Amperage Range ..............120 - 200A
Electrode Diameter Range ..................
Cooling Method ...............................................Air
Start Method ................................................... Lift
Weight ......................................................1.9 lbs.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ " or
1
16
COPYRIGHT © FEBRUARY, 2025 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 10/24) #MN23492 PRINTED IN CHINA
***Keep for Future Reference***
MODEL T34328
TIG TORCH FOR
MODEL T34311
