SYMPL essential2 Node m:pix
Information for Use
Read the Information for Use and the Safety Instructions
carefully. Subject to modification without prior notice.
Typographical and other errors do not justify any claim for
damages. Modification of the product is prohibited.
This document is designed for electricians and system
administrators of the product.
All product names and trademarks mentioned in this manual are
trademarks of their respective owners.
Except for internal use, relinquishment of the instructions to a
third party, duplication in any type or form - also extracts - as
well as exploitation and / or communication of the contents is not
permitted.
Downloads and more information at:
www.ecue.com
IC: CL24100000835
Edition:
09.05.25 [EN_SYMPL_essential2mpix_Node_Setup_v1p0]
Published by:
Traxon Technologies Europe GmbH
Karl-Schurz-Strasse 38
33100 Paderborn, Germany
©2025 Traxon Technologies Europe GmbH
All rights reserved
Traxon Technologies Europe GmbH
Sales Operations
Karl-Schurz-Str. 38
33100 Paderborn, Germany
+49 5251 54648-0
support@ecue.com
Advertisement
Related Manuals for Traxon ecue SYMPL essential2 Node m:pix
Summary of Contents for Traxon ecue SYMPL essential2 Node m:pix
- Page 1 33100 Paderborn, Germany third party, duplication in any type or form - also extracts - as well as exploitation and / or communication of the contents is not ©2025 Traxon Technologies Europe GmbH permitted. All rights reserved Downloads and more information at: Traxon Technologies Europe GmbH www.ecue.com...
- Page 2 Test mode via Web interface Firmware Update Dismounting Certifications Dimensions 12.1 About the SYMPL essential2 Node m:pix 12.2 Protocols 12.3 System 12.4 Power supply 12.5 Network 12.6 Update WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 2 / 2...
- Page 3 When using a power supply unit, the device must be supplied by a separate power supply that is certified according to the local regulations (e.g. SELV, Class 2). — If safety instructions are missing, please contact Traxon e:cue to receive a new copy. ...
- Page 4 1 x e:net 10/100 Mbit/s, RJ45 LEDs for Ethernet activity, device status, DMX status, error; User interfaces Identify button; Test button; web interface for confi guration WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 2 / 18...
- Page 5 LED Test / Error LED Status Power supply (V +, V –, „4.5 Power supply“ on page 8 GND left to right) „4.6 Grounding“ on page 9 WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 3 / 18...
- Page 6 Short-short-long sequence: Test mode active. On: If constantly lights in red, an error occurred. This can be an internal error or malfunction of the device. Switch the device off and on. If the error persists, contact Traxon e:cue Service. Status On: If constantly on, the device is online.
- Page 7 Before dismounting, appropriate measures must be taken to protect the respective components against damage caused by electrostatic discharge (ESD protection). — Do not try to repair the device. Return it to your Traxon e:cue distributor for replacement or repair. WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved.
- Page 8 Traxon’s portfolio undergoes continuous development to make it more secure. Traxon strongly recommends that updates are applied as soon as they are available and that the latest versions are used. Use of versions that are no longer supported, and failure to apply the latest updates may increase your exposure to cyber threats.
- Page 9 Never connect more than one SYMPL Node in factory state to a network. The identical IP addresses will conflict and disturb proper communication. — Ethernet cable must be shielded. WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 7 / 18...
- Page 10 To connect the device to a power supply unit, use the provided 3-pin terminal plug and lay the wires as stated on the front label. WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 8 / 18...
- Page 11 – DMX 1 DMX 2 DMX 3 DMX 4 DMX 5 DMX 6 DMX 7 DMX 8 SYMPL essential2 Node m:pix SUPPLY e:net + – WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 9 / 18...
- Page 12 The network configuration of the SYMPL essential2 Node m:pix is completed. Network configuration with the web interface Open a common web browser on a connected PC. Enter the SYMPL essential2 Node m:pix’s IP address into the address bar: e.g. http://192.168.123.1 WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 10 / 18...
- Page 13 You can change the login password to the SYMPL essential2 Node m:pix's configuration page and the device name of the SYMPL essential2 Node m:pix at “Settings” page. Do not forget the new password. WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 11 / 18...
- Page 14 Startup and the Offline output respectively are reverted to after exiting the Test mode. The Test mode is indicated by the blinking Test / Error LED. WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 12 / 18...
- Page 15 Click a button to choose a test pattern. Define the properties: Property Description Output DMX ports to run the test on. Channel Count Total frame length (0 - 1536). WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 13 / 18...
- Page 16 Disconnect all attached cables. Dismount the e:cue SYMPL essential2 Node from the rail by pulling the black DIN rail handle and unhitching the SYMPL essential2 Node. The dismounting is completed. 10 Certifications WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 14 / 18...
- Page 17 The m:pix protocol is a DMX based protocol that supports up to 1536 channels per universe, instead of the default 512 DMX channels. The connected fixtures need to support automatic speed detection or 750 kbit/s. WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 15 / 18...
- Page 18 Identification & Reset“ on page Can I repair the device myself? No. Do not try to repair the device. Return it to your Traxon e:cue distributor for replacement or repair. What can I do if my device does not work anymore? Please contact your supplier in case of malfunctioning.
- Page 19 10). What is the default value of the Addressing Port? The default port for the Adreesing Port is 5021 (UDP, used for the AddressPro tool). WWW.TRAXON-ECUE.COM ©2025 traxon technologies. All rights reserved. Information for Use 20255609 Sheet: 17 / 18...
- Page 20 You can find the latest firmware versions either on www.ecue.com. Or you will get a notification in SYMPHOLIGHT when an update is available. For more information see „8 Firmware Update“ on page content Please check for the latest updates and changes on the Traxon website. © 2025 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. www.traxon-ecue.com...
