- Page 1 BAR KPA X8 Air Inflator User Manual Model: X8 Please read this user manual carefully before use and keep if for future reference.
- Page 2 Thank you for choosing Fanttik. Thank you for purchasing Fanttik X8. For your own safety and the safety of others, please read through this manual carefully before using the product. Contents 1. PRODUCT OVERVIEW ..............................2. PACKAGE CONTENTS ..............................3. DISPLAY AND BUTTONS ..............................
- Page 3 1. PRODUCT OVERVIEW 1. Display screen 2. Power button 3. Mode button 4. Minus button 5. Light button 6. Plus button 7. Battery indicator 8. LED light 9. Air outlet 10. USB-C port - 02 -...
- Page 4 2. PACKAGE CONTENTS Air inflator x1 Nozzle and ball Presta valve needle adapter x1 adapter x1 USB cable x1 Air tube (for Storage bag x1 User manual x1 American valves) x1 *Carefully check the package contents. If anything is missing or damaged, please contact customer support.
- Page 5 3. DISPLAY AND BUTTONS Battery Level Current Unit BAR KPA Current Mode Pressure Value Detection Battery Level Indicator ● The battery level is shown by four bars, with each bar representing 25%. 1 bar = under 25% 2 bars = between 25% and 50% 3 bars = between 50% and 75% 4 bars = between 75% and 100% - 04 -...
- Page 6 Note: ● When the battery is fully charged, its total battery life will be around 30 minutes at 25°C ambient temperature and without any pressure load. ● Battery life and performance will decline as the ambient temperature falls or the pressure load climbs. ●...
- Page 7 NOTE: ● Each mode has a default unit. Long press the Mode Button for 3 seconds to switch the current unit between the 3 unit options(BAR, PSI, and KPA). ● The memory function enables the inflator to store the mode, unit, and pressure value and automatical- ly retrieve them after each start-up.
- Page 8 Button Functions ● Long press the Power Button to turn on the inflator. ● Short press the Power Button to start inflating. ● In the power-on state, long press the Power Button to turn off the inflator. ● After the mode is set, press the Plus Button to increase the preset pressure value. ●...
- Page 9 4. OPERATION AND FUNCTIONS Air Tube and Adapter Connection ① ● Connect the air tube onto the inflator’s air outlet by rotating clockwise. ● Choose an adapter according to the item to be inflated. - 08 -...
- Page 10 NOTE: ● The following data is for reference only. Please refer to the instructions for the item being inflated. Adapter Item to inflate Recommended pressure Motorcycle tires 1.8 - 3.0 BAR American valve (on the air tube) Car tires 2.2 - 2.8 BAR 12, 14, 16-inch bicycle tires 30 - 50 PSI 20, 22, 24-inch bicycle tires...
- Page 11 Mode Selection ② ● Before inflating for the first time, please fully charge the device. Turn on the inflator by long pressing the power button. ● ● Short press the Mode Button to switch between the following modes. ● Long press the Mode Button to switch the unit between KPA, PSI, and BAR. Bicycle icon (bicycle mode): Car icon (car mode): The preset pressure value: 45 PSI...
- Page 12 Note: Items such as balloons, toy balls, and swimming rings cannot be inflated using a preset pressure value because of their low inflation pressure. Be careful when inflating these items as it is easy to overinflate them, causing them to burst. ③...
- Page 13 ● The maximum pressure for balls is marked at the air valve ④ Inflation ● After the tube and adapter are connected and the mode is set, please connect the inflator to the valve of the item to be inflated. ●...
- Page 14 ● Detach the inflator from the target after everything cools down. ● Long-press the Power Button to turn off the inflator. After 3 minutes of inactivity, the system will automatically turn off. NOTE: Inflating for a long time will cause a build up of heat and pressure. Be careful not to directly touch the air tube or you could receive burns.
- Page 15 ● Please store the product in temperature ranging from -10℃ - 45℃. Extremely hot or cold environments may damage the battery and shorten the lifetime of the inflator. ● Long-time storage of the product may decrease the effectiveness of the battery. Charge the inflator at least once every three months to maintain its performance.
- Page 16 ● After running for a long time, the temperature of the junction between the air tube and the main body can become very high. To avoid burns, avoid touching it. ● This inflator is equipped with short circuit protection. Don't try to connect the wrong type of cable to the USB-C port.
- Page 17 -compliant one and charge with the charging original charging cable only *Please contact us at support@fanttik.com if you can not find a solution to your issue in the above table. We provide timely and effective online after-sales service. - 16 -...
- Page 18 We will repair or replace any defective your return package. product (due to manufacturing fault) within the warranty period. Purchase Name: How to Return Your Fanttik Product Contact support@fanttik.com with your order number. Order Number: We will issue you a return label for your return.
- Page 19 516-927-8658 Mon-Fri 9AM-5PM (ET) www.fanttik.com www.facebook.com/fanttikofficial support@fanttik.com AAT INNOVATION INC 228 PARK AVENUE SOUTH, #79525, NEW YORK, NY, United States, 10003...
