Hiseeu 8WK-3C40-1T Quick Manual

Wireless baery security camera system
Hide thumbs

Advertisement

Table of Contents

Wireless Ba ery Security
Camera System
Quick Guide
Suitable for Hiseeu Wireless Solar/Battery Camera System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8WK-3C40-1T and is the answer not in the manual?

Questions and answers

Related Manuals for Hiseeu 8WK-3C40-1T

Summary of Contents for Hiseeu 8WK-3C40-1T

  • Page 1 Wireless Ba ery Security Camera System Quick Guide Suitable for Hiseeu Wireless Solar/Battery Camera System...
  • Page 2                                        My system does not recognize that I have a hard ...

  • Page 3: Safety Caution

    Statement Thank you for purchasing Hiseeu product! This quick user guide will talk about main usages of the product.More information can be found on our website. Software download link:http://www.hiseeu.com/news/wsk Manual download link: http://www.hiseeu.com/news/wifi FAQ: http://www.hiseeu.com/news/wirelessskitfaq Email: johnny@hiseeu.com Safety Caution Please do not put any fluid container on the product.
  • Page 4 HDMI Port: For viewing on HDTV WIFI Antenna Ports: Double antennas to WIFI range WAN Port: Connect your NVR to Internet or USB Ports: For mouse and data backup data transmission with cameras Power Input: Use 12V2A power adapter VGA Port: For viewing on VGA monitor Solar/Battery Cameras TF Card Slot Switch/Reset Button...

  • Page 5: Setup The System

    TV monitor. If you connect the NVR with monitor shows Hiseeu logo or shows black, normally it is your monitor resolution is lower than the monitor. You can press the left side of the mouse for 30s, then it will reboot.
  • Page 6 When you turn on the NVR box, the monitor will get below interface: Setup Wizard→Down→General setup→Next→wireless setup→Next→Fast network→Next→Format the hard drive→Next...
  • Page 7 (if you forget the password, pls find the solution on the FAQ page) http://www.hiseeu.com/news/wirelessskitfaq/46.html Tips: To protect your privacy, please set your password at earliest convenience(don’t set the password over 8 characters). Right click the mouse→System Setup→System Admin→User to set password.
  • Page 8 Once you power up, repeat the steps outlined as above. Cloud status must be ONLINE and Network Status must be Healthy Network. If this does not happen, you will not be able to view remotely. Installation Instruction Of WiFi NVR Kit Note: The NVR can work with the router by wireless connection and wired connection Wired connection: when your NVR connect by RJ45 to your router, it will get network settings...
  • Page 9 How To Setup The Record Video Plan? There are 3 modes for reocrd. Time Recording: Setup period of time of recording on NVR GUI.Right click mouse→System Setup→ Record setup→Record Plan. Click “time”and put mouse icon on the upper left corner(for example“1” as picture shows), press and drag the mouse to the right to choose the time.The list will turn to red.
  • Page 10 VIDEO PLAYBACK Steps:right clik mouse in main menu→Video playback→choose date, channel, record mode→click search→then can view playback file. (IE browser can’t check the playback directly, so you can use the Eseecloud software on computer or check on your phone app Eseecloud) Warm prompt: IIIustration for playback button: play,...
  • Page 11 How To Backup The Video? Use U disk to copy video, so easy and convenient! 2 USB ports: Plug U flash disk into the USB port of NVR. Right click on main menu→Video backup→choose backup channel→choose video mode→setup searching time→search→ choose recording file on the list→video backup (support 32G U flash disk at max.
  • Page 12 Input Cloud ID (Right click the mouse→fast network→Cloud ID) Input User Name and Password (If you doesn't change the user name and password, User Name is admin, no password) Windows system,please download Eseecloud software from www.hiseeu.com. Or download from this link: https://www.dropbox.com/s/o7z59qiret93hr9/EseeCloud%20for%20 Windows.rar?dl=0 : http://download.dvr163.com/tool/EseeCloud_Setup_3.0.5.6_20201109.rar...
  • Page 13 if you check in the local network,you can use the NVR IP address to add the system (Find the IP address on Fast network page or Network setting page) c)To View on IE browser You can also visit www.dvr163.com or www.e-seenet.com via IE browser to watch it. Change the language at the right top corner.
  • Page 14 4.4 or above, and if you still can't download, please log in to our official website link: http://www.hiseeu.com/news/wsk Click "+"→other ways to add/ scan the QR code on your fast network page→Network connected device→input Cloud ID and User name and password (user name and password is the same one you...
  • Page 15 Tips: if you’ve set a password on your NVR system, please update your password on APP to view. And if your camera loading for a long time and don’t show image, you can right click your NVR mouse and choose System Setup→Network setup, change the MTU to 1000. Playback On Mobiles In the Eseecloud APP, while viewing live video of the system, click Playback, you will enter the remote playback menu.
  • Page 16 Extend WiFi Range Wireless connection is easy and convenient, but it’s not universal application. Because of the character of WIFI, the WIFI signal will decrease when going through some obstacles. Some methods can be applied to bypass obstacles and extend WiFi range. Position The Antenna Correctly WIFI range is like an apple and the antenna of NVR is in the center of it.

  • Page 17: Repeater Setup

    Repeater Setup Step 1. Right click the NVR mouse, and choose "Video Manage"→then left click “Repeater” Step 2. Add repeater As picture shown below,click icon + besides channel 3, choose other channel. Step 3. As picture shown below, it means IPC1 is connected to NVR through IPC2 and IPC3. IPC2 is connected to NVR through IPC3.

  • Page 18: Delete Repeater

    Step 4. Click “Apply” and then click “refresh” to check if the setting is successful. Delete Repeater Move the mouse to targeted channels, left click to delete, and then click “Apply” and “OK”. APPLICATION EXAMPLE Solar Camera Solar Camera As picture shown above, when IPCAM1 is put somewhere is out of NVR WIFI range, and there is IPCAM2 between them with strong WIFI signal, users can put IPCAM1 close to NVR and power it, setup IPCAM1 repeated by IPCAM2, and then install IPCAM1 to the presupposed place.

  • Page 19: Frequently Asked Questions

    3.5" SATA HDD or 2.5"SATA HDD,support 500GB to 6TB . Below are the installation steps of the hard drive (Or Email to johnny@hiseeu.com to get help) Unplug your NVR from power, unscrew and remove the top cover. Connect the SATA power and data cables from the NVR to the corresponding ports on your HDD.
  • Page 20 Q2: How can I troubleshoot camera issues? A: Check camera status is red light or blue light, only blue light which means camera work fine, if show red light, please check camera battery status, better charge it full. If still not work, please take camera close to NVR, delete the connect failed camera, and go to match code or wireless add page reset your camera for 6 seconds to add it again.
  • Page 21 Q5:How can I get motion notifications on my phone? A:First check the status of your Cloud ID is ONLINE and the Network Status indicates Healthy. Second, from the home screen of your monitor, right click the mouse, choose System setup→Channel Setup→Video detection.
  • Page 22 After you have finished setting your preferred channel as outlined above, repeat the process for your remaining preferred channels.Starting from the home screen of your monitor, right click the mouse, navigate to System setup→Channel Setup→Video detection. Next, select Copy to and either select the All option for all cameras, or you can select the specific channel(s) you prefer.
  • Page 23 After you have entered all of your information, click Test until the Test success message appears on the screen. Please allow a few minutes for the testing cycle to complete. If the test failed, try another Email account. Click Ok. Whether or not your test was successful, be sure to click Ok to save your settings.
  • Page 24 You can refer to this youtube video:https://youtu.be/KJpJnYFlGK8 If still can’t work, pls take below photo to our email: Johnny@hiseeu.com to get super password Q12: Purchase repeater to enhance camera signal If the camera is set as WiFi repeater and the antenna is replaced, the problem of weak signal still cannot be solved, you can buy a dedicated WiFi repeater to extend the wireless signal transmission distance of the camera.
  • Page 25 Setup WIFI Reapter ①Press the reset button on the repeater for 10 seconds ②Use an Ethernet cable connect the reapter to NVR ③Video manage→Search→Auto add→Yes→Yes Reset Button ④Add the camera you want to add after the repeater Q13: What's the meaning of IRON on the TV/PC monitor? Picture IRON Location...
  • Page 26 Q14:What should I do if the NVR always appear Offline? Pls Connect NVR to your router with an Ethernet cable.After that right click the mouse→Fast network. If Step 1 doesn't work, Pls check the Ethenet cable is broken or not If there is no problem with the cable.
  • Page 27 Step 3: If the auto config still can't make it work, pls kindly check the same network computer network setting Then "manual configuration" set the recorder network settings, don't choose DHCP, input the same IP address and gateway and submask same as your computer. Check computer network parmeters on the same router that can access the internet(Gateway, subnet mask, preferred DNS and computer network...
  • Page 28 Set the area of motion detection to be set within the field of view of the camera. App Alarm a)Select App Alarm on NVR b)Click "My center"→Settings→enable Push notification→prviacy setting→turn on Notification permission Q16: How to setup factory setting? A: Right click the mouse→System setup→System admin→factory setting→simple restore.
  • Page 29 How to find answers to these questions on the website? Please open the link: http://www.hiseeu.com/news/wirelessskitfaq How can I get product and technical support? US Toll Free:1-917-338-1084 (Available Pacific Time 5:00pm -12:00pm) Amazon Email:johnny@hiseeu.com WeChat ID: +86 13590254421 Skype ID: johnny.chen1204 Website: www.hiseeu.com Whatsapp :+8613392810296...
  • Page 30 Shenzhen Hiseeu Technology Co., Ltd How can I get product and technical support? US Toll Free:1-917-338-1084 (Available Pacific Time 5:00pm -12:00pm) Amazon Email:johnny@hiseeu.com Skype ID: johnny.chen1204 Website: www.hiseeu.com Official Website Whatsapp :+8613392810296 www.hiseeu.com...
