Summary of Contents for Hiseeu WKIT-4HB612-1T
- Page 1 A007-V3.0 Wireless Ba�ery Security Camera System USER MANUAL Suitable for Hiseeu Wireless Ba�ery Camera System ※Please read the Quick Guide carefully before using the product and keep it properly.
- Page 2 APP, and reset your NVR password, before sending it back to Amazon. lt will erase your personal information (footage, email, etc.) On behalf of all colleagues in Hiseeu, we sincerely appreciate your trust and support. Please let us know if there is anything we can do to assist you further.
- Page 3 Thanks for purchasing Hiseeu wireless camera system, Hiseeu expandablewireless NVR support connec�ng with 8 pieces cameras. Hiseeu WiFi Camera Systems: Model: WKIT-4HB612-1T Model: WK-4HB312-1T Model: WK-12V-4HB612-3T Asin: B07719HQQS Asin: B07QM5996S Asin: B07T8ZDTTP Model: WK-10V-4HB612-1T Model: WK-4HBC23-1T Model: WK-4HD203-1T Asin: B07F32X3XZ...
- Page 4 Compa�ble with Below Cameras: 1. Indoor camera 2. Dome camera Model: FJ2C Model: TZ-HC913 Asin: B086L7ZYQV Asin: BO8HRPQMY3 3. PTZ camera Model: WHD303 Model: WHD602Z(5X Op�cal) Model: AMZ-WHD902A Asin: B08JYMYPCM Asin: B08RHM6VF2 Asin: B081PRVDJ3 Model: WHD203 Model: WHD103Z(30X Op�cal) Model: TZ-HBK13 Asin: B097CW41XJ Asin: B094JF5HHF Asin: B08PY58W2M...
- Page 5 Model: C80 Model: WTDA03 Asin: B096XPT915 Asin: B09TGPFNMN 5. Bullet camera Model: TZ-HB612 Model: TZ-HB612B Model: TZ-HB312 Asin: B07JQZQRVG Asin: BO7K1CZN1L Asin: BO7FVSK6BY Model: TZ-HB412B Asin: B08DKX3WYL Accessories for System Work: Model: 1TB-HDD Model: 3TB-HDD Model: 12V 2A-US Asin: B07DW4YGYM Asin: B07L3MKQBC Asin: B07GP1DX4N -03-...
-
Page 6: Table Of Contents
Contents Statement ..........................05 Safety Cau�on........................05 Out of Box Audit ........................05 All Products & Parts ......................06 NVR............................. 06 Ba�ery Cameras......................... 07 Installa�on Instruc�on of WiFi NVR KIT ................08 Setup the System ......................... 09 Main Menu ........................... 13 Connect the System with Network by WiFi or Wired ............ -
Page 7: Statement
The quick user guide will introduce most of the func�on of the system. This user guide may contain inaccurate content due to hardware and so�ware upgrade. For latest user manual, please email johnny@hiseeu.com to get it. Safety Cau�on Please do not put any fluid container on the product. -
Page 8: All Products & Parts
Screw bag (for Camera)×2/3/4 Network Cable×1 Screw bag (4 screws for HDD)×1 All Products & Parts This product may require cabling , we suggest to test all products & parts before installa�on and cabling. CAUTION WARAING:TO PREVENT FIRE OR SHOCKHAZARD,DO NOT EXPOSE UNITSNOT SPECIFICALLY DESIGNED FOR OUTDOOR USE TO RAIN OR MOISTURE 1. -
Page 9: Ba�Ery Cameras
Ba�ery Cameras Model 1 Indicator Light Power Bu�on Reset Bu�on USB Port Model 2 Reset Bu�on/ USB Port Power Bu�on Indicator Light Ba�ery Camera LED Light Instruc�ons: Blue light + red light always on: (Privacy light) Remotely previewing the camera Blue light on for 1 second: The device is on or awake The blue light keeps flashing: Upgrading Red light flashes 3 �mes quickly: Shutdown... -
Page 10: Installa�On Instruc�On Of Wifi Nvr Kit
Key Opera�on： Long press Power Bu�on for 2s in the shutdown state: Turn on/off Model 1 (blue light on for 1s) Long press Reset Bu�on for 2-3s: Turn on Model 2 (blue light on for 1s) Short press Reset Bu�on 3 �mes con�nuously: Shut down Model 2 (red light flashes 3 �mes quickly) Long press Reset Bu�on for 8s: Reset into pairing state (Red light flashes) -
Page 11: Setup The System
Setup the System HDMI Cable Network Cable Ba�ery Camera Power Router Mouse This system is standalone with embedded Linux Opera�ng System in the NVR. Just like a desktop PC, need to hook a screen to the NVR to enter the OS. Any TV, monitor with VGA or HDMI input should work for it. - Page 12 If you connect the NVR with monitor shows Hiseeu logo or shows black, normally it is your monitor resolu�on is lower than the monitor. You can press the le� side of the mouse for 30s, then it will reboot. If s�ll can't work, pls change a monitor, thanks.
- Page 13 Wireless Channel: according to your country policy choose correct one. Region: US(FCC), EU(EU), Asia(MKK). -11-...
- Page 14 Click Yes, Next. Cloud ID: online which means your NVR connect with network successfully, Offline or network busy which means network doesn’t connect. Network Status: Healthy network: means no problem of network. Gateway Unreachable: means NVR IP gateway and IP address not the same as your router, Click Manual Config, then find your router correct gateway, such as 192.168.1.1, then IP address should be 192.168.1.*** which can’t be the same as your router, change it on NVR.
-
Page 15: Main Menu
Storage Manage: show the HDD informa�on and Capacity, first �me to use please format the HDD at first, if your system not included HDD it should be blank. Click Next to finish fast setup. Main Menu Right click the mouse choose any op�on to login the system, default user name is admin and no password, just click ok. - Page 16 If it shows Username/Password is Incorrect! There are 2 ways to reset the password: 1: Click ok you will see Cloud ID and the Date, then send below johnny@hiseeu.com photo to to get the super password. 2: on below frame quickly click the mouse: right-le�-right-le�-right-le�-right-le�-right-le�-right-le�...
-
Page 17: Connect The System With Network By Wifi Or Wired
Connect the System with Network by WiFi or Wired Right click the mouse of the NVR, choose Fast Network. In the middle of the window you should see Cloud ID status as ONLINE and Network Status as Healthy Network. If not show online and healthy network, select Manual Config then enable DHCP, Click Apply , then power off... - Page 18 There are two ways to connect the NVR with network: 1. Wired connec�on 1) Wired connec�on, connect the NVR with router by ethernet cable. 2)Rright click your NVR mouse choose fast network, then click Auto Config, check cloud ID status is online and network is healthy, then can remotely check the system on your phone app.
-
Page 19: Menu-Do What
2. WiFi connec�on 1) Please notes our NVR only can work with 2.4Ghz WiFi network. 2) Right click your NVR mouse choose system setup → network setup → wireless internet → enable wireless LAN, then find your house WiFi name, input password, apply it. (please note the WiFi name can not included any special character, such as "_", otherwise it will show connected failed.）... -
Page 20: Split Screen
Split Screen Video Manage Search: wired connec�on camera with NVR to find new IP address or connect by Onvif protocol to find the camera IP address Match Code: wired connec�on transfer to WiFi connec�on with NVR Add One: add the camera IP address directly to your channel -18-... - Page 21 Modify IP: change the camera IP address when it show the same IP address with other cameras Advanced: allow to repeated to add the camera in more than 2 channels. Delete: delete the camera from NVR Delete All: delete all cameras on the NVR Manual Edit IP address: change camera IP address Password: when it shows Password Error to input correct camera...
-
Page 22: System Setup
System Setup Click right mouse → Choose System Setup; enter the menu that enable you to do all se�ngs related to this system. General setup Language: support English, Chinese, Japanese, Spanish, Portuguese, German, French and so on, choose the correct one. Display Resolu�on: refer your monitor choose correct resolu�on. -
Page 23: Time Setup
Time Setup Date Format: select the one you like. Sync Time: system connect the network will automa�cally use your local �me. Time Zone: find your city �me zone to input correct one. Time Format: allow you choose 12h format and 24h format. If you don’t know it, please disable Sync Time, set the Date �me same as your phone. -
Page 24: Error
Overwrite: when HDD full it will automa�cally delete old file and make new record Format: the first �me to use please format the HDD, it will delete all record on your NVR Please notes: if there is no any HDD informa�on, please make sure the system you bought with HDD, and NVR power adapter output is 12V2A or 12V3A. -
Page 25: Network Setup
Mo�on: select it to make mo�on detec�on record if you select 24/7 days will show all green line. Copy To: Copy recording se�ng to other cameras. Select All: will select 24/7 days. Reset: clear all se�ng on record. Alarm recording is useless, please ignore it. Network Setup -23-... - Page 26 DHCP: adap�ve local network. IP address: NVR IP address(according to your router change to the same, the first 3 number should be the same, the last can’t be same, otherwise it will show IPC conflict). Subnet Mask: 255.255.255.0, no need change. Gateway: use router Gateway.
-
Page 27: E-Mail
Network Service: Enable RTSP Server: rtsp://user:password@ipaddr:port/chN_M.264. User: The user name defaults to admin. Password: The password is empty by default. Ipaddr: IP address of the device. Port: 80 or 554. N is the channel number: IPC is 0, 4 NVR is 0~3, 8 NVR is 0~7, and so M is the code stream number: the main code stream is 0, and the secondary code stream is 1. - Page 28 Gmail s�ll need login www.google.com to turn on Less secure app access. E-Mail Func�on: enable it to set email. SMTP Provider: according to your email select correct provider. Sender: email address which to receive the no�fica�on. Password: sender email password (some email enable SMTP service will generate a password, please input this password).
-
Page 29: Wireless Setup
Port: according to your se�ng select correct one(refer this link to find which one is correct: h�ps://www.arclab.com/en/kb/email/ list -of-smtp - and-imap-servers-mailserver-list.html). Encryp�on Type: SSL. Sendee 1/2: allow use the same sender email address . Subject: Email subject to receive email. Interval: 30s. -
Page 30: Wireless Internet
Wireless Internet Wireless LAN: enable it to connect the NVR with WiFi network(doesn’t support 5Ghz WiFi network). WiFi Name: on the right find your home WiFi name select it(please note the WiFi name be�er without any special characters, such as “-”). Password: input home WiFi password. -
Page 31: Channel Setup
Channel Setup Encode Setup Encode Mode: AV stream(turn on camera audio func�on), Video only (turn off audio func�on of cameras). Resolu�on: allow you change camera resolu�on. Other func�ons doesn’t allow to change. Channel OSD -29-... -
Page 32: Video Detec�On
Light&Color: allow to change camera Brightness, Satura�on, Contrast, Sharpness, not suggest to change. Ircut mode: Infrared mode: camera show color image at day�me, blank and white at night. Daylight: turn off Infrared light, only show color image, at night if no light it can’t be seen clearly. - Page 33 Detec�on: Mo�on: set mo�on detec�on. Video loss: camera not connect with NVR. Video Cover: set a privacy area on camera, it will show a white frame on live stream. Sensi�vity: get many mo�on detec�on no�fica�on select lowest, less mo�on detec�on no�fica�on select higher. Humanoid Tracking: ba�ery camera not support this func�on.
-
Page 34: Ipc Upgrade
IPC Upgrade Camera working without any problem, don’t suggest to upgrade the camera. If any problem please take this photo and email Johnny@hiseeu.com to get the firmware. How to upgrade the camera? Please firmware copy to USB DISK root( format should be FAT32), select the correct channel →... -
Page 35: Bitrate
Bitrate Show camera working speed. System Admin System Version Device model: K8208-3WS S/W version: 3.2.0.0M -33-... -
Page 36: System Log
System Log To see the opera�on of the NVR, HDD and camera working status. User Add User: add a new user, default user admin can’t be changed Delete User: delete the new user you set Edit User: to set the permission of the user -34-... - Page 37 Set Password: change the NVR password. New password: don’t set it over 12 characters and without any special characters . Repeated: the same as your new password. -35-...
-
Page 38: System Upgrade
System Upgrade Local Upgrade: system not connect with network need to upgrade, please take a photo of the System version to johnny@hiseeu.com get firmware How to upgrade the system by Local Upgrade? 1. Copy the file named FWHI*****.rom that sent to you, and copy it to the root of the u disk (the place where the u disk is opened). -
Page 39: System Maintenance
System Maintenance Auto reboot: allow Everyday, Everyweek, Everymonth to reboot the NVR, all cameras if lost connec�on with NVR at the same �me, please set system auto reboot func�on. Factory Se�ng Simple Restore: Reten�on channel, network and user setup. -37-... -
Page 40: Video Playback
Video Playback Warm prompt: Time record show red line, Mo�on record show green line. Playback bu�on: play, pause, fast forward*2,*4,*8. File Playback: Choose the recording file in file list, as number “1” shown in picture. Choose one of the recording, click “play” to play to recording file. -
Page 41: Video Backup
Video Backup USB Format should be FAT32, search the playback and select the one you want to make backup, suggest backup one file by one file it will take a lot of �me to make backup. If you need check the playback on computer, please use VLC player, you can download windows so�ware here: h�p://download.dvr163.com/tool/Video-player%20.zip, MAC OS system please google VLC player to download. -
Page 42: Exit System
Exit System Logout: logout user. Reboot: restart the NVR. Shutdown: turn off the NVR, then unplug the power adapter. View System on Phone EseeCloud APP and Computer EseeCloud So�ware To View on Phone APP Download Free App EseeCloud Search free APP “EseeCloud” in APP store or Google play. The phone App will be updated some�mes, if your phone App menu is different from the menu in user manual, please contact us to get the latest user manual. -
Page 43: Register Account
Register Account Go to login interface, click "Register". Register with your phone number or email address, click "Confirm". Manually press and hold the tennis ball, drag it to the red dot, and then drag it to the tennis racket to go to the next step. You’ll receive a verifica�on code, input the verifica�on code and set up your own password, then click "Confirm"... -
Page 44: Add System To Phone App
Add system to phone APP Before add the system please set the password for your NVR: right click NVR mouse choose system setup → system admin → User → set password. Click Add camera → Other ways to add → Add by ID/IP → input NVR Cloud ID →... -
Page 45: Func�On On App
Func�on on APP Cloud Service Click “ ”icon to buy cloud storage, NVR with HDD no need to buy cloud storage. Cloud storage only support buy one channel by one channel. -43-... -
Page 46: News
News Check mo�on detec�on message and photo, click the photo → View Video → Full video to see 30s mo�on playback. Please notes if no playback on NVR monitor, it will show no video. Make sure NVR set recording func�on. Share -44-... -
Page 47: Playback
Click ” ” icon to share the device to your family members. Share Permissions: set the permissions allow others to check. QR code validity period: QR code valid �me to add the device on other phone. A�er all setup, click Complete to generate the QR code, others’ phone need register a new account of EseeCloud APP, scan this QR code to add Playback Click “... -
Page 48: Livestream Interface
Livestream Interface 1. SD & HD Switch: switch the camera from SD mode to HD mode, due to service not supported always in HD mode, each �me when preview camera need change it manually 2. Split view: view by x1, x4, x6, x8 cameras 3. -
Page 49: Se�Ngs
10. Frequently Viewed Loca�on: ba�ery camera doesn’t support this func�on. 11. More: Detect alarm: turn on/off mo�on detec�on alarm message. Photo album: check manual record and photo capture file. PTZ adjustment: C40 camera is not a PTZ camera, this func�on is useless. Siren: camera prompt sound when mo�on detec�on happened. -
Page 50: Zoom And Focus Bo�On
Zoom and Focus Bo�on Ba�ery camera doesn’t support this func�on. To View on MAC and Windows Computer Please email johnny@hiseeu.com to get the so�ware download. Select English to install the so�ware. Login with phone EseeCloud account(email or phone number and password). - Page 51 Select icon to see camera live stream on computer. Click icon to see the playback. Click allow to change the view channel from 1-64. Click icon to see EseeCloud so�ware version and mo�on detec�on message . -49-...
-
Page 52: Frequently Asked Ques�Ons
Frequently Asked Ques�ons Q1: How can l troubleshoot camera issues: IPC disconnected / Connect failed? A: 1. Check camera is power on or not, you can see the indicator on camera len, if no any indicator, please power camera about 8 hours and check again, or turn off... - Page 53 Q3: Connected the system with monitor, why nothing is showing here? A: Default output resolu�on of the NVR is 1280*1024, which may not be compa�ble with some monitor screens. There are a few op�ons you can try to fix it: 1.
- Page 54 3.5" SATA HDD or 2.5" SATA HDD, support 500GB to 4TB . Below are the installa�on steps of the hard drive ( Or Email to johnny@hiseeu.com to get help) Unplug your NVR from power, unscrew and remove the top cover.
- Page 55 3) Holding the hard drive and the NVR, gently turn it over and line up the holes on the hard drive with the holes on the NVR. Using a screwdriver screw the provided screws into the holes and assemble the cover. Note: New HDD should be forma�ed before recording.
- Page 56 2. Check the power adapter connected to the NVR box. The NVR box uses 12V 2A or 12V3A power supply. Connect the 12V 1A power supply to the NVR, the NVR box will not have enough power to drive the hard drive.
- Page 57 Q6: How to receive no�fica�on alarm message on cellphone? A: 1. Right click the mouse → System setup → Channel Setup → Video detec�on → Selec�ng the Channel for Mo�on Detec�on → enable APP Alarm, a�er set it up, click Copy to to set to all channel. -55-...
- Page 58 2. Set Area Edit, default all selected show Blue Color, support narrow the mo�on detec�on area to decrease mo�on detec�on message. 3. Set the Arming Time, default 24/7 days show Orange color. -56-...
- Page 59 4. Enable App Alarm. Click Me → Se�ngs → enable Push no�fica�on. Click System authority se�ngs, turn on all permission of the app. -57-...
- Page 60 Q7: Night image mode doesn’t work correctly? A: Click the mouse to select the screen → click Color Adjust. Select Ircut mode → change to Infrared mode. Q8: How to adjust camera channel posi�on? A: Select the camera , adjust the icon to move camera channel up and down.
- Page 61 User name and password should be within 7-10 characters and should not contain such as &*I@(...#% and other special characters) Reset password video: h�ps://youtu.be/KJpJnYFlGK8 If s�ll can’t work, please take below photo to our email : Johnny@hiseeu.com to get super password. -59-...
- Page 62 Q10: How to do if camera lost signal with NVR? A: 1. Please check if the antenna on the camera is parallel . change the wireless channel and region of the camera system, and the antenna of NVR is be�er to stand up. change region to FCC, wireless channel change to 1,6,11 to check.
- Page 63 Q12: What should I do if the NVR always appear Offline? A: Please Connect NVR to your router with an Ethernet cable. A�er that right click the mouse → Fast network. If Step 1 doesn't work, please check the Ethenet cable is broken or not If there is no problem with the cable.
- Page 64 Step 3: If the auto config s�ll can't make it work, pls kindly check the same network computer network se�ng. Then "manual configura�on" set the recorder network se�ngs, don't choose DHCP, input the same IP address and gateway and submask same as your computer. -62-...
- Page 65 first three se�ngs of the IP address are the same, the last paragraph should not berepeater), if s�ll can’t work, can change DNS to 8.8.8.8 or 114.114.114.114. Q13: How to find hiseeu website? A: Input link: h�p://www.hiseeu.com. -63-...
- Page 66 How can I get product and technical support? Website: www.hiseeu.com Amazon - US Toll Free: 1-917-338-1084 (Available Pacific Time 5:00pm-12:00pm) - Email: Johnny@hiseeu.com (For US) Jason@hiseeu.com (For UK & EU) - Skype ID: johnny.chen1204 - WeChat/Whatsapp: +8613392810296 Aliexpress - Email: support@hiseeu.com...
Need help?
Do you have a question about the WKIT-4HB612-1T and is the answer not in the manual?
Questions and answers
Как удалить все записи с жесткого диска?
To delete all recordings from the Hiseeu WKIT-4HB612-1T hard drive, follow these steps:
1. Right-click the NVR mouse.
2. Go to System Setup → General Setup → HDD Setup.
3. Click "Format" to format the HDD.
This will erase all recordings on the hard drive.
This answer is automatically generated
Can not get a password to work. Always "password incorrect"
There are two ways to reset the password for the Hiseeu WKIT-4HB612-1T:
1. Request a Super Password
- Click "OK" on the incorrect password message.
- A screen will show the Cloud ID and Date.
- Take a photo of this screen and send it to johnny@hiseeu.com to receive a super password.
2. Restore Default User
- On the password entry screen, quickly click the mouse in the following sequence:
Right-Left-Right-Left-Right-Left-Right-Left-Right-Left-Right-Left (about 12 times).
- A prompt will appear: "Restore default user. Are You Sure To Continue?"
- Click "Yes" to proceed.
- A new interface will appear to set a new password.
- Enter and confirm a new password, ensuring it is no longer than 12 characters and does not include special characters like "_".
This answer is automatically generated
