1. INTRODUCTION PRODUCT OVERVIEW GB-75 and GB-152 are gas boosters with control kits intended to be used to provide a very high pressure gas supply to systems using a GPC1 High Pressure Gas Controller and other high gas pressure test and calibration systems. -
Page 8: Location And Description Of The Components
GB-75™ AND GB-152™ OPERATION AND MAINTENANCE MANUAL LOCATION AND DESCRIPTION OF THE COMPONENTS 1.2.1 GAS BOOSTER 1. High Pressure Instrument Gas Filter 2. High Pressure Instrument Gas Supply Port 3. Drive Air Supply Port (from Drive Air Control Kit) 4. Breather Port 5. -
Page 9: Drive Air Control Kit
1. Drive Air Supply Connection (not visible) 2. Drive Pressure Adjust Regulator 3. Drive Pressure Indication Gauge 4. Drive Air Shut Off Valve 5. Drive Air Out Connection, to Booster (not visible) Figure 2. Drive Air Control Kit Page 3 ©1998-2008 DH Instruments, a Fluke Company... -
Page 10: Figure 3. System Schematic
GB-75™ AND GB-152™ OPERATION AND MAINTENANCE MANUAL 1. Drive Air Regulator 5. High Pressure Outlet Port 2. Drive Air Gauge 6. Booster Pump 3. Drive Air Shutoff Valve 7. 1/4 in. PFA Tubing 4. High Pressure Instrument 8. Shop Drive Air Inlet Port Gas Supply Port Figure 3. -
Page 11: Specifications
0.15 to 1 MPa (20 to 150 psi) Pressure Supply Maximum high pressure output is drive air pressure Pressure Range: times 75 (GB-75) or 152 (GB-152) 2 to 20 MPa (300 to 3 000 psi) High Pressure Supply Gas: Maximum high pressure output is high pressure supply... - Page 12 GB-75™ AND GB-152™ OPERATION AND MAINTENANCE MANUAL ©1998-2008 DH Instruments, a Fluke Company Page 6...
-
Page 13: I N S T A L L A T I On
2. INSTALLATION UNPACKING AND INSPECTION GB-75 and GB-152 are delivered enclosed in plastic film and secured by foam in place in a corrugated box. The Drive Air Control Kit and Interconnections Kit are included in the same box. Remove all parts from the shipping box and plastic bag. Be sure not to lose or discard the Drive Air Control Kit and Interconnections Kit. -
Page 14: Site Requirements
The drive air supply provides power to operate the booster. The booster’s very high pressure output is the drive air multiplied by either 75 (BG-75) or 152 (GB-152). This supply is usually “shop” or “factory” air. Drive air requirements are:... -
Page 15: High Pressure Instrument Gas
Point of use of output pressures; • Noise levels. The booster operation is noisy; • Vibration during use; • Access to the unit for operation of the regulators and valve; • Vents to atmosphere. Page 9 ©1998-2008 DH Instruments, a Fluke Company... -
Page 16: Installation
GB-75™ AND GB-152™ OPERATION AND MAINTENANCE MANUAL 2.3.2 INSTALLATION The installation of the gas booster system is broken down into four parts: • Installation of the gas booster (see Section 2.3.2.1) • Installation and connection of the Drive Air Control Kit (see Section 2.3.2.2) •... -
Page 17: Booster High Pressure Instrument Gas Suppply Connection
Depending on the drive pressure set by the DRIVE ADJUST regulator, GB-75 may generate pressure over 70 MPa (10 000 psi) and GB-152 may generate pressure over 110 MPa (16 000 psi). Be sure to use fittings and tubing rated for the pressure that is to be output from the booster. -
Page 18: Initial Start Up
(75 for GB-75, 152 for GB-152). For example, if the desired high pressure output of a GB-152 is 70 MPa (10 000 psi), set the drive air pressure to 70 MPa/152 = 460 kPa (67 psi). Remember that when the SHUTOFF valve is in the ON position, the booster will operate until the high pressure output is equal to the drive air setting times the booster ratio. -
Page 19: O P E R A T I O
DRIVE ADJUST regulator and the regulator is set to at least 140 kPa (20 psig). Operation is continuous until the outlet pressure is 75 (GB-75) or 152 (GB-152) times the shop drive air pressure. At this point, the opposing forces within the pump reach equilibrium and the pump stalls. For example, using a GB-75 with the drive air pressure set to 500 kPa (73 psig), the pump will run until the high pressure output reaches 75 x 0.5 = 37.5 MPa (5 450 psig). -
Page 20: Setting The Booster Output Pressure
(75 for GB-75, 152 for GB-152). For example, if the desired high pressure output of a GB-152 is 70 MPa (10 000 psi), set the drive air pressure to 70 MPa/152 = 460 kPa (67 psi). Remember that when the SHUTOFF valve is in the ON position, the booster will operate until the high pressure output is equal to the drive air setting times the booster ratio. -
Page 21: M A I N T E N A N C E A N D A D J U S T M E N T
4. MAINTENANCE AND ADJUSTMENTS MAINTENANCE GB-75 and GB-152 gas booster packages require no standard maintenance or adjustments. Page 15 ©1998-2008 DH Instruments, a Fluke Company... - Page 22 GB-75™ AND GB-152™ OPERATION AND MAINTENANCE MANUAL ©1998-2008 DH Instruments, a Fluke Company Page 16...
-
Page 23: T R O U B L E S H O O T I N
A stalled state will occur when the pressure in the high pressure section of the booster is equal to the pressure in the low pressure section times the ratio (75:1 or 152:1). A stall can only occur if the high pressure circuit is plugged. Page 17 ©1998-2008 DH Instruments, a Fluke Company... -
Page 24: Booster Runs Too Slowly
GB-75™ AND GB-152™ OPERATION AND MAINTENANCE MANUAL BOOSTER RUNS TOO SLOWLY A slow running booster means that the pump itself is running slowly which also causes the pressure to be generated slowly. • Check that the drive air SHUTOFF valve is in the ON position. If not, set the valve fully to the ON position. -
Page 25: Booster Runs (Cycles) Continuously
If the shop drive air supply pressure is above 500 kPa (75 psig) for GB-75 or 250 kPa (40 psig) for GB-152, adjust to below this limit. If the booster stops running, increase high pressure supply to IN port instrument gas supply and try again. -
Page 26: Leaks
GB-75™ AND GB-152™ OPERATION AND MAINTENANCE MANUAL LEAKS Pressure leaks are the most common problem found in pressure handling equipment. Normally, the first step is to determine if the leak is within the booster or outside of the unit. •... -
Page 27: W A R R A N T Y S T A T E M E N
6. WARRANTY STATEMENT WARRANTY STATEMENT Except to the extent limited or otherwise provided herein, DH Instruments, a Fluke Company (DHI) warrants for one year from purchase, each new product sold by it or one of its authorized distributors, only against defects in workmanship and/or materials under normal service and use. Products which have been changed or altered in any manner from their original design, or which are improperly or defectively installed, serviced or used are not covered by this warranty. - Page 28 GB-75™ AND GB-152™ OPERATION AND MAINTENANCE MANUAL ©1998-2008 DH Instruments, a Fluke Company Page 22...
