WaterSentinel WSS-1 Installation & Quick Start Manual

Installation Quick Start Guide for WSS-1
1
Locate existing filter and remove it by turning it
counter clockwise as shown in the graphic.
2
Holding new filter in your hands, carefully remove the
packaging and sanitary end-cap from the new filter.
3
Locate the Start arrow found at the top of the
instruction label on the back side of the filter. Align the
Start arrow with the arrow on the refrigerator filter
head.
4
Apply slight upward pressure and rotate the filter
clockwise until the Stop arrow on the front of the filter
label is aligned with the arrow on the refrigerator filter
head. Ensure filter is fully installed in refrigerator head
a full 1/4 turn. This is required to activate the internal
valve inside the refrigerator. If the filter is not turned a
full 1/4 turn the valve will not fully open and may
cause the water flow to be slow, or even cause the
valve to make a chattering noise during use.
Important Installation Instructions
