Guide to Intel Matrix Storage Manager
1. Enter Intel Matrix Storage Manager
RAID driver is built in Intel ALL in one driver provided in our support
CD. After you finish the driver installation, you can create, delete, or
rebuild any RAID array. Please enter Intel Matrix Storage Manager by
clicking on Start
All Programs
Intel(R) Matrix Storage
Manager
Intel Matrix Storage Console.
Then, the below screen appears.
Intel(R) Matrix Storage Console
1
Advertisement
Table of Contents
Related Manuals for ASROCK 4Core1600P35-WiFi
Summary of Contents for ASROCK 4Core1600P35-WiFi
- Page 1 Guide to Intel Matrix Storage Manager 1. Enter Intel Matrix Storage Manager RAID driver is built in Intel ALL in one driver provided in our support CD. After you finish the driver installation, you can create, delete, or rebuild any RAID array. Please enter Intel Matrix Storage Manager by clicking on Start All Programs Intel(R) Matrix Storage...
-
Page 2: Create Raid Volume
2. Create RAID Volume Select Action Create RAID Volume from Existing Hard Drive to create a RAID volume. Intel(R) Matrix Storage Console Then, Create RAID Volume from Existing Hard Drive Wizard pops up. Please click Next to continue. - Page 3 To configure a new RAID volume, you need to key-in the Volume Name with 1-16 letters, select the RAID Level, and then set the Strip Size between 4KB and 128KB. The most typical strip size settings are: 4KB: For specialized usage models requiring 4KB strips 8KB: For specialized usage models requiring 8KB strips 16KB: Best for sequential transfers 32KB: Good for sequential transfers...
- Page 4 Then you have to select the member disk. Please click the “ ” arrow to move the member disk that you plan to use to the Selected field, and then click Next to continue. Since the existing data on the selected hard disk drive will be deleted, do not forget to back up your data before continuing.
- Page 5 Specify the Volume Size. Specify the amount of available array space to be used by the new RAID volume. You may enter the amount in the space or use the slider to specify. It is recommended you use 100% of the available space for the optimized usage.
- Page 6 Start Creating RAID Volume from Existing Hard Drive Wizard. Please note that as long as you click Finish, the existing data on the selected hard drive will be deleted and this operation cannot be undone. It is critical that you backup all important data before this step. Then, the migration process starts, which may take up to two hours to complete depending on the size of the disks being used and the strip size selected.
- Page 7 After the migration process is completed, the below screen appears. Then you have to reboot your system to use the full capacity of the new volume.
- Page 8 IRRT (Intel Rapid Recover Technology) Intel Rapid Recover Technology is a feature of Intel Matrix Storage Manager. It uses RAID 1 (mirroring) functionality to copy data from a designated master drive to a designated recovery drive. The master drive data can be copied to the recovery drive either continuously or on request.
