Sonance VISUAL PERFORMANCE Series Installation Manual

I N S T A L L A T I O N M A N U A L
V I S U A L P E R F O R M A N C E
L A R G E
R E C T A N G L E S P E A K E R S
Introduction
Thank you for purchasing Sonance Visual Per formance
Series Large rectangle speakers. When properly installed your
new speakers will give you years of entertainment pleasure.
S W :
AFETY ARNING
T F
HESE SPEAKERS HAVE AST
SPEAKER FROM FALLING OUT OF THE MOUNTING HOLE DURING THE
.
INSTALLATION PROCESS
T F
HE EDGES OF THE AST
U
SE CAUTION WHEN HANDLING THE SPEAKER
Box Contents
Each Sonance Visual Performance Series Large rectangle speaker
box contains (2) Visual Performance Series Large rectangle
speakers, (2) paint plugs (installed on the fronts of the speakers),
(2) paintable grilles and (1) mounting cut-out template.
Speaker Placement
Home Theater Speaker Placement
Left, Center & Right Speakers
• Place the left & right speakers on either side of the video
screen, 6 – 10 feet (1.8m – 3m) apart and 3 – 4 feet (0.9m –
1.2m) from the floor.
• If possible, locate the center speaker at the same height as the
left & right channel speakers.
• If you must place the center speaker above or below a video
screen, place it no more than 2 feet (0.6m) above or below the
center of the left and right speakers. This will maintain consis-
tent tonality between all three front channel speakers.
• The main listening position should be 8 – 12 feet (2.4m –
3.7m) away from the speakers.
Use Figure 1 as a guide.
18"
(0.5m)
From Side
Wall
2'
(0.6m)
max.
F 1: L , C
IGURE EFT
H T
OME HEATER
S E R I E S
®
M ®
OUNT TABS THAT PREVENT
M
OUNT TABS ARE VERY
.
6' – 10'
(1.8m – 3m)
Apart
(0.5m)
From Side
Wall
& R C
ENTER IGHT HANNEL
S P
PEAKER LACEMENT
Surround Speakers (5.1-Channel System)
Locate the surround channel speakers on the side walls 2 – 6 feet
®
(0.6m – 1.8m) behind the listening position, 5 – 7 feet
(1.5m – 2.1m) from the floor.
THE
.
SHARP
F 2: 5.1-C
IGURE
Use Figure 2 as a guide.
Surround Speakers (7.1-Channel System)
• L & R
EFT IGHT
surround speakers directly to the sides of the listening position,
5 – 7 feet (1.5m – 2.1m) from the floor.
• S B
URROUND
the rear wall, 3 – 6 feet (0.9m – 1.8m) apart and at 5 – 7 feet
(1.5m – 2.1m) from the floor.
Use Figure 3 as a guide.
Right
18"
Front
Speaker
Video
Screen
Center
Speaker
Left
Front
Speaker
F 3: 7.1-C
IGURE
2' – 6'
(0.6m – 1.8m)
5' – 7'
(1.5m – 2.1m)
H T
HANNEL OME HEATER
P
LACEMENT
S S : Place the left and right
URROUND PEAKERS
S : Place the surround back speakers in
ACK PEAKERS
Right Surround
Speaker
Left Surround
Speaker
H T
HANNEL OME HEATER
S S
URROUND PEAKER
Right
Surround Back
Speaker
Left
Surround Back
Speaker
S P
PEAKER LACEMENT
