Reiss RS-AE Series User Manual

1 channel amplifier
Hide thumbs Also See for RS-AE Series:

Advertisement

Quick Links

U S E R
M A N U A L
RS-AE SERİES
1 CHANNEL AMPLIFIER
Pl ea s e ca ref u l l y rea d th e u s e r m a nu a l.
Do n o t u se yo u r d ev i ce wit h out rea di ng .
Dear Customer,
First of all, we would like to thank you for choosing our REISS AUDIO
branded device, which is the pioneer of quality.
In order for your device, which has been produced in modern facili-
ties and has undergone rigorous quality control, to o er you the best
e
ciency,
Please read this entire manual carefully before using your device and
keep it as a reference.
w w w . r e i s s a u d i o . c o m . t r

Advertisement

loading
Need help?

Need help?

Do you have a question about the RS-AE Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Reiss RS-AE Series

  • Page 1 Do n o t u se yo u r d ev i ce wit h out rea di ng . Dear Customer, First of all, we would like to thank you for choosing our REISS AUDIO branded device, which is the pioneer of quality.
  • Page 2 U S E R M A N U A L RULES TO BE FOLLOWED IN MAINTENANCE, REPAIR AND USE ONLY AUTHORIZED TECHNICAL PERSONS CAN OPEN THE BACK COVER. THE WARRANTY OF THE DEVICE IS APPLICABLE TO DEVICES WITHOUT OPEN BACK COVER. TO AVOID FIRE HAZARD AND DANGEROUS SHOCK, DO NOT EXPOSE THE APPLIANCE TO MOISTURE OR RAIN.
  • Page 4 What’s Included Important Safety Considerations Important Installation Precautions...
  • Page 5 Important Installation Precautions Continued Mounting Placement...
  • Page 6 Side Panel Layout AE850.1D & AE1500.1D AE2500.1D...
  • Page 7 Side Panel Layout Continued Ground: recommends when making your chassis ground to use a Star Washer which will help prevent your ground bolt from loosening. Remote Input Terminal: If you are using the High-Level Speaker Outputs connection a remote input to your ampli e r.
  • Page 8 Side Panel Layout Continued 3. +12V olt Positive Terminal: Power Connection for Fuse Rating Connect to Fuse chassis ground Connect to Source unit’s of vehicle. Keep accessory lead or Less Grounds as short than 18” switched 12v source as possible Vehicle Battery...
  • Page 9 Side Panel Layout Continued Fuse Holder: Speaker Outputs: Visi t or talk to your Authorized Dealer to see a complete selection of premium installation accessory that wil l complement and enhance listening experience.
  • Page 10 Side Panel Layout Continued Low Level RCA Inputs: Low Level RCA Preouts: Input Voltage Selector: Turn On Mode Selector: Remote (+12Volt Remote Turn-On Lead): This Signal (Signal Sensing Circuit): This is an This circuit senses input from the Right Channel.
  • Page 11 Side Panel Layout Continued need to wire a remote input to the ampli er. This circuit senses input from the Right Channel. 10. Clipping Led Indicators: 11. Input Gain:...
  • Page 12 Side Panel Layout Continued Phase: Lo w Pass (LP) Filter Fr equency Filter : Infrasonic Filter: 15. Boost Eq:...
  • Page 13 Side Panel Layout Continued 16. Remote Level Control: 17. Sync Mode Selector Switch: will be no output.)
  • Page 14 Side Panel Layout Continued 18. Sync Connection Port: Common Installation Diagrams (Note if using the Sync Mode with bridged two same AE Mono 1-OHM 2-4 OHM Subwoofer (min) Subwoofer 1. A Single Voice Coil Subwoofer Speaker 2. Two Single Voice Coil Subwoofer Speakers (Note: Don’t connect speaker impediance under 1 ohm)
  • Page 15 Sync Mode Connection Diagram CAR RADIO HEAD UNIT RJ11 CABLE SWITCH POSITION SWITCH POSITION...
  • Page 16 Sync Mode Connection Diagram Continued Master Amp Slave Amp...
  • Page 17 www.reissaudio.com.tr...
  • Page 18 Specifica�ons AE850.1D AE1500.1D Specifica�ons AE850.1D AE1500.1D Channels Channels Rated RMS Power 4 Ohms Mono @ 14.4 Volts 500 Wa�s x 1 700 Wa�s x 1 Rated RMS Power 4 Ohms Mono @ 14.4 Volts 500 Wa�s x 1 700 Wa�s x 1 Rated RMS Power 2 Ohms Mono @ 14.4 Volts 850 Wa�s x 1 1000 Wa�s x 1...
  • Page 19 Troubleshooting Problem Solu�on 1. Check to see if Power, Remote and Ground is connected to the Amplifier. Amplifier does not work; no 2. Check Power and Remote Turn-on lead for proper LED's on +12 Voltage. (12 - 16 Volts DC acceptable range.) 3.
