NETGEAR DGN2200v1 Installation Manual

N300 Wireless ADSL2+ Modem Router
DGN2200
Package Contents:
N300 Wireless ADSL2+ Modem Router
DGN2200
Resource CD
Phone
Filter Splitter
(plug varies by country)
Telephone Cable Ethernet Cable
Installation Guide
Internet
Tip: Use an ADSL microfilter
for every phone line in the house.
If your modem router and telephone
connect to the same phone line,
use an ADSL microfilter/splitter
like the one shown here.
Modem Router
ADSL
Phone
Filter/splitter
Note: If your laptop does not have a CD drive, see "Manual Installation"
on the back to complete your router setup.
Power Adapter
4 Step Cable Connection
1
Line
3
Power
2
on/off
Laptop or Desktop
Computer
4
Resource CD
