- Page 1 User Manual 2024 HKN-CBG36A Gas Countertop Charbroilers Radiant Models Models: HKN-CBG24A HKN-CBG36A HKN-CBG48A Note: Please read this manual thoroughly prior to equipment set-up, operation, and maintenance. www.equip.me...
- Page 2 WARNINGS Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other equipment. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation and maintenance instructions thoroughly before installing or servicing this equipment.
- Page 3 Gas Countertop Charbroilers Radiant Models Table of Contents Features & specifications Installation instructions Regular maintenance Troubleshooting Instructions and images in this manual are only for reference and may differ from the actual product. Launch the E-Manual. www.equip.me...
-
Page 4: Features And Specifications
Features & specifications Style Manifold Total B.T.U. Model Gas Type (manual) pressure per Hour 2 Burners w/ Natural 4.0" WC HKN-CBG24A 60,000 individual control Propane 10.0" WC 3 Burners w/ Natural 4.0" WC HKN-CBG36A 90,000 individual control Propane 10.0" WC... - Page 5 SET UP Pressure testing: The equipment and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½ psi (3.5 kPa). The equipment must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½...
-
Page 6: Propane Gas Conversion
PROPANE GAS CONVERSION This charbroiler is shipped from the factory equipped with fixed burner orifices for natural gas operation. The burner orifices required to convert the charbroiler to propane gas are shipped with the charbroiler in the shipping packaging. It is recommended that a trained gas service technician with the necessary tools, instruments and skills perform the conversion. -
Page 7: Operation
Preheating the charbroiler: Allow the charbroiler to preheat for 30 minutes. Rub grates with cooking oil before using After 20 minutes of burn-in, equipment is ready for use. OPERATION: 1. To ignite the burners, depress and turn the gas control knob to high position. 2. -
Page 8: Troubleshooting
Maintenance A qualified service company should check the unit for safe and efficient operation on an annual basis. Gas piping shall be a certain size and installed to provide a supply of gas sufficient to meet the full gas input of the equipment. A manual shut off valve should be installed upstream from the manifold within 4 ft.
