Parklio Bollard User Manual

Hide thumbs Also See for Bollard:

Advertisement

Quick Links

Download this manual
Parklio™ Bollard
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the Bollard and is the answer not in the manual?

Questions and answers

Related Manuals for Parklio Bollard

Summary of Contents for Parklio Bollard

  • Page 1 Parklio™ Bollard USER MANUAL...
  • Page 2 4.4.4. Electrical connections ..................30 4.4.5. Autonomy and Battery Life ................36 5. Controlling the Bollard ..................37 5. 1. Bollard Key Reset ....................38 6. Manual Bollard Release ..................40 Unlocking Steps ......................40 7. Cleaning and Maintenance ..................42 8.
  • Page 3 To ensure you have the most up-to-date information, we kindly request that you visit our official website regularly. Attention! • Read the user manual and technical sheet before installing and using the Parklio Bollard. • Always follow the safety instructions.
  • Page 4 The Parklio™ Bollard is available in standard and solar models, providing flexibility for various installation environments. The solar model includes a solar panel kit, allowing installation without relying on a continuous power supply, ensuring continuous functionality, and providing an eco-friendly alternative.
  • Page 5 ➔ Durable Design: Made from stainless steel for long-lasting performance in all weather conditions. ➔ Remote Control: Operate the bollard using a smartphone app or remote control device. ➔ Solar-Powered Option: Available for areas without a steady power supply, offering eco-friendly operation.
  • Page 6 ANY DAMAGE OR INJURY TO PEOPLE OR THINGS CAUSED BY IMPROPER USE OR WRONG INSTALLATION. THE BOLLARD WAS MADE IN ACCORDANCE WITH ALL IMPORTANT SAFETY CRITERIA AND STANDARDS. CHILDREN, PERSONS WITH DISABLED PHYSICAL, MOTOR, OR PERSONAL EQUALITY, AND RELATED PEOPLE WITHOUT PREVIOUS EXPERIENCE OR KNOWLEDGE SHOULD NOT USE THE BOLLARD WITHOUT THE REQUIRED HELP AND SUPERVISION.
  • Page 7 Parklio is not liable for the incorrect use of this product or another use other than the one for which it was designed. Before installing the product, make sure it is in perfect condition.
  • Page 8 1 milimeter and from water spray less than 60 degrees from vertical. Double insulation symbol The appliance is double-insulated and does not require a safety connection to electrical earth (ground). _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 9 Ignoring use instructions, as well as inappropriate installation and use of the bollard may result in bollard damage or user injury. Parklio is not liable if the safety standards were not taken into account when installing the equipment to be automated or for any deformation that may occur to it.
  • Page 10 Always use the same type of module within a particular photovoltaic system. The provided battery for the solar model of the bollard, is fragile; please handle it with care. Do not expose the battery to direct heat. _______________________________________________________________________ www.parklio.com...
  • Page 11 The battery provided for the solar model of the bollard is intended to be used only with Parklio products; use with other products is not recommended . Parklio is not responsible for any damage caused to the equipment or the battery pack when misused.
  • Page 12 The installer of the product must provide a means for cable strain relief to prevent the transmission of stress to the connections. ➔ In addition to this manual, refer to the photovoltaic panel manual for detailed instructions and to the battery manual for scheduled maintenance cycles. _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 13 3. Product Description This section will describe all the components a parking bollard is made of. 3.1. Product Components Overview _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 14 3.2. Dimensions _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 15 60 W Duty cycle 70 % Operating temperature -20ºC to +50ºC / -4ºF to +122ºF Covers Anti-slip stainless steel 4 mm Weight capacity when closed 20000 kg / 44100 lb Diameter 204 mm / 8 In _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 16 4. Installation This section describes how to install the Parklio Bollard. The illustrations provided here are purely for illustrative purposes. Depending on the total size of the installation, the area required for mounting the automatic bollard and accessories may vary. The installer is in charge of selecting the best solution.
  • Page 17 4.2. Unpacking the Product The Parklio™ Bollard is delivered in sturdy, high-quality packaging to ensure protection during shipment. Upon unpacking, carefully check that all necessary components are included in the package. Inspect each component for any visible damage and ensure that nothing is missing.
  • Page 18 STEP 1. Inside the prepared hole, create a solid cement base that will support the Parklio Bollard. Ensure that the base is perfectly level and stable to maintain proper bollard alignment and operation. Place the sewer at an angle of 10°, as depicted in Section A of the diagram below.
  • Page 19 STEP 4. Make sure no debris, dirt, or foreign objects fall inside of the bollard protecting the space using a piece of cloth, paper, or other material to create a seal between the stainless steel tube and the PVC pipe.
  • Page 20 Section B of the diagram below. STEP 6. Put the bollard cover back in place and complete the installation by pouring a concrete layer around the bollard for long-term stability, as illustrated in Section C of the diagram.
  • Page 21 STEP 9. Mount the control box in close proximity to the bollard, ensuring it is installed at least 20 cm above the ground level. For distances exceeding 10 meters between the control box and the bollard, a 2.25 mm power cable is required.
  • Page 22 -4°F to +131°F 95%, Non-Condensing HUMIDITY CHARGING PEAK EFFICIENCY IP65 DEGREE OF PROTECTION DIMENSIONS 400 mm x 300 mm x 200 mm / 15.7 in x 11.8 in x 7.9 in WEIGHT 8 kg / 17.6 lbs _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 23 4.0 kg / 8.8 lbs 4.4.2. Photovoltaic Module Mounting Solar photovoltaic modules are engineered to transform light energy into direct-current electrical energy, specifically for outdoor applications. These modules can be installed on the ground, rooftops, vehicles, or boats. _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 24 To avoid glass breakage, do not place any heavy objects on the module. ➔ Do not set the module down hard on any surface to avoid breakage. ➔ Transport and install the module with caution to avoid damage. _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 25 Do not attempt to drill holes in the glass surface of the modules, as this action will void the warranty. Do not drill additional mounting holes in the frame of the module, as this action will also void the warranty. _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 26 In addition, ensure that the lowest portion of the module is placed high enough so that it is not shaded by plants or trees or damaged by sand and stone driven by wind. _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 27 In some cases, a special support frame may be necessary. The roof installation of solar modules may affect the fireproofing of the house construction. _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 28 If the support frame is made of metal, the surface of the frame must be electro- plated and have excellent conductivity. We recommend the lay-in lug when grounding (Cat. No. GBL4-DBT is recommended by the producer). _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 29 The Dimensions Drawings chapter of this manual contains a dimension drawing of the solar panels and Junction box. This drawing also indicates the mounting holes. Observe a minimum clearance of 10 cm under and above the Junction Box charger for optimal cooling. _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 30 / AWG 10 cable for connecting the PV panels in series and to the junction box. For connecting the Load output to the Parklio bollard, it is recommended to use at least 2.5m m2 / AWG 14 wire. The wire diameter may vary depending on the installation distance of the PV panels to the Junction box and the Junction box to the Parklio bollard.
  • Page 31 Torque the battery, load, and PV connections at 0.75 Nm. The Parklio Solar kit comes with pre-wired batteries and charging circuitry. The installer must connect the PV panels to the Junction box, the load output to the Parklio bollard, and ground the Junction Box and PV.
  • Page 32 _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 33 Then connect the Photovoltaic panel negative lead to the SOLAR - input of the Junction box and the panel positive lead to the SOLAR + input of the junction box. Connect the Load of the Junction box to the Parklio bollard. After all connections are made, inspect the connections, then turn on the Battery disconnect switch.
  • Page 34 The Solar kit replaces the power transformer. Connect the Solar kit LOAD output from the Junction box to the Parklio Bollard “20V VAC” input on the control board (pins 1 and 2). The connection polarity is not important.
  • Page 35 PV panels to reduce the impact of lightning. Do not connect the solar charger to a grounded PV array. Only one ground connection is allowed, and this should be near the battery. Ground Fault Detection _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 36 100%. From that point onward, the load disconnect level will be modulated so that a nearly 100% recharge is achieved about once every week. _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 37 Utilize your smartphone to manage bollard operations effortlessly via Bluetooth connectivity, eliminating the need for an internet connection. The app provides real-time control, allowing you to raise or lower the bollard with a simple tap. Additionally, you can share digital keys with authorized users, specifying access durations as needed.
  • Page 38 5. 1. Bollard Key Reset The Bollard digital key is set once the Bollard is added to a user account. This key can only be removed by resetting it. The reset is done by pressing and holding the Reset button for 3 seconds, until the green LED lights up.
  • Page 39 Resetting the Bollard digital key will cause all the shared guest keys and the owner key to be unusable. It will be necessary to resend all guest keys individually. _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
  • Page 40 Unlocking Steps STEP 1. Locate the manual release slot on the surface of the bollard. ( Figure 8.1. ) STEP 2. Insert the key into the slot and turn it clockwise to disengage the bollard’s locking mechanism ( Figure 8.2 ).
  • Page 41 EMERGENCY USE GUIDELINES ➔ During a power outage, the bollard relies on a backup battery, which can perform only one maneuver (open or close). Avoid using the bollard further until the 230V power supply is restored, as the battery is meant strictly for emergencies.
  • Page 42 . Avoid unauthorized repairs to prevent damage or voiding the warranty. Inspect the bollard periodically (every 6 months) for signs of wear or damage. Check for obstructions, dirt buildup, or blockages around the moving components. Regularly inspect the control box for any signs of moisture, dust, or damage that could impair its functionality.
  • Page 43 For solar bollard systems, ensure that photovoltaic panels, batteries, and associated components are disposed of in accordance with specific regulations for electronic and hazardous waste. Batteries may contain substances that are harmful to the environment and require disposal at certified recycling facilities.
  • Page 44 EN 60335-1 ● EN 55014-1 ● EN 55014-2 ● EN 61000-3-2 ● EN 61000-3-3 ● Parklio d.o.o. declares the control board follows the directive 95/05/EC (R&TTE). _______________________________________________________________________ www.parklio.com info@parklio.com +385977247276...
