- Page 1 PARKLIO BOLLARD USER MANUAL PARKLIO BOLLARD DETAILED INSTRUCTIONS P a g e www.parklio.com info@parklio.com +385977247276 Hercegovacka 78, 21 000 Split Commercial Court in Split MBS: 060323069 Raiffeisen Bank, Zagreb, Petrinjska 59 IBAN: HR7724840081107194017 VAT: HR60755958894...
- Page 2 Thank you for the confidence you have shown us by purchasing our product. Please read this manual first! Dear Customers, We hope that all your expectations about this product will be fulfilled. Parklio Bollard is manufactured using the latest technologies and has undergone rigorous quality control procedures.
-
Page 3: Table Of Contents
02. Technical Data.................... 04 03. Consideration for Installation................. 05 04. Method of Installation ..................05 05. Work Phases ..................... 06 06. Installation Bollard ................... 07 07. Electrical Connection ................09 7.1 Emergency release................... 09 08. Trouble Shooting ....................10 09. -
Page 4: Dimensions
PARKLIO BOLLARD USER MANUAL 01.DIMENSIONS 02.TECHNICAL DATA Motor power supply 230 Vac Motor current input 250 W Motor RPM 1400 Condenser 12.5 µF Operating temperature -20° C / +55° C Led power supply 24 Vac P a g e www.parklio.com info@parklio.com... -
Page 5: Consideration For Installation
04. METHOD OF INSTALLATION • Create an excavation in the ground of an adequate size to hold the tube outside of the bollard and prepare the trunking and drainage for the water inside the holes on the bottom of the tube. -
Page 6: Work Phases
PARKLIO BOLLARD USER MANUAL 05.WORK PHASES • Prepare level (A) at a depth of about 1m from the surface • Block the tube (T) through weak-mix concrete (M) • Check the lead and level • Put cement P a g e www.parklio.com... -
Page 7: Installation Bollard
PARKLIO BOLLARD USER MANUAL BOLLARD INSTALLATION (If supplied separately from tube) P a g e www.parklio.com info@parklio.com +385977247276 Hercegovacka 78, 21 000 Split Commercial Court in Split MBS: 060323069 Raiffeisen Bank, Zagreb, Petrinjska 59 IBAN: HR7724840081107194017 VAT: HR60755958894... - Page 8 PARKLIO BOLLARD USER MANUAL P a g e www.parklio.com info@parklio.com +385977247276 Hercegovacka 78, 21 000 Split Commercial Court in Split MBS: 060323069 Raiffeisen Bank, Zagreb, Petrinjska 59 IBAN: HR7724840081107194017 VAT: HR60755958894...
-
Page 9: 07. Electrical Connection
PARKLIO BOLLARD USER MANUAL ATTENTION! DO NOT UNSCREW OR REMOVE THE WHOLE CAP. IT CAN CAUSE WATER INFILTRATION. P a g e www.parklio.com info@parklio.com +385977247276 Hercegovacka 78, 21 000 Split Commercial Court in Split MBS: 060323069 Raiffeisen Bank, Zagreb, Petrinjska 59... -
Page 10: Trouble Shooting
PARKLIO BOLLARD USER MANUAL 08. PROBLEMS-CAUSES AND SOLUTIONS 10 | P a g e www.parklio.com info@parklio.com +385977247276 Hercegovacka 78, 21 000 Split Commercial Court in Split MBS: 060323069 Raiffeisen Bank, Zagreb, Petrinjska 59 IBAN: HR7724840081107194017 VAT: HR60755958894... -
Page 11: Safety Precautions
PARKLIO BOLLARD USER MANUAL 09. SAFETY PRECAUTIONS These warnings are an essential, integral part of the product and must be given to the user. They provide important indications on the installation. Use and maintenance must be read carefully. This form must be preserved and passed on to subsequent users of the system. - Page 12 PARKLIO BOLLARD USER MANUAL SAFETY WARNINGS • Read the instructions and enclosed documentation carefully. • The product must be used for the express purpose for which it was designed. Any other use is considered improper and therefore hazardous. Furthermore, the information given in this document and in the attached documentation may be subject to modifications without prior notice.
