- Page 1 E5-MR9S User's Manual https://z.wiki...
- Page 2 Any problem, please feel free to contact us. Contents Specifications ............................1 Overview of Components ........................2 Install CPU & Fan .........................3 Install Memory ..........................4 Install Expansion Card .........................5 Back Panel Connectors ....................... 5 USB 2.0 Port ........................6 USB 3.0 Port ........................6 RJ45 LAN Port ........................6 Audio Port ...........................
- Page 3 Any problem, please feel free to contact us. Specifications E5-MR9S Compatible with Intel 5th/6th generation Core i7 processors and XEON Processor E5 V3/V4 series processors, not compatible with LGA 2011 CPUs. Southbridge B85 Chipset Technology 4 Channel DDR4 Maximum 256GB (32GB*8)
- Page 4 Any problem, please feel free to contact us. Overview of Components Package List: E5-MR9S Motherboard * 1 SATA Cable * 1 I/O Blocking * 1 CPU fan bracket * 1 DC-Fan * 1 — 2 — https://z.wiki...
- Page 5 Any problem, please feel free to contact us. Install CPU & Fan Please install the CPU into the CPU socket as shown below. Important • Make sure that the motherboard supports the CPU. • Always unplug the power cord from the power outlet before installing or removing the CPU to prevent hardware damage.
- Page 6 Any problem, please feel free to contact us. Install Memory The motherboard provides 8 DDR4 ECC DIMM slots with a maximum capacity of 256GB. 1. Wrench the latches on both sides of the memory slot outwards. 2. Insert the memory into the slot by aligning it with the notch in the slot. 3.
- Page 7 Any problem, please feel free to contact us. Install Expansion Card The motherboard provides 2 PCI Express 3.0 X16 expansion slots, 1 PCI Express 3.0 X4 expansion slot and 2 PCI Express 3.0 X1 expansion slot. Place the expansion card in an available PCI Express slot and press the expansion card until it is fully inserted into the slot.
- Page 8 Any problem, please feel free to contact us. USB 2.0 Port The USB port supports the USB 2.0 specification. Use this port for USB devices. USB 3.0 Port The USB 3.0 supports the USB 3.0 specification and is compatible to the USB 2.0 specification.
- Page 9 Any problem, please feel free to contact us. Internal Connectors F_PANEL1 Connector SPEAK1 Connector JAUDIO1 Connector This connector allows you to connect audio jacks on the front panel. Important • An incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it.
- Page 10 Any problem, please feel free to contact us. 4* SATA 3.0 Connectors and 2* SATA 2.0 Connectors These SATA 3.0 connectors are SATA 6Gb/s interface ports. Each SATA connector supports a single SATA device. M.2 Slot Insert your M.2 SSD into the M.2 slot at a 30-degree angle. Secure the M.2 SSD in place with the scr ew.
- Page 11 Any problem, please feel free to contact us. JCOM1: Serial Port Connector The COM connector can provide one serial port via an optional COM port cable. ATXPWR1, JATXPWR1: Power Connectors With the use of the power connector, the power supply can provide enough stable power to all the components on the motherboard.
- Page 12 Any problem, please feel free to contact us. CPU_FAN1, SYS_FAN1~3: Fan Connectors CPU_FAN is a interface for CPU radiator. The 4pin fan has PWM intelligent speed regulation function, which can intelligently control the fan speed based on load and temperature changes.
- Page 13 Any problem, please feel free to contact us. BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the CMOS on the motherboard. BIOS identifies, configures, tests and connects computer hardware to the OS immediately after a computer is turned on. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters and loading the operating system, etc.
- Page 14 Any problem, please feel free to contact us. Enter BIOS Setup Entering BIOS Setup When the computer starts up, BIOS enters the self-test process. When the self-test is completed, the following message is displayed: Press DEL key to enter Setup Menu. At this time, Press <Delete>...
