B75-PRO-U5
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B75-PRO-U5 and is the answer not in the manual?

Questions and answers

Related Manuals for MACHINIST B75-PRO-U5

Summary of Contents for MACHINIST B75-PRO-U5

  • Page 1 B75-PRO-U5 User's Manual...

  • Page 2: Table Of Contents

    Any problem, please feel free to contact us. Contents Specifications......................1 Overview of Components..................2 Install CPU & Fan....................3 Install Memory.....................4 Install Expansion Card..................5 Back Panel Connectors..................5 USB 2.0 Port....................5 VGA Port......................5 USB 3.0 Port....................6 RJ45 LAN Port....................6 Audio Port.......................

  • Page 3: Specifications

    Any problem, please feel free to contact us. Specifications B75-PRO-U5 Supports Intel Core i3/i5/i7 2th or 3th generation, Xeon E3 v2, Pentium and Processor Celeron series processors Southbridge B75 Chipset Technology Dual channel DDR3 Maximum 16GB (8GB*2) Capacity Memory Slot...

  • Page 4: Overview Of Components

    Any problem, please feel free to contact us. Overview of Components Package List: B75 Motherboard * 1 SATA Cable * 1 I/O Blocking * 1 — 2 —...

  • Page 5: Install Cpu & Fan

    Any problem, please feel free to contact us. Install CPU & Fan Please install the CPU into the CPU socket as shown below. Important • Make sure that the motherboard supports the CPU. • Always unplug the power cord from the power outlet before installing or removing the CPU to prevent hardware damage.

  • Page 6: Install Memory

    Any problem, please feel free to contact us. Install Memory The motherboard provides 2 DDR3 DIMM slots with a maximum capacity of 16GB. 1. Wrench the latches on both sides of the memory slot outwards. 2. Insert the memory into the slot by aligning it with the notch in the slot. 3.

  • Page 7: Install Expansion Card

    Any problem, please feel free to contact us. Install Expansion Card The motherboard provides a PCI Express 3.0 x16 expansion slot. Place the expansion card in an available PCI Express slot and press the expansion card until it is fully inserted into the slot. Important •...

  • Page 8: Usb 3.0 Port

    Any problem, please feel free to contact us. VGA (Video Graphics Array) supports analog video signal transmission, high resolution, fast display rate and rich colors. HDMI Port The HDMI port supports 4K and 1080px. You can use this port to connect your HDMI-supported monitor.

  • Page 9: Internal Connectors

    Any problem, please feel free to contact us. Internal Connectors F_PANEL1 Connector SPEAK1 Connector JAUDIO1 Connector This connector allows you to connect audio jacks on the front panel. Important • An incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it.

  • Page 10: Sata 3.0 Connectors; Sata 2.0 Connectors

    Any problem, please feel free to contact us. SATA 3.0 Connectors; SATA 2.0 Connectors These SATA 3.0 connectors are SATA 6Gb/s interface ports. Each SATA connector supports a single SATA device. M.2 Slot Insert your M.2 SSD into the M.2 slot at a 30-degree angle. Secure the M.2 SSD in place with the scr ew.
  • Page 11 Any problem, please feel free to contact us. Important • Always turn off the computer and unplug the power cord from the power outlet before discharging. — 9 —...

  • Page 12: Jcom1: Serial Port Connector

    Any problem, please feel free to contact us. JCOM1: Serial Port Connector The COM connector can provide one serial port via an optional COM port cable. ATXPWR1, JATXPWR1: Power Connectors With the use of the power connector, the power supply can provide enough stable power to all the components on the motherboard.

  • Page 13: Cpu_Fan1, Sys_Fan1~3: Fan Connectors

    Any problem, please feel free to contact us. CPU_FAN1, SYS_FAN1~3: Fan Connectors CPU_FAN is a interface for CPU radiator. The 4pin fan has PWM intelligent speed regulation function, which can intelligently control the fan speed based on load and temperature changes.

  • Page 14: Bios Setup

    Any problem, please feel free to contact us. BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the CMOS on the motherboard. BIOS identifies, configures, tests and connects computer hardware to the OS immediately after a computer is turned on. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters and loading the operating system, etc.

  • Page 15: Enter Bios Setup

    Any problem, please feel free to contact us. Enter BIOS Setup Entering BIOS Setup When the computer starts up, BIOS enters the self-test process. When the self-test is completed, the following message is displayed: Press DEL key to enter Setup Menu. At this time, Press <Delete>...
  • Page 16 Any problem, please feel free to contact us. several ways to reset the BIOS: ∙ Go to BIOS and press F6 to load optimized defaults. ∙ Short the Clear CMOS jumper on the motherboard. Important • Be sure the computer is off before clearing CMOS data. Please refer to the Clear CMOS jumper section for resetting BIOS.
