Bosch Rexroth A2FO Instruction Manual
Bosch Rexroth A2FO Instruction Manual

Bosch Rexroth A2FO Instruction Manual

Axial piston fixed pump
Hide thumbs Also See for Rexroth A2FO:

Advertisement

Quick Links

Аксиально-поршневой насос
с постоянным рабочим объемом
A2FO
Технический паспорт
Серия 6
Номинальный размер
5
от 10 до 200
от 250 до 1000
Открытый контур
Содержание
Код заказа для стандартной программы поставок 2
Технические характеристики
Размеры, номинальный размер 5
Размеры, номинальный размер 10, 12, 16
Размеры, номинальный размер 23, 28, 32
Размеры, номинальный размер 45
Размеры, номинальный размер 56, 63
Размеры, номинальный размер 80, 90
Размеры, номинальный размер 107, 125
Размеры, номинальный размер 160, 180
Размеры, номинальный размер 200
Размеры, номинальный размер 250
Размеры, номинальный размер 355
Размеры, номинальный размер 500
Размеры, номинальный размер 710
Размеры, номинальный размер 1000
Указания по монтажу
Общие указания
Номинальное/максимальное давление
315/350 бар
400/450 бар
350/400 бар
4
10
11
13
15
17
19
21
23
25
26
27
28
29
30
31
33
R-RS 91401/06.2012 1/34
Заменяет: 03.08
Особенности
– Аксиально-поршневой насос с постоянным
рабочим объемом в исполнении с наклонным
блоком для гидростатических приводов с открытой
системой циркуляции рабочей жидкости
– Используется в мобильном и стационарном
оборудовании
– Объемный расход насоса пропорционален частоте
вращения приводного вала и рабочему объему
насоса
– Подшипниковая опора приводного вала рассчитана
на стандартные для таких сфер применения
требования к сроку службы подшипников
– Высокая удельная мощность
– Компактные размеры
– Высокий суммарный КПД
– Экономичное техническое решение
– Цельный конусный поршень с поршневыми
кольцами для герметизации
