- Page 1 4K Analog HDCVI Dome Camera Version 1.0.0...
- Page 2 Contents Welcome ....................................3 Important Safeguards and Warnings ............................3 Product Introduction ................................4 Features ....................................4 Installation ....................................4 Connection ....................................5 Audio ...................................... 5 Technical Specifications ................................5 FCC Statement ..................................7 IC Warning Statement................................7 Appendix A: Toxic or Hazardous Materials or Elements ......................8...
- Page 3 Many of the setup and installation sections have corresponding videos on YouTube. To access the setup videos, please go to http://amcrest.com/videos. For access to other support related materials and information, please visit us at http://amcrest.com/support. To contact Amcrest support, please do one of the following: Visit http://amcrest.com/contacts...
- Page 4 Be sure to use only the accessories recommended by the manufacturer. Before installation, please open the package and check to make sure that all the components are present. Contact the retailer that you purchased from or Amcrest directly if anything is broken or missing in the package. Product Introduction These series of cameras adopt with CMOS image sensors that provide high performance, high megapixel resolution that supports 4K video.
- Page 5 Using a drill bit that is the same diameter or slightly smaller diameter than the included drywall wall anchors, drill the 4 holes and insert the wall anchors into the holes. Note: The wall anchors should be in the same bag as the screws and a designed to secure the screws onto the mounting surface.
- Page 6 S/N Ratio >65dB Minimum Illumination 0.03Lux/F2.0, 30IRE, 0Lux IR on IR Distance 98.4ft (30m) IR On/Off Control Auto/Manual IR LEDs Pan/Tilt/Rotation Range Pan:0°-360°, Tilt: 0°-78°, Rotation: 0°-360° Lens Lens Type Fixed-focal Mount Type Focal Length 2.8mm Max. Aperture F2.0 Angle of View H: 105°, V: 56°, D: 125°...
- Page 7 Storage Temperature -40°F to 140°F (-40°C to +60°C), <95% (non-condensation) Protection Grade IP67 Casing Plastic w/metal inner core Mounting Wall Mount: AMCPFA130-E, Ceiling Mount: AMCPFA106 + AMCPFB220C, Pole Mount: AMCPFA130-E + AMCPFA152-E Dimensions Φ3.82"×3.38" (Φ97 mm × 85.8 mm) Weight 0.66lbs.
- Page 8 radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body.
- Page 9 To contact Amcrest support, please do one of the following: Visit http://amcrest.com/contacts and use the email form. Call Amcrest Support using one of the following numbers: Toll Free US: (888) 212-7538 International Callers (Outside of US): +1-713-893-8956 USA: 713-893-8956 Canada: 437-888-0177...
