Ellipse Matrix Blend

Battery

When the battery is low you will hear distortion as you play through the Ellipse system. Remove
the strings, to access the battery inside the guitar. Replace with a fresh 9V alkaline battery.
We recommend that you remove the battery prior to shipping or airline travel. If loose inside the
guitar, the battery may damage the instrument.
E S
LECTRICAL

General:

Typical 9V alkaline battery life:
Typical current consumption @ 9Vdc:
Nominal output impedance:
Maximum output level (onset of clipping):

Pickup Input

(Measured with Blend control set to Pickup):
Signal gain with Matrix pickup:
Baseline noise (A-weighted):
Dynamic range (A-weighted, referenced to onset of clipping):
Signal to noise ratio (A-weighted, referenced to -10dBV output):

Voicing Switch

Natural I setting:
Frequency response (-3dB referenced to 2kHz):
Bass boost:
Natural II setting
Frequency response (-3dB referenced to 2kHz):

Microphone Input

Mic Trim gain range:
Baseline noise at maximum gain (A-weighted):
Baseline noise at minimum gain (A-weighted):
Dynamic range
(A-weighted, referenced to onset of clipping, maximum gain):
Signal to noise ratio
(A-weighted, referenced to -7dBV, maximum gain):
Frequency response (-3dB referenced to 2kHz, -10dB at 100Hz):
Because we continually improve our products, all specifications and information in this manual are subject to change without notice.
513-000-029 Rev B 3-05 • This product is protected by one or more of the following patents: 6,278,059, 4,774,867, 4,727,634,
4,944,209, 5,029,375, 5,155,285, 5,319,153, 5,189,771, 5,463,185, 5,670,733, 5,817,966, 4,911,057, 4,984,498,
5,693,898, 6,239,349, 6,429,367, 4,785,704, 4,356,754, 6,680,431, and 6,677,514. Other patents may also apply.
PECIFICATIONS
www.fishman.com
220 hrs.
2.3mA
1k Ohm
+7dBV
+3.5dB
95dBV
102dB
85dB
50Hz – 160kHz
+3dB @ 90Hz
80Hz – 140kHz
-1.5dB to +8.5dB
-103dBV
-105dBV
110dB
98dB
300Hz – 75kHz
