Mackie PROFX10 GO Owner's Manual

10-channel battery powered analog mixer with enhanced fx, usb recording modes, and bluetooth

Hide thumbs

page of 54

/ 54
Bookmarks

Quick Links

Download this manual

10 CHANNEL BATTERY POWERED ANALOG MIXER

WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH

OWNER'S MANUAL

www.mackie.com

Need help?

Do you have a question about the PROFX10 GO and is the answer not in the manual?

Questions and answers

Summary of Contents for Mackie PROFX10 GO

Page 1 10 CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH OWNER’S MANUAL www.mackie.com...
Page 2 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Important Safety Instructions 1. Read these instructions. 20. This apparatus has been equipped with a rocker-style AC mains power switch. This switch is located on the rear panel and should remain readily accessible to the user.
Page 3 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Table of Contents Important Safety Instructions ................................2 Table of Contents ......................................3 Chapter : Welcome ....................................6 Introduction ........................................6 Features .........................................6 Things to Remember ....................................7 About This Guide .......................................8 Getting Started ......................................8...
Page 4 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Pan Knobs .......................................18 Mute Switches ......................................18 Channel Level Knobs ....................................19 USB 3-4 Switch ......................................19 Bluetooth Switch .....................................19 FX Footswitch Jack ....................................20 L/R Main Output Jacks ..................................20 1/4"...
Page 5 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Hookup Diagrams ....................................40 Hookup Diagrams > Typical Live Sound System ..........................40 Hookup Diagrams > Typical Recording System..........................41 Hookup Diagrams > Camping ................................42 Appendix A : Service Information ................................
Page 6 • When you’re out of juice, swap out the battery with a spare (sold separately) for double the battery life • All the bells and whistles of a professional Mackie mixer, including Onyx™ preamps, no longer chained to the wall •...
Page 7 Please see the Safety Instructions on page 2 for information on hearing protection. • As a general guide, the ProFX10 GO should be turned on ﬁrst, subwoofers next, and the loudspeakers last. As such, the loudspeakers should also be turned o ﬁrst, followed by the subwoofers, then the ProFX10 GO.
Page 8 ProFX10 GO. Getting Started The following steps will help you set up the ProFX10 GO quickly. If you desire a more thorough walk-through of ProFX10 GO, there is a wealth of information in the following pages! Read and understand the Important Safety Instructions on page 2.
Page 9 Introduction The top panel of the ProFX10 GO mixer may be where the magic all happens, but nothing will happen if it can’t be powered up, so let’s start there! The rear panel of each ProFX10 GO mixer is ou ﬁtted with a power connector, power switch, and a USB-C port for connecting to a computer.
Page 10 This is a 2x4 interface that allows audio to stream to and from the ProFX10 GO mixer via computer. Connect the USB-C side of a USB cable to the ProFX10 GO mixer and the USB-A side to the computer’s USB port.
Page 11 Introduction From top to bottom and lef to right, the top panel of each ProFX10 GO mixer is ou ﬁtted with a bunch of knobs, buttons, faders, jacks, screens, and more. So much more, in fact, that we will call out and describe each one...
Page 12 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH XLR Mic Input Jacks This is a female XLR connector that accepts a balanced mic or line level input from almost any type of source. These mic preamps feature higher ﬁdelity and headroom rivaling any standalone mic preamp on the market today.
Page 13 Sleeve = Shield (Ground) Tip = Lef Channel Ring = Right Channel While the volume may be raised and lowered via the ProFX10 GO mixer, the volume of the device also needs to be up. Line / Hi-Z Switches [Chs. 1 and 2] To connect a guitar or bass directly to the mixer without using a DI Box, press this switch in ﬁrst;...
Page 14 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH 1/4" Insert Jacks These unbalanced /4" jacks are for connecting serial e ects processors such as compressors, equalizers, de-essers, or ﬁlters. The insert point is af er the gain control and low cut ﬁlter, but before the channel’s EQ and level. The channel signal can go out of the insert jack to an external device, be processed and come back in on the same insert jack.
Page 15 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Gain Knobs and Level Set LEDs “U” like Unity Gain ProFX10 GO mixers have a “U” symbol on many level controls. It stands for “unity gain,” meaning no change in signal level.
Page 16 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Compressor Knobs Channels –2 of each ProFX10 GO mixer has an in-line compressor circuit with a variable threshold. This is very useful for compression of vocals, and snare drums, for example, so you might consider connecting your vocal and drum mics to these channels, rather than one of the other channels.
Page 17 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Channel Equalization (EQ) ProFX10 GO mixers have 3-band EQ with shelving hi, peaking mid, and shelving low. The 3-band equalization has low shelving at 80 Hz, mid peaking at 2.5 kHz, and high shelving at 2 kHz.
Page 18 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH FX Knobs These knobs tap a portion of each channel’s signal to set up a nice FX mix feeding the internal FX processor, and to feed external processors via the FX send.
Page 19 Bluetooth Switch Mixers can only accept one input per channel and the ProFX10 GO is no di erent. This switch will engage the channel’s pairing mode, allowing the mixer to be seen by other Bluetooth devices such as a phone or tablet.
Page 20 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH FX Footswitch Jack This /4" TRS connector is where to connect your favorite footswitch. This allows you to easily mute or un-mute the internal e ects at will. Any one-button on/o footswitch will work.
Page 21 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH To connect unbalanced lines to these outputs, use a /4" mono (TS) phone plug, wired as follows: 1/4" TS Unbalanced Mono Wiring: Sleeve = Shield...
Page 22 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH 1/4" Control Room Jacks These /4" jacks are usually patched to the inputs of a control room ampliﬁer or a headphone distribution ampliﬁer. The control room outputs may also be used for other applications. The sound quality is just as impeccable as the main outputs.
Page 23 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Main Meters These peak meters are made up of two columns of twelve LEDs, with three colors to indicate di erent ranges of signal level, tra c light style. They range from –30 at the bottom, to 0 in the middle, to OL at the top.
Page 24 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Phones Knob This knob is used to adjust the volume at the phones output from (o ) to maximum gain (max). Make sure that this knob is fully o [counter-clockwise] before selecting or adding a new source.
Page 25 REVERB + CHORUS Factory Reset When a ProFX10 GO is factory reset, it restores most parameters back to their default. This includes all FX parameters and any stored presets. This is a permanent reset with no undo. So how does one place the mixer back to its factory default? Press and hold the Studio Command Control Knob AND Back Button simultaneously until the display shows the Mackie Running Man.
Page 26 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH FX Section The ProFX10 GO FX engine is incredibly powerful and packed with a ton of features. There are 2 e ects to choose from, but each one of those may be manipulated and tweaked to your inclination.
Page 27 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Delay The preset display should now show the current parameters of the delay e ect: DELAY TIME HICUT PRESETS Delay allows adjustment of the delay e ect. ProFX10 GO mixers come with three delays to choose from: delay, echo and slapback.
Page 28 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH FX EQ Now let’s take a look at the EQ section. As before, rotate the knob until EQ is highlighted, then push in to reveal the EQ screen.
Page 29 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Before moving on to ‘Presets’ and ‘Reset’, let’s take a quick peek at the parameters of delay, echo and slapback, as well as their EQ settings.
Page 30 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH FX Presets The presets section allows you to save up to six settings to memory that may be recalled at a later time. No more having to reset parameters upon every power-up! As was done previously, simply rotate the Studio Command Control Knob until ‘Presets’...
Page 31 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH FX EQ Reset A few pages ago, we were looking at the FX EQ section. In addition to the changeable parameters – frequency, width, gain, LPF and HPF –...
Page 32 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Hall Reverb Parameters and Values Parameter Low Value High Value Default Increments Decay ± Size ± Hi Cut ± – – – – Frequency 400 Hz 6.0 kHz...
Page 33 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Now a look at the three modulation e ects (Chorus , Chorus 2 and Flanger). FLANGER RATE DEPTH BLEND PRESETS Rate – This knob sets the speed of the delay modulation. The range will vary depending on the e ect chosen.
Page 34 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Flanger Parameters and Values Parameter Low Value High Value Default Increments Rate ± Depth ± Blend ± – – – – Frequency 400 Hz 6.0 kHz...
Page 35 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Lastly, onto the ﬁnal three multi-purpose e ects (Delay + Reverb, Delay + Chorus, and Reverb + Chorus). Time – This knob sets the current delay time in milliseconds, from 20 ms to 000 ms.
Page 36 PRESETS The ProFX10 GO mixer allows you to access it for all kinds of information. This could be anything from hiking trail locations, hunting/ﬁshing/bird watching locations, and camping recipes. Furthermore, they are listed in day time and night time activities.
Page 37 Once the karaoke battle has concluded and the winner has received their trophy, feel free to check out the stars in the sky above. Yes, the ProFX10 GO works as a sky guide, as well... a map of the stars! The Delta Aquariids are meteor showers that may be viewed from Mount Rainier.
Page 38 Battery Replacement The Lithium-Ion Battery allows you to use a ProFX10 GO without the need to be plugged in or wasting money on expensive batteries. This is great for mobile gigging, live streaming, and more! SAFETY FIRST: Before installing and using this product, please read these instructions carefully.
Page 39 Replace the battery cover and lock it to the ProFX10 GO by pushing down on the cover until the tab ‘clicks’. When not in use, a spare battery (purchased separately) may be charged via USB cable. The USB-C side of the cable connects to the battery and the other side into a standard USB connector.
Page 40 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Hookup Diagrams Hookup Diagrams > Typical Live Sound System MUTE MUTE MUTE MUTE MUTE MUTE MUTE MUTE MUTE This diagram shows a guitar and bass attached to the channel and 2 line-level inputs, each via a mono e ects processor.
Page 41 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Hookup Diagrams > Typical Recording System MUTE MUTE MUTE MUTE MUTE MUTE MUTE MUTE MUTE Like the previous hookup diagram, this one also starts with a guitar and bass attached to the channel and 2 line-level inputs, each via a mono e ects processor.
Page 42 MUTE A family loves to go camping... but they also love to play music together. With Mackie ProFX10 GO, both are a possibility! Af er pitching a tent and grabbing ﬁrewood – but before snipe hunting – we would like to get everything connected.
Page 43 Troubleshooting If you think your Mackie product has a problem, please check out the following troubleshooting tips and do your best to conﬁrm the problem. Visit the Support section of our website (www.mackie.com) to get some ideas or contact our technical support heroes.
Page 44 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Noise / Hum • Are the EQs set to reasonable levels? • Are you using unbalanced cables? Swap them out with balanced cables to see if that ﬁxes the problem.
Page 45 Microphone Stand The bottom panel of the ProFX10 GO has three non-threaded holes that allow it to be ﬁtted with an optional microphone stand adapter. This lets you support the mixer on a standard mic stand, and adjust its height and level to whatever suits your strangely-complex set of preferences.
Page 46 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Appendix B : Technical Information Speciﬁcations Noise Characteristics Equivalent Input Noise (EIN) ( 50 Ω Source Impedance, 20 Hz to 20 kHz) Mic in to Insert Send out, max gain: ..............................– 26 dBu Residual Output Noise All outputs, master levels o , all channel levels o : ...........................–95 dBu...
Page 47 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Equalization Low: ....................................± 5 dB @ 80 Hz Mid: ....................................± 5 dB @ 2.5 kHz High: ....................................± 5 dB @ 2 kHz Low Cut Filter: ..................................
Page 48 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH Phantom Power 48 VDC to all Mic channels simultaneously Power Requirements Power Connector: ....................2V 2A Class I Hard-Wired Wall Mount Adapter [Output] 00VAC–240VAC, 50–60 Hz, 0.8A [Input] Battery Type: ......................................Lithium Ion...
Page 49 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH ProFX 0 GO Dimensions 10.6 in / 269 mm 11.5 in / 292 mm 3.8 in / 97 mm Weight 5.9 lb / 2.7 kg...
Page 50 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH ProFX 0 GO Block Diagram...
Page 51 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH ProFX 0 GO Track Sheet MUTE MUTE MUTE MUTE MUTE MUTE MUTE MUTE MUTE...
Page 52 Introduction The ProFX10 GO mixer allows you to send audio from the computer into either the USB /2 Blend Mix or the 3/4 Main Mix. USB /2 is most useful for overdubbing when recording, while 3/4 is typically used for backing tracks, streaming or game audio.
Page 53 You will need it to obtain any warranty service. For full terms and conditions, as well as the speciﬁc duration of the Warranty for this product, please visit www.mackie.com/warranty. The Product Warranty, together with your invoice or receipt, and the terms and conditions located at www.mackie.com/warranty constitutes the entire agreement, and supersedes any and all prior agreements between LOUD and Customer related to the subject matter hereof.
Page 54 MACKIE PROFX10 GO 10-CHANNEL BATTERY POWERED ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES, AND BLUETOOTH 9820 North Creek Parkway #20 , Bothell, WA 980 • USA Phone: 425.487.4333 • Toll-free: 800.898.32 Fax: 425.487.4337 • www.mackie.com...
