BEF320-3A
Operating Manual
This manual is provided to persons purchasing an
SPE machine and may not be reproduced in part or
full without written permission of
SPE International Ltd.
This manual provides the basic information required
and is only to be used as a guideline.
The SPE machines are manufactured and covered by
SPE design registrations granted and pending.
SPE International Ltd reserves the right to alter the
equipment design and specification as required
without notice.
The SPE product range is subject to amendment and
improvement as a result of ongoing research.
Honeyholes Lane, Dunholme, Lincoln LN2 3SU, England
Tel: +44 (0) 1673 860709 Fax: +44 (0) 1673 861119
Email:
sales@spe-int.com
BEF320-3A
Operating Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the BEF320-3A and is the answer not in the manual?

Questions and answers

Related Manuals for SPE BEF320-3A

Summary of Contents for SPE BEF320-3A

  • Page 1 Operating Manual BEF320-3A Operating Manual This manual is provided to persons purchasing an SPE machine and may not be reproduced in part or full without written permission of SPE International Ltd. This manual provides the basic information required and is only to be used as a guideline.
  • Page 2 BEF320-3A Operating Manual...
  • Page 3 WARNING Failure to follow this instruction may result in serious personal injury or death. SPE disclaims all responsibility for damage to persons or objects arising as a consequence of incorrect handling of the machine, failure to inspect the machine for damage or other faults that may influence the operation prior to starting work, or failure to follow the safety regulations listed or applicable to the job site.
  • Page 4 BEF320-3A Operating Manual INDEX Page No Starting Work General Operation Dust Control Maintenance Basic Maintenance Checklist Safety Accessories 9-11 Cutter Drum Set Up Spare Parts Breakdown Body Components Undercarriage Components Height Adjuster Components Drum Drive Components Hydraulic Tank Components Hydraulic Drive Components...
  • Page 5 BEF320-3A Operating Manual STARTING WORK CHECK the following prior to starting the equipment: - Check condition of cutter drum assembly - Check all bolts for tightness - Check drive belt condition and tension - Check drive pulleys are undamaged and clean...
  • Page 6 To control any dust created by the operation connect an industrial dust collector or vacuum to the 50mm port at the side of the machine. We recommend the SPE 316 for almost 100% dust control. In the absence of a dust control unit it is acceptable to spray water onto the surface or to feed water down the vacuum port.
  • Page 7 BEF320-3A Operating Manual MAINTENANCE PRIOR TO ANY MAINTENANCE OR ADJUSTMENT STOP ENGINE. After use: Clean the machine to remove all build up of dust and surface residues. Drum Removal: Remove bolts on side plate and then screw two bolts back into the two tapped holes in the side plate.
  • Page 8 BEF320-3A Operating Manual Cont’d …… Height Adjustment Maintenance: Ensure the height screw thread is cleaned and then lightly oiled. Periodically it should be removed and the female threaded section cleaned out and oiled. At the same time, the self- aligning bearing should be greased.
  • Page 9 BEF320-3A Operating Manual BASIC MAINTENANCE/CHECKLIST DAILY: (or every 8hrs to 10hrs) Check cutters Check flail shafts Check all bolts and nuts for tightness Check belt tension Clean air filter elements Check engine oil Check hydraulic oil level. Clean any debris from drum enclosure and ensure drum turns freely.
  • Page 10 Note: It is possible that the noise level produced by the BEF320 could exceed 90dbA. Personal noise protection must be worn. To control dust it is recommended that an SPE dust control unit/vacuum is fitted. Never leave the BEF320 unattended while in use. Always stop the engine and set the height adjustment fully up before leaving the machine.
  • Page 11 BEF320-3A Operating Manual ACCESSORIES Part number Description Application Hardened steel cutter with tungsten inserts, for all concrete texturing, scabbling, planing and grooving applications. Removal of Heavy duty drum complete with bridge deck and car park 32001 T.C.T. cutters and spacers.
  • Page 12 BEF320-3A Operating Manual ACCESSORIES For the removal of thermoplastic 20mm road/runway markings, rubber based deposits and cold plastic 80600N coatings from asphalt and Milling cutter: Tipped with concrete. tungsten carbide. Heavy duty drum complete with For use with various cutter 32000 flail shafts.
  • Page 13 BEF320-3A Operating Manual...
  • Page 14 BEF320-3A Operating Manual...
  • Page 15 BEF320-3A Operating Manual...
  • Page 16 BEF320-3A Operating Manual...
  • Page 17 BEF320-3A Operating Manual...
  • Page 18 BEF320-3A Operating Manual...
  • Page 19 BEF320-3A Operating Manual...
  • Page 20 BEF320-3A Operating Manual...
  • Page 21 BEF320-3A Operating Manual...
  • Page 22 BEF320-3A Operating Manual...
  • Page 23 BEF320-3A Operating Manual...
  • Page 24 BEF320-3A Operating Manual...
  • Page 25 BEF320-3A Operating Manual...
  • Page 27 BEF320-3A Operating Manual SPECIFICATION SHEET Specifications Type Diesel Part Number BEF320-3A Power Output (hp) Voltage Cycles Cutter head speed (rpm) Starter Manual Travel speed mtr/min 0-12 Machine Dimensions (mm) Length 1230 Width Height 1220 Weight (kg) c/w cutter drum Working width of cutters (mm)
  • Page 28 BEF320-3A Operating Manual RECORD OF NOISE AND VIBRATION ASSESSMENT Manufacturer: Type: Scarifier Model No. BEF 320-3A Diesel Motor: Yanmar Operation : Concrete floor surface Inserted Tool: TCT cutters Running Conditions: 1800 rpm HAV Note: Acoustic Associates HAND-ARM VIBRATION Frequency Weighted Energy Equivalent Accelerations (a...
  • Page 29 Conditions of Sale (copy attached). As despatch date Warranty start date: BEF320-3A Model: Serial no: Customer name: Customer Address: Manufacturer: SPE International Ltd Honeyholes Lane Dunholme Lincoln LN2 3SU England +44 (0) 1673 860709 Telephone: +44 (0) 1673 861119...
  • Page 30 BEF320-3A Operating Manual Declaration of Incorporation Certificat de incorporation Integratie certificaat Declaración de Incorporatción Declaração de Incorporação Dichiarazione Di Fabbricante Secondo Allegato llB Della Direttiva Macchine 2006/42/EC Einbauerklärung Bartell Morrison Inc. 170 Traders Blvd Mississauga, Ontario, Canada L4Z 1W7 Tel: 647-953-4100 EN Declare under our sole responsibility that the product to which this declaration relates is in conformity with the following standard(s) or other normative documents.
  • Page 31 IT Numero di seria la macchina IT Modello DE Seriennummer DE Modell Machine: BEF320 Multiplane Model: BEF320-3A EN The Technical Construction file is maintained at: Bartell Morrison Inc. FR Les fiches techniques de construction sont gardées à: 170 Traders Blvd.
  • Page 32 BEF320-3A Operating Manual EN Signature of Authorized Person: FR Signature de la personne autorisée: NL Handtekening van gemachtigd persoon: ES Firma de la persona autorizada: PT Assinatura de pessoa autorizada: IT Firma della persona autorizzata: Eric Campbell DE Unterschrift der verantwortlichen Person:...
  • Page 33 BEF320-3A Operating Manual CONDITIONS OF SALE The quotation overleaf and any order placed following such quotation are subject to the following conditions of sale in which SPE International Limited is referred to as the “Company”. Validity of quotation No order received from a customer by the Company shall constitute a contract until accepted in writing by the Company.
