QUICK CONSUMER
REFERENCE GUIDE
YOUR System: ADT Alarm Keyholder Response
Starting to use the PM10 Alarm Panel and Keypad
PM10 Control Panel
As a security feature, the status of your System is hidden from view
• To start using your System, push the "unset" key
your 4-Digit User Code or tap the screen on the Keypad.
• The Alarm Panel/ Keypad is now lit and you are ready to start using your System.
Setting Your System
Step 1
When leaving your home ensure that all protected doors/windows, including your
front door, are closed before setting your System.
Step 2
Set your System by:
Option 1:
The Keypad – by pressing the "set" key
entering your 4-Digit User Code.
Option 2:
The Alarm Panel – by pressing the "set" key
your 4-Digit User Code.
Step 3
You will hear a continuous beeping to remind you to leave the property via your
specified exit route. Your System will set only once the exit door is closed.
Step 4
The beeping stops and your System is now successfully set.
Keypad
on your Alarm Panel and enter
and presenting your KeyTag /or
on the Alarm Panel and entering
1
KeyTag
Advertisement
Table of Contents
Related Manuals for ADT PM10
Summary of Contents for ADT PM10
- Page 1 QUICK CONSUMER REFERENCE GUIDE YOUR System: ADT Alarm Keyholder Response Starting to use the PM10 Alarm Panel and Keypad PM10 Control Panel Keypad KeyTag As a security feature, the status of your System is hidden from view • To start using your System, push the “unset” key on your Alarm Panel and enter your 4-Digit User Code or tap the screen on the Keypad.
-
Page 2: Unsetting Your System
KeyTag or set/unset KeyTag. Your 4 digit PIN code will not work at this point. Important: Unsetting the alarm stops the Internal Siren ringing should the alarm be activated but will not interrupt the transmission of the alarm signal to the ADT Alarm Monitoring Centre. - Page 3 Changing/Deleting Master And User Codes Using the Alarm Panel only 1. If ADT Screen Saver is displayed press the ‘Open Padlock key followed by the manager code 2. The screen will now display ‘Ready’ 3. Press the ‘Forwards Button’ until the display shows ‘User Settings’. Press ‘OK’...
-
Page 4: Panic Alarm
Police.* (*ADT can only contact Police if your Panic Alarm has been issued with a Unique Reference Number – URN by your local Police. Intruder Alarm and Panic Alarm now must have two separate URNs for the Police to respond to your emergency.) - Page 5 Adding KeyTags Continued Step 11 The display will Show: ‘ENROLL NOW or ENTR ID:XXX-XXXX’ Step 12 Go to Remote Keypad with New Tag Step 13 Press the Open padlock followed by the master code/existing programmed Step 14 Press Full Set key locked padlock Button: Step 15 Hold the tag to the top left of the Remote Keypad to the key Tag icon...
- Page 6 Deleting KeyTags Step 1 On the Main Panel press Open Padlock and enter your master code to exit the screen saver Step 2 Press Step 3 The display will show: ‘User Settings’ Step 4 Press Step 5 Type in your master code Step 6 The display will show: ‘Set Zone Bypass’...
- Page 7 Adding Code Step 1 On the Main Panel press Open Padlock and enter your master code to exit the screen saver Step 2 Press Step 3 The display will show: ‘User Settings’ Step 4 Press Step 5 Type in your Code Step 6 The display will show: ‘Set Zone Bypass’...
- Page 8 Deleting Code Step 1 On the Main Panel press Open Padlock and enter your master code to exit the screen saver Step 2 Press Next Step 3 The display will show: ‘User Settings’ Step 4 Press Step 5 Type in your Code Step 6 The display will show: ‘Set Zone Bypass’...
-
Page 9: Changing Code
Changing Code Step 1 On the Main Panel press Open Padlock and enter your master code to exit the screen saver Step 2 Press Next Step 3 The display will show: ‘User Settings’ Step 4 Press Step 5 Type in your Code Step 6 The display will show: ‘Set Zone Bypass’... - Page 10 Bypass Zone This function allows a user to temporarily disable a device/zone from the System (for example, to disable a movement detector when a dog is left in the house). Zone bypass last for a one set period only and automatically switches off when the System in Unlocked.
- Page 11 Bypass Zone Continued Step 12 Press (OK) Step 13 The Display will Show:’<OK> To Bypass’ Step 14 Press Step 15 The zone is now bypassed Step 16 You can Bypass more zones by repeating process from Step 10 Step 17 To exit press the (Lock) and press (OK)
- Page 12 Review Bypass Continued Step 6 Type in your CODE Step 7 The display will show: ‘Set Zone Bypass’ Step 8 Press the (Next) Step 9 Until the display shows: ’Review Bypass’ Step 10 Press (OK) Step 11 The display will show: ’Bypass List’ Step 12 Press (OK)
- Page 13 Recall Bypass This Function to Removes (Recalls) the most recent Bypassed devices/zones. Step 1 Close all doors (including your entry/exit door), Press (Unlock) Step 2 If the panel shows ‘Enter Code’ type in CODE If the panel shows ‘Ready’ go to step 4. Step 4 Press (Next)
-
Page 14: Time Format
Time Format Step 1 On the Main Panel press Open Padlock and enter your master code to exit the screen saver Step 2 Press Next Step 3 The display will show: ‘User Settings’ Step 4 Press Step 5 Type in your Code Step 6 The display will show: ‘Set Zone Bypass’... - Page 15 Time Step 1 On the Main Panel press Open Padlock and enter your master code to exit the screen saver Step 2 Press Next Step 3 The display will show: ‘User Settings’ Step 4 Press Step 5 Type in your Master code Step 6 The display will show: ‘Set Zone Bypass’...
- Page 16 Date Step 1 On the Main Panel press Open Padlock and enter your master code to exit the screen saver Step 2 Press Next Step 3 The display will show: ‘User Settings’ Step 4 Press Step 5 Type in your Master code Step 6 The display will show: ‘Set Zone Bypass’...
-
Page 17: Preventing False Alarms
System. * Calls charged at the standard rate of a regular local or national landline number. Costs from mobiles may vary. ADT803 PM10-PDF / Issue 1 / August 16...
