- Page 1 Hive EV Charging EO Mini Pro 3 Installation Guide...
- Page 2 EO Mini Pro 3 Installation Guide Contents Before you start page 3 Charger installation page 4 Software setup page 9 Smart Charging page 12 Randomised Delay page 13 PEN fault detection page 14 Connection options page 14 Wi-Fi connectivity page 15 GSM –...
- Page 3 3 Find the Installer Details label within the rear housing (see below) and take a clear photo where you can read the text clearly. You will need to refer to this later. Note: Technical support is available from Hive at https:/ /hivehome.com/guides/ev-charging...
- Page 4 Please note the diagrams below and throughout this guide are based on the untethered version. Installation requirements remain the same for tethered chargers. 2 Place the base of the EO Mini Pro 3 in the installation location and make sure the surface is flat and level.
- Page 5 EO Mini Pro 3 Installation Guide If using Ethernet as a means of connecting to the client router, CT clamps need to be fed into the Mini Pro 3, then the second aperture can be drilled out and a suitable gland fitted.
- Page 6 EO Mini Pro 3 Installation Guide Attach the EO Mini Pro 3 base to the wall using the four screws provided. Make sure the charger is secure and flush against the wall. Use packing washers if necessary for a flush fit.
- Page 7 PCB boards together, as shown on the next page. NOTE: CT clamps are included with your Hive EO Mini Pro 3 and are recommended to be installed as per the above instructions. If you decide not to install CT clamps, you will need to ensure that Load...
- Page 8 14 Do not attach the fascia to the EO Mini Pro 3 until all testing is done. Complete all testing before closing the unit.
- Page 9 EO Mini Pro 3 Installation Guide 3 Software setup Power up the charger. You will see a hotspot with the name eo-xxxxxxxxxxxxxx – it may take a couple of minutes to appear. The hotspot expires after 10 minutes if no connection is made. You must power the charger down and back up again to reactivate the hotspot.
- Page 10 EO Mini Pro 3 Installation Guide Confirm charger settings. • Enter your installer details. Please note, failure to enter these details WILL invalidate the customer’s warranty. • Tap Save Tilt + Calibrate to confirm if you have changed any of these values.
- Page 11 EO Mini Pro 3 Installation Guide CT Types Source: An external source of energy. Site: Boundary point into a property which will contain the charger usage within it. Load: An external load to the charger that does not contain the charger usage.
- Page 12 These will be overridden by the Hive app. If the charger is going to be used as a non-smart charger, without the Hive app: Set the Default Profile to suit the customer’s requirements. Otherwise, they will only be able to charge outside of the periods set by the factory.
- Page 13 EO Mini Pro 3 Installation Guide 5 Randomised Delay There is a risk of overloading the grid if lots of people start or stop charging their EV at the same time. To avoid this, all EV chargers now have a Randomised Delay feature. This means that there will be a random delay of up to 10 minutes when customers start or stop charging, which will help the grid stay balanced.
- Page 14 7 Connection options The Hive EO Mini Pro 3 has been developed with three methods of connection to the Hive platform. During the installation, you should consult with the customer and choose the most effective method of communication that suits their home and the installation location.
- Page 15 8 Wi-Fi connectivity If the Hive EO Mini Pro 3 is to use Wi-Fi for its internet connection to the Hive platform, before fitting the device in place it is recommended that the strength and integrity of the Wi-Fi signal is checked. If a weak Wi-Fi signal is present, then there is a chance that the installation of the charging station may fail.
- Page 16 EO Mini Pro 3 Installation Guide Configuring a Wi-Fi connection If you are connecting the Hive EO Mini Pro 3 to a customer’s Wi-Fi, then please: Enable Wi-Fi In order to view the list of available Wi-Fi networks, click on the “Refresh List” button.
- Page 17 EO Mini Pro 3 Installation Guide Select the chosen network and then click on the “use as Wi-Fi SSID” button. This will then populate the “Wi-Fi SSID” text field, allowing the installer to enter the Wi-Fi password into the Wi-Fi PSK field.
- Page 18 Physical EO Mini Pro 3 installation is now complete. The customer can now log in to the Hive app to complete setup of the charger. If the customer has not received a charger PIN from Hive, then please follow the customer registration steps which follow.
- Page 19 EO Mini Pro 3 Installation Guide 10 Customer registration The customer needs to be registered with Hive to receive the PIN that is required to add their EO Mini Pro 3 charger to the Hive app. You can complete this by: •...
- Page 20 EO Mini Pro 3 Installation Guide Important installation information Topic Note Characteristics of power supply input Permanently connected to 230V Characteristics of power supply output Supplies 230V AC to the vehicle Normal environmental conditions Can be installed indoors or outdoors...
- Page 21 EO Mini Pro 3 Installation Guide Where the EO Mini Pro 3 includes internal 6mA DC leakage protection (DCL option), then a 30mA Type A RCD must be Measures for protection against fitted at the supply. Otherwise, a Type B RCD or equivalent electric shock should be used.
- Page 22 LED pulses blue Ready ready to charge* *Once the LED pulses blue, it may take up to a further 10 minutes for the charger to connect to the Hive platform, which enables control and smart functionality within the Hive app.
- Page 23 LED solid red Fault condition A fault has occurred The Hive EO Mini Pro 3 is updating to the latest LED pulsing blue and Firmware update firmware. Once complete, the charger will green...
