CONTROL PANEL DESCRIPTION

1. DISPLAY

2. FUNCTION BUTTONS

3. ROTATING /CONFIRMATION KNOB

• Rotate to set the duration, the power, the temperature(depending on models), and weight, to choose the food category and to adjust the

clock. Rotating right or left will increase or decrease value.

• Press knob to confirm parameter. When the last parameter is confirmed, the function goes in RUN.

4. START/STOP BUTTONS

MWF 259

MWF 258

MWF 255

Need help?

Do you have a question about the MWF 259 and is the answer not in the manual?

Questions and answers

Summary of Contents for Whirlpool MWF 259

Page 1 CONTROL PANEL DESCRIPTION MWF 259 MWF 258 MWF 255 1. DISPLAY 2. FUNCTION BUTTONS 3. ROTATING /CONFIRMATION KNOB • Rotate to set the duration, the power, the temperature(depending on models), and weight, to choose the food category and to adjust the clock.
Page 2 COOKING FUNCTIONS MICROWAVE (MANUAL) Microwave function is a manual function that allows to quickly cook or reheat food and beverages. For example setting the watt to 650 W and 5 min. duration: Press Microwave button. 800 W is default setting. Rotate knob to set the power level to 650 W.
Page 3 • For better result we recommend to let the food rest for at least 5 minutes. MWF 258 INSTRUCTION FOOD CATEGORY MWF 255 WEIGHT ACCESSORIES MWF 259 Meat 100-2000 g/ 50 g Minced meat, slices, chops, stew. MW Safe Dish Chicken 100-2000 g/ 50 g...
Page 4 FORCED AIR (MANUAL) This function allows you to obtain oven-baked dishes. Using a powerful heat element and fan, the cooking cycle is just like that of a tradition- al oven. Use this function to cook pastries, bakeries, meat, poultry, fishes etc. The cooking process will be preceded by a preheating phase of the oven in order to achieve the best possible cooking results.
Page 5 STEAM MENU (MWF 255 AND MWF 259 ONLY) This function allows you to obtain healthy and natural tasting dishes by cooking with steam. Use this function to steam cook food such as pasta, rice, vegetables and fish. You will be asked to set the boiling time for the rice and pasta according to your food package recommenda- tion.
Page 6 FOOD CATEGORY WEIGHT ACCESSORIES INGREDIENTS INSTRUCTION - Put 100 ml in the steamer and put the grid. - Place food on the grid, avoiding overlapping. Apples, Steam Fruit 150-500 g/50 g - Cook and after cooking let the product rest for peers few minutes.
Page 7 FOOD CATEGORY WEIGHT ACCESSORIES INGREDIENTS INSTRUCTION - Add the white fish fillet and basil to a food processor fitted with the blade attachment and blend just until it's broken down into small pieces. - Then put pink pepper and salt to the basil and 500 g white fish fillet white fish fillets.
Page 8 CRISP/CRISP FRY (MWF 258 AND MWF 259 ONLY) Manual Crisp This function allows to obtain a perfect browning on both top and bottom surfaces of foods, while cooking internally developing the perfect texture. Cooking function that uses microwave and grill. The crisp plate reaches the right temperatures that enable to cook and brown foods.
Page 9 FOOD CATEGORY WEIGHT ACCESSORIES INGREDIENTS INSTRUCTION Crisp Plate Manual Function Crisp Handle - Place the product on the crisp plate, avoiding overlappings. - Press auto cook button and select the program, French fries 200-400 g/50 g French fries then press Jet start button. - When required, turn the product.
Page 10 - Mix the ham and cheese. - Gently slice a lengthwise pocket into each chicken breast. - Stuff each breast with the ham and cheese mixture and secure with a skewer or a few 400 g chicken breast sliced, toothpicks. 50 g sliced cheese, - In a medium shallow bowl, add the flour, salt and 50 g sliced ham,...
Page 11 GRILL This function uses a powerful quartz grill to brown foods, creating a grill or a gratin effect. For example to grill food at Medium level for 3 minutes: Press Grill button. 1 is default setting. Rotate knob to change power level to 2. Press OK Knob to confirm.
Page 12 COMBI GRILL (MW + GRILL) This function combines Microwave and Grill heating, allowing you to cook gratin in less time. For example to combi grill food at 650 W power level for 3 minutes: Press Combi button. 1 is Combi Grill function. Press OK Knob to confirm.
Page 13 COMBI (MW + FC) This function combines Microwave and Forced Air cooking, allowing you to prepare oven-baked dishes in less time. Combi ( Microwave + Forced Air ) allows you to cook dishes like roast poultry, entire potatoes, lasagna, fish. Roasted meat and fruit cakes, sweets and pastries. For example to bake food at 350 W power level, 170℃...
Page 14 The Special menu is a convenient button that contains different functions that support the cooking process. Allowing you to make the Yogurt, Dough rise, Soften and Melt butter, Ice cream, Cream cheese, etc. For example to soften 250 g butter with MWF 259 model: Press Special button.
Page 15 2 g of salt. Kneadwell until a dough is formed. This function can be used with any other dough recipe. • For better result we recommend to use this function for 250-500 g dough rising. FOOD CATEGORY MWF 255 MWF 258 MWF 259 WEIGHT ACCESSORIES Keep Warm Roast beef 600- 1400g...
Page 16 KEEP WARM (MWF 255 & MWF 258 ONLY) The Keep Warm function is used only to keep warm Roasted beef and Pizza. For example to keep warm 350 g pizza with MWF 255 model: Press Keep Warm button. P1 is default setting. Rotate knob to P2.
Page 17 • The Grill element does not need cleaning since the intense heat will burn off any splashes, but the ceiling beneath it may need regular cleaning. This should be done with a soft and damp cloth with mild detergent. ACCESSORIES MWF 255 / MWF 259 MWF 258 Steamer bottom...
Page 18 Place food onto a microwave safe dish or high rack, low rack, MW safe dish or crisp plate(according to the indication provided for each recipe). For example to cook ready mix cake with MWF 259 model: Press 6th Sense Menu button.
Page 19 Model MWF 258 and MWF 259 refer to below table: FOOD WEIGHT ACCESSORIES INGREDIENTS INSTRUCTION CATEGORY C1 Convenience MW safe cake tin - Put the mix into the cake tin and place it into the (not provided) cavity. Ready mix cake...
Page 20 INGREDIENTS INSTRUCTION FOOD CATEGORY WEIGHT ACCESSORIES - Put the crisp plate into the cavity in order to perform the preheat. - Combine eggs, salt, pepper, and herbs in a medium bowl and whisk until homogeneous and frothy, about Crisp Plate 1 minute.
Page 21 INGREDIENTS INSTRUCTION FOOD CATEGORY WEIGHT ACCESSORIES Crisp Plate - Place asparagus on the crisp plate and put it into the cavity. - Cook. 1 serving : 1-4 servings/ - When required open the door, add the eggs over the Eggs and asparagus 1 egg, 1 serving 100 g asparagus...
Page 22 INGREDIENTS INSTRUCTION FOOD CATEGORY WEIGHT ACCESSORIES - Wash, dry and pierce with a fork the potatoes. - Then put them in a safe mw plate. 1 kg potatoes 1-4 servings/ - Cook and turn when required. Baked potatoes medium size not 1serving - At the end of cooking time, let potatoes to cool peeled,...
Page 23 INGREDIENTS INSTRUCTION FOOD CATEGORY WEIGHT ACCESSORIES C5 Fish/seafood - Place the fish fillet on the crisp plate and put it in the 150-500 g/ cavity of the oven. White Fish Fillets White fish fillet - Cook. 50 g - When required, turn the product 400 g cod fillets, - In a bowl mix the breadcrumbs with the herbs, oil, salt 30 g breadcrumbs,...
Page 24 INGREDIENTS INSTRUCTION FOOD CATEGORY WEIGHT ACCESSORIES - Put the crisp plate into the cavity in order to perform the preheat. 100-400 g/ - When it finishes, place the burgers on the crisp plate Burgers Burgers 100 g Crisp Handle and put it in the cavity of the oven. - Cook When required, turn the product.
Page 25 INGREDIENTS INSTRUCTION FOOD CATEGORY WEIGHT ACCESSORIES C7 Dessert and Pastry - Grease and flour the crisp plate Crisp Plate - Mix butter and sugar until mounting them, add eggs 100 g dark cocoa, 200 g wheat flour, 200 g and mount again. - Mix flour, cocoa and baking powder together and add butter, Chocolate and pear...
Page 26 INGREDIENTS INSTRUCTION FOOD CATEGORY WEIGHT ACCESSORIES Crisp plate on low rack - Mix butter and sugar until mounting them, add eggs 200 g flour, and mount again. 180 g sugar, - Add flour and yeast. 4 eggs, 200 g cherry - Place the dough in the crisp plate and put on the tip Pie (e.g.
Page 27 INGREDIENTS INSTRUCTION FOOD CATEGORY WEIGHT ACCESSORIES C8 Baby menu - In a safe MW glass or bottle, put milk stored at room temperature. - Remove teats. - Press auto cook button and select the program, then MW safe bottle (Not Milk Reheat from 100-500 ml / press Jet start button.
Page 28 Model MWF 255 refer to below table: FOOD CATEGORY WEIGHT ACCESSORIES INGREDIENTS INSTRUCTION C1 Breakfast High Rack - Place the products directly on the high rack. Toast - Cook. 40-80 g/ 40 g Bread slices by 20 g each - Turn when required. - Mix all the ingredients.
Page 29 FOOD CATEGORY WEIGHT ACCESSORIES INGREDIENTS INSTRUCTION C3 Healthy/vegs 200 g potatoes in cubes, 100 g broccoli, - Wash, dry and pierce with a a fork the potatoes. 1 mature tomato cut in Then put them in a safe mw plate. cubes, - Cook and turn when required.
Page 30 FOOD CATEGORY WEIGHT ACCESSORIES INGREDIENTS INSTRUCTION - Mix flour and salt in a bowl. - Cut cold butter thinly and put them into the flour mixture, making sure each slice of butter is evenly coated. - Pour in the water and stir until the dough forms 200 g flour, a ball.
Page 31 FOOD CATEGORY WEIGHT ACCESSORIES INGREDIENTS INSTRUCTION - Add warm water to yeast to the bowl, and stir to combine. - Add gradually flour, olive oil and salt and continue mixing the dough for 5-10 minutes. - Let it rest for 45-60 minutes in a warm place. - Turn the dough onto a floured surface, roll it out Baking Plate(not 200g flour,...
