VYPER
USER'S GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the VYPER and is the answer not in the manual?

Questions and answers

Related Manuals for Suunto VYPER

Summary of Contents for Suunto VYPER

  • Page 1 VYPER USER’S GUIDE...
  • Page 2 Maximum Depth Arrows: Ceiling Depth on Decompression - Decompression Stop at the Ceiling Depth Mandatory Safety Stop Depth - Mandatory Safety Stop Zone Average Depth on Logbook - Ascent Recommended Oxygen Partial Pressure - Must Descend AM/PM Indicator Present Depth Safety Stop Warning Dive Counter Safety Stop Indicator...
  • Page 3 1. WELCOME TO THE WORLD OF SUUNTO DIVE COMPUTERS ....7 2. WARNINGS, CAUTIONS, AND NOTES ..........8 3. SUUNTO USER INTERFACE ............17 3.1. Navigating in the menus ............17 3.2. Button symbols and functions ........... 18 4. GETTING STARTED ..............21 4.1.
  • Page 4 5.7.3. Battery power indication ............ 46 5.7.4. Diving at altitude ............. 47 5.7.5. Personal adjustments ............48 5.8. Safety Stops ............... 50 5.8.1. Recommended Safety Stops ..........51 5.8.2. Mandatory Safety Stops ............ 52 6. DIVING .................. 54 6.1. Diving in AIR mode ............... 54 6.1.1.
  • Page 5 7.6. Simulation Mode [SIMUL] ............90 7.6.1. Dive Simulator [1 SIMDIVE] ..........91 7.6.2. Dive Planning Simulator [2 SIMPLAN] ........92 8. CARE AND MAINTENANCE OF MY SUUNTO DIVING COMPUTER ..94 9. BATTERY REPLACEMENT ............97 9.1. Battery kit ................97 9.2.
  • Page 6 12.2. EN 13319 ............... 113 12.3. EN 250 / FIOH ..............113 13. SUUNTO LIMITED WARRANTY ..........114 14. DISPOSAL OF THE DEVICE ............116 GLOSSARY ................117...
  • Page 7 1. WELCOME TO THE WORLD OF SUUNTO DIVE COMPUTERS Suunto Vyper dive computer is designed to help you get the most out of your diving. The Vyper dive computer is a compact and sophisticated multipurpose dive instrument that will give you years of trouble-free and joyful diving.
  • Page 8 Before you go on to read the user's guide itself, it is extremely important that you read the following warnings. These warnings are intended to maximize your safety while using Suunto Vyper and must not be ignored. YOU MUST READ the leaflet and user guide for your dive com- WARNING puter.
  • Page 9 (DCI). Therefore, Suunto strongly recommends that the device not be used for any commercial or professional diving activities. ONLY DIVERS TRAINED IN PROPER USE OF SCUBA DIVING...
  • Page 10 SUUNTO STRONGLY RECOMMENDS THAT SPORT DIVERS WARNING LIMIT THEIR MAXIMUM DEPTH TO 40 M/130 FT OR TO THE DEPTH CALCULATED BY THE COMPUTER BASED ON THE SELECTED O % AND A MAXIMUM PO OF 1.4 BAR! Exposure to greater depths increases the risk of oxygen toxicity and decom- pression illness.
  • Page 11 YOU ARE ADVISED TO AVOID FLYING ANY TIME THE COM- WARNING PUTER COUNTS DOWN THE NO-FLY TIME. ALWAYS ACTIV- ATE THE COMPUTER TO CHECK THE REMAINING NO-FLY TIME PRIOR TO FLYING! Flying or traveling to a higher altitude within the no-fly time can greatly increase the risk of DCI. Review the recommendations given by Divers Alert Network (DAN).
  • Page 12 THE DIVE COMPUTER WILL NOT ACCEPT FRACTIONAL WARNING PERCENTAGE VALUES OF OXYGEN CONCENTRATION. DO NOT ROUND UP FRACTIONAL PERCENTAGES! For example, 31.8% oxygen should be entered as 31%. Rounding up will cause nitrogen percentages to be understated and will affect decompres- sion calculations.
  • Page 13 SET THE CORRECT PERSONAL ADJUSTMENT MODE! WARNING Whenever it is believed that factors that tend to increase the possibility of DCI exist, it is recommended that you use this option to make the calculations more conservative. Failure to select the correct Personal Adjustment setting will result in erroneous dive and planning data.
  • Page 14 NEVER ASCEND ABOVE THE CEILING! You must not ascend WARNING above the ceiling during your decompression. In order to avoid doing so by accident, you should stay somewhat below the ceiling. DO NOT DIVE WITH A CYLINDER OF ENRICHED AIR IF YOU WARNING HAVE NOT PERSONALLY VERIFIED ITS CONTENTS AND ENTERED THE ANALYSIS VALUE INTO YOUR DIVE COM-...
  • Page 15 Insufficient or improper training may cause a diver to commit errors that may lead to serious injury or death. Using the Suunto Dive Planner software is not a substitute for WARNING proper dive training. Diving with mixed gases has dangers that are not familiar to divers diving with air.
  • Page 16 ENSURE THE WATER RESISTANCE OF THE DEVICE! Moisture WARNING inside the device or battery compartment will seriously damage the unit. Only an authorized SUUNTO dealer or distributor should do service activities. It is not possible to change between AIR, NITROX and GAUGE NOTE modes before the instrument has counted down the no-fly time.
  • Page 17 3. SUUNTO USER INTERFACE 3.1. Navigating in the menus Suunto Vyper multipurpose dive computer features three dive computer modes (AIR, NITROX, GAUGE), three main operating modes (TIME/STAND-BY, SURFACE, DIVING), three menu based main modes (MEMORY, SIMULATION, SET) and 15–17 menu based submodes. You can scroll through the modes using the push buttons.
  • Page 18 Figure 3.1. Time keeping display. Press the PLAN or TIME button to activate the display. 3.2. Button symbols and functions The list below explains the main functions of the dive computer's buttons. The buttons and their use is explained in more detail in the relevant sections of the user's guide. The dive computer has easy-to-use push buttons and an advising display, which guides the user.
  • Page 19 Figure 3.2. Push buttons of the dive computer. SMART (MODE) button Activates the dive computer • Switches from the Surface mode to menu based modes • Selects, confirms or quits a submode (short press) • Immediately exits any submode to the Surface mode (long press) •...
  • Page 20 Activates the Time display(s) and/or alternative display(s). • Scrolls down the options ( decreases values) • The dive computer is controlled with the SMART (MODE/On/Backlight/Select/ OK/Quit) and the PLAN and TIME push buttons and with the water contacts as follows: Activation: Press the SMART (On) button or immerse the instrument in water for five (5) seconds.
  • Page 21 4. GETTING STARTED To get the most out of your Suunto Vyper , use some time to personalize it and really make it YOUR computer. Set the correct time and date, the alarms, and backlight settings. The main menu based functions are grouped under 1) memory, 2) dive simulation and 3) setting modes.
  • Page 22 • Dive Planning Simulator [2 SIMPLAN] SET MODES [3 SET] • Dive Parameter Settings [1 SETDIVE] • Altitude Adjustment and Personal Adjustment Settings [1 AdJ MODE] • Dive Time Alarm Setting [2 d ALARM] • Maximum Depth Alarm Setting [3 MAX DPTH] •...
  • Page 23 THE USE OF THE MENU BASED FUNCTIONS Activate the menu based modes by pressing once the SMART (MODE) button in the Dive Mode. Figure 4.1. Main menu based Mode options [3 MODE] Scroll the mode options by pressing the arrow up/ down buttons. When scrolling the options, the label and an equivalent number are shown on the display.
  • Page 24 Figure 4.2. Scroll the mode options by pressing the arrow up/ down buttons. Press the SMART (Select) button once to select the desired option. Scroll the submode options by pressing the arrow up/down buttons. When scrolling the options, the label and an equivalent number are shown on the display. Select the desired option by pressing once the SMART (Select) button.
  • Page 25 By pressing the SMART button for more than 1 second, any menu based function or submode can be quit and the dive computer will return directly to the Dive Mode. 4.1. SET MODES [3 SET] The Set Modes include dive configuration and setup options that have to be set before the dive.
  • Page 26 4.1.1. Setting Time [2 SET TIME] To enter the Time Setting mode, select MODE- 3 SET- 2 SET TIME. The Time Setting mode has three options: 1 AdJ Time, 2 AdJ Date, and 3 T ALARM Daily Time Alarm. Figure 4.4. Time Setting Mode [2 SET TIME] Adjusting Time [1 AdJ TIME] To enter the Time Setting mode, select MODE- 3 SET- 2 SET TIME- 1 AdJ TIME.
  • Page 27 Figure 4.5. Adjusting the Time setting. Adjusting Date [2 AdJ DATE] To enter the Date Setting mode, select MODE- 3 SET- 2 SET TIME- 2 AdJ DATE. After entering this mode you are able to set the correct year, month and day in this order.
  • Page 28 Figure 4.6. Adjusting the Date setting mode [2 AdJ DATE]. Adjusting Daily Alarm [3 T ALARM] You can set one daily alarm in the dive computer. When the daily alarm activates, the time symbol blinks for 1 minute and the alarm sounds for 24 seconds. The alarm is given at the preset time each day.
  • Page 29 Figure 4.7. Adjusting the Daily Alarm setting mode [3 T ALARM] 4.1.2. Setting Preferences [3 SET PREF] To enter the Setting Preferences mode, select MODE- 3 SET- 3 SET PREF. The Setting Preferences mode has two options: 1 LIGHT and 2 MODEL. Backlight On Time Setting [1 LIGHT] In the Backlight Setting mode the backlight can be turned off or on and the on time can be set to be 5 to 30 seconds.
  • Page 30 Figure 4.8. Setting Backlight On Time. Press scroll buttons to change backlight on/off and to set time value. Dive Computer Model Settings (Air/Nitrox/Gauge) [3 MODEL] In the Dive Computer Model Setting mode the dive computer can be set to be an AIR computer, NITROX computer or a depth GAUGE with a timer.
  • Page 31 Figure 4.9. Setting Dive Computer model 4.2. AC water contacts The water contacts control the automatic activation of the Dive Mode. The water and data transfer contacts are located on bottom of the case. When sub- merged the water contacts are connected to the push buttons (which are the other pole of the water contact) by the conductivity of the water.
  • Page 32 Figure 4.10. Depth sensor (A), water/data transfer contacts (B)
  • Page 33 It is a significant advance on the classic Haldane models, which do not predict free gas. The advantage of Suunto RGBM is additional safety through its ability to adapt to a variety of situations and dive profiles.
  • Page 34 5.2. Emergency ascents In the unlikely event that the dive computer malfunctions during a dive, follow the emergency procedures provided by your certified dive training agency or, alternatively, follow these steps: Assess the situation calmly and then move promptly to less than 18 m/60 ft. At 18 m/60 ft, slow down your ascent rate to 10 m/33 ft per minute and move to a depth between 3 and 6 m/10 and 20 ft.
  • Page 35 Table 5.1. Audible and visual alarm types Alarm type Alarm reason Short single beep Dive computer is activated. Dive computer automatically returns to the TIME mode. Three single beeps with a two No-decompression dive turns into a decompression second interval and activated stop dive.
  • Page 36 Table 5.2. Preset alarm types Alarm type Alarm reason Continuous beep series for 24 seconds or until any Preset maximum depth has button is pressed. been exceeded. Maximum depth blinks as long as the current depth value exceeds the preset value. Continuous beep series for 24 seconds or until any Preset dive time has been ex- button is pressed.
  • Page 37 Table 5.3. Oxygen alarms in NITROX mode Alarm type Alarm reason Three double beeps and the The OLF bar graph reaches 80%. The segments ex- backlight for five (5) seconds ceeding the 80% limit start to blink. The OLF bar graph reaches 100%. The OLF value will blink.
  • Page 38 5.5. Error conditions The dive computer has warning indicators that alert you to react to certain situations that would significantly increase the risk of DCI. If you do not respond to its warnings, the dive computer will enter an Error mode, indicating that the risk of DCI has greatly increased.
  • Page 39 5.6. DIVE mode settings Suunto Vyper has several user-definable functions, as well as depth and time-related alarms that you can set according to your personal preferences. The DIVE mode settings are dependent on the dive submode chosen (AIR, NITROX, GAUGE), so that, for example, settings are only available in the submode.
  • Page 40 5.6.1. Setting the personal/altitude adjustments [1 AdJ MODE] The current Altitude and Personal Adjustment settings are displayed in the startup screen when diving at the surface. If the mode does not match the altitude or personal conditions (refer to Section 5.7.4. Diving at altitude and Section 5.7.5. Personal adjust- ments), it is imperative that you enter the correct selection before diving.
  • Page 41 5.6.2. Setting the dive-time alarm [2 d ALARM] The Dive Time Alarm setting [2 d ALARM] can be activated and used for several pur- poses to add to your diving safety. To enter the Dive Time Alarm Setting mode, select MODE- 3 SET- 1 SET DIVE- 2 d ALARM.
  • Page 42 To enter the Maximum Depth Alarm Setting, select MODE- 3 SET- 1 SET DIVE- 3 MAXDPTH. Figure 5.3. Setting Maximum Depth Alarm. Press scroll buttons to change alarm on/off and to set maximum depth value. 5.6.4. Setting the nitrox values [4 NITROX] If set to the NITROX mode, the correct oxygen percentage of the gas in your cylinder must always be entered into the computer to ensure correct nitrogen and oxygen calculations.
  • Page 43 5.7.1. Accessing DIVE mode The Suunto Vyper has three diving modes: AIR mode for diving with standard air only, NITROX mode for diving with oxygen enriched mixtures, and GAUGE mode for use...
  • Page 44 5.7.2. DIVE mode activation The dive computer activates automatically when submerged deeper than 0.5 m/1.5 ft. However, it is necessary to activate the DIVE mode BEFORE diving to check the altitude and personal adjustment settings, battery condition, oxygen settings, and so on. Press the SMART (On) button to activate the instrument. Figure 5.5.
  • Page 45 Figure 5.6. Startup II. Battery power indicator. At this time, perform your pre-checks, and ensure that: • the instrument operates in the correct mode and provides a complete display (AIR/NITROX/GAUGE mode) the low battery indicator is not on. • the altitude and personal adjustment settings are correct. •...
  • Page 46 The surface interval time is not shown before the first dive. NOTE After activation of the Dive mode or after the dive has ended, the instrument will automatically switch to show the time keeping display within 5 minutes to conserve the battery power, unless you press any buttons or start a dive.
  • Page 47 Figure 5.7. Low Battery Warning. Battery symbol indicates that the battery is low and battery replacement is recommended. If the battery symbol is displayed in the Surface mode, or if the display is faded or weak, the battery may be too low to operate the dive computer, and battery replacement is recommended.
  • Page 48 Table 5.4. Altitude Adjustment settings Alt. adjustment Symbol on display Altitude range value 0–300 m / 0–1000 ft 300–1500 m / 1000–5000 ft 1500–3000 m / 5000–10 000 ft Section 5.6.1. Setting the personal/altitude adjustments [1 AdJ NOTE MODE] describes how the Altitude value is set. Traveling to a higher elevation can temporarily cause a change WARNING in the equilibrium of dissolved nitrogen in the body.
  • Page 49 The personal factors which tend to increase the possibility of DCI include, but are not limited to: cold exposure —water temperature less than 20 °C/68 °F • below average physical fitness level • fatigue • dehydration • • previous history of DCI stress •...
  • Page 50 The reasons for performing a Safety Stop in- clude: reducing sub-clinical DCI, microbubble reduction, ascent control, and orientation before surfacing. The Suunto Vyper displays two different types of Safety Stops: Recommended Safety Stop and Mandatory Safety Stop. The Safety Stops are indicated by: STOP label, when in the depth range 3–6 m/10–20 ft = Recommended Safety Stop...
  • Page 51 STOP + CEILING label, when in the depth range 3–6 m/10–20 ft = Mandatory • Safety Stop Time display STOP label, when deeper than 6 m = Mandatory Safety Stop scheduled • 5.8.1. Recommended Safety Stops With every dive over 10 meters, there is a three-minute countdown for the Recommen- ded Safety Stop, to be taken in the 3–6 m/10–20 ft range.
  • Page 52 (5) seconds, the microbubble build-up is predicted to be more than is allowed for in the decompression model. The Suunto RGBM calculation model responds to this by adding a Mandatory Safety Stop to the dive. The time of this Mandatory Safety Stop depends on the severity of the ascent rate excess.
  • Page 53 You must not ascend shallower than 3 m/10 ft with the Mandatory Safety Stop warning on. If you ascend above the Mandatory Safety Stop ceiling, a downward pointing arrow will appear and a continuous beeping starts. You should immediately descend to, or below, the Mandatory Safety Stop ceiling depth.
  • Page 54 6. DIVING This section contains instructions on how to operate the dive computer and interpret its displays. The dive computer is easy to use and read. Each display shows only the data relevant to that specific diving mode. 6.1. Diving in AIR mode This section contains information on diving with standard air.
  • Page 55 The dive computer will remain in the SURFACE mode at depths NOTE less than 1.2 m/4 ft. At depths greater than 1.2 m/4 ft the instru- ment will go into the DIVE mode automatically. However, it is re- commended that you activate the SURFACE mode manually before entering the water in order to perform the necessary dive pre-checks.
  • Page 56 Bookmarks will be shown as a dive log symbol when scrolling the profi le memory on the computer display. The Bookmarks will also be shown as annotations in the PC- software, Suunto Dive Manager. To make a bookmark on the profile memory during a dive press the PLAN button.
  • Page 57 200 minutes, the first (lowest) bar graph segment appears. As your body absorbs more nitrogen, more segments start to appear. Green Zone– As a safety precaution Suunto recommends you should maintain the no-decompression bar graph within the green zone. Segments start to appear when the available no-decompression time decreases below 100, 80, 60, 50, 40, 30, and 20 minutes.
  • Page 58 Red Zone– As all of the bars appear (red zone), your no-decompression stop time has become zero and your dive has become a decompression stop dive (for more information see Section 6.1.5. Decompression dives). 6.1.4. Ascent rate indicator The ascent rate is displayed graphically along the right hand side with a vertical bar. When the maximum allowed ascent rate is exceeded, the fifth SLOW warning segment and the STOP sign appear and the depth reading starts to blink, indicating that the maximum ascent rate has been exceeded continuously or that the current ascent rate...
  • Page 59 When the maximum allowed ascent rate is exceeded the fifth SLOW warning segment and the STOP sign appear and the depth reading starts to blink indicating that the maximum ascent rate has been exceeded continuously or that the ascent rate is above the allowed maximum rate.
  • Page 60 DO NOT EXCEED THE MAXIMUM ASCENT RATE! Rapid as- WARNING cents increase the risk of injury. You should always make the Mandatory and Recommended Safety Stops after you have ex- ceeded the maximum recommended ascent rate. If this Mandatory Safety Stop is not completed, the decompression model will penalize your next dive(s).
  • Page 61 If you exceed the no-decompression limits on a dive, the dive computer will provide the decompression information required for ascent. After this, the instrument will continue to provide subsequent interval and repetitive dive information. Rather than requiring you to make stops at fixed depths, the dive computer lets you decompress within a range of depths (continuous decompression).
  • Page 62 Ceiling, ceiling zone, floor and decompression range When in decompression, it is important that you understand the meaning of ceiling, floor, and decompression range. The ceiling is the shallowest depth to which you should ascend when in decom- • pression. At this depth, or below, you must perform all stops. The ceiling zone is the optimum decompression stop zone.
  • Page 63 In such cases, it is more manageable to maintain an additional distance below the ceiling, to ensure that the waves do not lift you above the ceiling. Suunto recom- mends that decompression takes place deeper than 4 m/13 ft, even if the indicated ceiling is shallower.
  • Page 64 Figure 6.7. Decompression dive, below floor. Upward pointing arrow, blinking ASC TIME label and an audible alarm tell you to ascend. Minimum total ascent time including safety stop is 7 minutes. Ceiling is at 3 m/10 ft. Display above the floor When you ascend above the floor, the ASC TIME sign stops blinking and the upward pointing arrow disappears.
  • Page 65 Figure 6.8. Decompression dive, above the floor. The upward pointing arrow has disappeared and the ASC TIME label has stopped blinking, which means that you are in the decompression range. Decompression will now begin, but is very slow. Therefore, you should continue your ascent.
  • Page 66 Figure 6.9. Decompression dive, at ceiling zone. Two arrows point at each other (“hour glass”). You are in the optimum ceiling zone at 3.5 m/11 ft and your minimum ascent time is 5 minutes. Pressing TIME button activates alternative display. During the decompression stop, ASC TIME will count down towards zero.
  • Page 67 Figure 6.10. Decompression dive, above ceiling. Note a downward pointing arrow, an Er warning and an audible alarm. You should immediately (within 3 minutes) descend to or below ceiling. In addition, an Error warning (Er) reminds you that you have only three (3) minutes to correct the situation.
  • Page 68 6.2.1. Before diving in the NITROX mode If set to the NITROX mode, the correct oxygen percentage of the gas in your cylinder must always be entered into the computer to ensure correct nitrogen and oxygen calculations. The dive computer adjusts its mathematical nitrogen and oxygen calcu- lation models accordingly.
  • Page 69 In the NITROX mode, the maximum operational depth is calculated based on set O % and PO values. If set to the NITROX mode, the Suunto will additionally show on the alternative display: the oxygen percentage, labeled O • the set oxygen partial pressure limit, labeled PO •...
  • Page 70 In the Dive modes, the oxygen percentage labeled with O % and the current oxygen toxicity exposure shown with an Oxygen Limit Fraction (OLF) bar graph are shown (Fig. 3.22. and Fig. 3.23.). The O % is shown until the remaining air time is less than 30 minutes.
  • Page 71 • maximum depth (during decompression stop dive) Figure 6.13. Alternative display. Pressing the TIME button displays the current time, maximum depth and CBT. After five seconds, the display will automatically revert to the original display. 6.2.3. Oxygen limit fraction (OLF%) If set to the NITROX mode, in addition to tracking the diver's exposure to nitrogen, the instrument tracks the exposure to oxygen.
  • Page 72 The Oxygen Limit Fraction (OLF) has 11 segments, each representing 10%.The Oxygen Limit Fraction (OLF%) displays only the value of the higher of the two calcu- lations. The oxygen toxicity calculations are based on the factors listed in Section 10.3. Oxygen exposure .
  • Page 73 6.3. Diving in the GAUGE mode If set to Gauge mode, the dive computer can be used for diving with technical diving mixed gases. If you are trained for technical diving and you plan to use Gauge mode on a regular basis, it may be preferable to set the instrument permanently to its Gauge mode.
  • Page 74 If you dive with the GAUGE mode, it is not possible to change NOTE between the modes before the no fly time has counted down.
  • Page 75 7. AFTER DIVING Once back at the surface, Suunto Vyper continues to provide post-dive safety inform- ation and alarms. Calculations to enable repetitive dive planning also help to maximize diver safety. Table 7.1. Alarms Symbol on display Indication Diver Attention Symbol - Extend Surface Interval...
  • Page 76 Figure 7.1. Surface display. You have surfaced from a 18 minute dive, which maximum depth was 20.0 m/66 ft. The present depth is 0.0 m/0 ft. The Airplane symbol indicates that you should not fly and diver attention symbol indicates that you should prolong your surface interval time.
  • Page 77 Figure 7.2. Surface interval, the surface time and no-flying time displays: Pressing the TIME button once the surface time display is shown and by pressing the TIME button twice the no-flying time display is shown, indicated by the airplane symbol. Or when the TIME button is pressed once or twice: •...
  • Page 78 7.2. Dive numbering Several repetitive dives are considered to belong to the same repetitive dive series when the dive computer has not counted the no-fly time to zero. Within each series, the dives are given individual numbers. The first dive of the series will be numbered as DIVE 1, the second as DIVE 2, the third as DIVE 3, and so on.
  • Page 79 Following any dive that required a decompression stop, flying should be delayed • for at least 24 hours, and if possible, for 48 hours. Suunto recommends that flying is avoided until all the DAN and UHMS guidelines, • as well as the dive computer’s no-fly conditions, are satisfied.
  • Page 80 Figure 7.3. Memory options [3 MEMORY]. 7.4.1. Logbook and Dive Profile Memory [1 LOGBOOK]) The Suunto Vyper has a very sophisticated, high capacity Logbook and Profile Memory. The data is recorded in the profile memory based on the selected sample rate.
  • Page 81 Figure 7.4. Logbook, end of the memory. END text is displayed between oldest and the most recent dive. Page I, main display date of dive • dive start time • dive number •...
  • Page 82 Figure 7.5. Logbook, page I. Scroll different pages of specific dive. Page II maximum depth • Due to lower resolution, the reading may differ from the max- NOTE imum depth reading of the Dive History up to 0.3 m /1 ft total dive time •...
  • Page 83 downward pointing arrow, if the ceiling was violated • oxygen percentage (only in Nitrox mode) • maximum OLF during the dive (only in Nitrox mode) • Figure 7.6. Logbook, page II. Main dive related data. Page III • dive number in the dive series average depth •...
  • Page 84 Figure 7.7. Logbook, page III. Surface interval time and average depth. Page IV • dive number in the dive series • the profile of the dive profile, automatic scrolling during which: logbook symbol blinks when the user has pressed the PLAN button for Bookmark •...
  • Page 85 Figure 7.8. Logbook, page IV. Profile of a specific dive. Press the SMART (Select) button once to change the scroll buttons to scroll the different dives forward and backward. Press the SMART (>Select) button again to change function of the scroll buttons back to scroll the different pages of the selected dive. When searching the dives, only the page 1 is shown.
  • Page 86 Dive Profile memory [PROF] The scrolling of the profile will start automatically when the Logbook page IV (PROF) is entered. With the default setting, the dive profile is recorded and displayed in 20- second increments with each display being shown for about three seconds. The depths shown are the maximum values of each interval.
  • Page 87 The Dive History Memory can hold a maximum of 999 dives and 999 diving hours. When these maximum values are reached, the counters will start again from zero. The maximum depth can be reset to 0.0 m/0 ft using the PC Inter- NOTE face unit and the downloadable Suunto Dive Manager software.
  • Page 88 The Suunto DM4 with Movescount (DM4) is an optional software that greatly enhances the functionality of your Suunto Vyper. With the DM4 software, you can download dive data from your dive computer to your laptop. After that, you can view and organize all the data recorded with your Suunto .
  • Page 89 To connect to Movescount: Go to www.movescount.com. Register and create your free Movescount account. Download and install the Suunto DM4 with Movescount software from the Movescount.com website if you do not already have the DM4 installed on your laptop...
  • Page 90 To transfer data: Connect your dive computer to your laptop. Download your dives to the DM4 on your laptop. Follow the instructions on the DM4 on how to transfer your dives to your Movescount.com account. 7.6. Simulation Mode [SIMUL] The Simulation mode can be used to acquaint yourself with the features and displays of the instrument before diving, to plan dives in advance, for demonstration or education purposes, or just for pleasure.
  • Page 91 7.6.1. Dive Simulator [1 SIMDIVE] The Dive Simulator mode is an excellent tool for becoming familiar with the dive computer and planning your dives. Suunto recommends using the dive simulator to run through different dive scenarios. The Dive Simulator will allow you to “perform”...
  • Page 92 7.6.2. Dive Planning Simulator [2 SIMPLAN] The Dive Planning Simulator mode shows you the present no-decompression limits. In this mode, you are also able to add the desired surface interval increment to present surface interval time, which allows you to plan your dives in advance. This mode is also used to add the desired surface intervals for dive simulations.
  • Page 93 The Dive Planning Simulator mode is disabled in Gauge mode NOTE and in Error mode.
  • Page 94 8. CARE AND MAINTENANCE OF MY SUUNTO DIVING COM- PUTER The SUUNTO dive computer is a sophisticated precision instrument. Although it is designed to withstand the rigors of scuba diving, you must treat it with the same proper care and caution as any other precision instrument.
  • Page 95 The service requires special tools and training. Therefore, it is advisable to contact an authorized SUUNTO dealer or distributor for service. Do not at- tempt to do any servicing that you are not sure of.
  • Page 96 A leak must be corrected without delay as moisture will seriously damage the unit, even beyond repair. SUUNTO does not take any responsibility for damage caused by moisture in the dive computer unless the instructions of this manual are carefully followed.
  • Page 97 9. BATTERY REPLACEMENT It is advisable to contact an authorized Suunto representative for NOTE battery replacement. It is imperative that the change is made in a proper manner to avoid any leakage of water into the battery compartment or computer.
  • Page 98 9.3. Replacing the battery The battery and the buzzer are located in the back of the instrument in a separate compartment. To change the battery: Remove the computer from the console or boot. Wrist model: Pull off the boot. Remove it first from the front end with the longer part of the •...
  • Page 99 In case of a leak or any other damage, bring the dive computer to an authorized SUUNTO dealer or distributor for check and repair. Check the condition of the O-ring; a defective O-ring may indicate sealing or other problems.
  • Page 100 the low battery warning is off. • the buzzer beeps and backlight works. • all the settings are correct. Reset if necessary. • 18. Install the dive computer back into the console or boot and reassemble the strap. The instrument is now ready for use. Wrist model: Assembling into the boot: First insert the longer strap in its hole in the front of •...
  • Page 101 Figure 9.1. Opening of the securing ring.
  • Page 102 10. TECHNICAL DATA 10.1. Technical specifications Dimensions and weight: • Diameter: 61.0 mm/2.4 in • Thickness: 28 mm/1.1 in • Weight: 68 g/2.4 oz Depth gauge: • Temperature compensated pressure sensor • Calibrated complying with EN 13319 • Maximum depth of operation: 80 m/262 ft (complying with EN 13319) •...
  • Page 103 It is recommended that the instrument be stored in a dry place at room temperature. Do not leave the dive computer in direct sunlight! NOTE Tissue calculation model: • Suunto RGBM algorithm (developed by Suunto and Bruce R. Wienke, BSc, MSc, PhD) • 9 tissue compartments...
  • Page 104 • Tissue compartment halftimes: 2.5, 5, 10, 20, 40, 80, 120, 240, and 480 minutes (on gassing). The off gassing halftimes are slowed down • Reduced gradient (variable) "M" values based on diving habit and dive violations. The "M" values are tracked up to 100 hours after a dive •...
  • Page 105 It was developed in co-operation between Suunto and Bruce R. Wienke BSc, MSc, PhD. It is based on both laboratory experiments and diving data, including data from DAN.
  • Page 106 10.2.1. Suunto RGBM adaptive decompression The Suunto RGBM algorithm adapts its predictions of both the effects of microbubble build-up and adverse dive profiles in the current dive series. It also changes these calculations according to the personal adjustment you select.
  • Page 107 10.2.2. No-decompression limits for air The no-decompression limits displayed by the dive computer for the first dive to a single depth (see Table 10.1, No-decompression time limits for various depths (m) and Table 10.2, No-decompression time limits for various depths (ft) .), are slightly more conservative than those permitted by the U.S.
  • Page 108 No-decompression time limits (mins) for various depths (m) for the first dive of a series Depth Personal Mode / Altitude Mode P0/A0 P0/A1 P0/A2 P1/A0 P1/A1 P1/A2 P2/A0 P2/A1 P2/A2 Table 10.2. No-decompression time limits for various depths (ft) No-decompression time limits (mins) for various depths (ft) for the first dive of a series Depth Personal Mode / Altitude Mode...
  • Page 109 No-decompression time limits (mins) for various depths (ft) for the first dive of a series Depth Personal Mode / Altitude Mode (ft) P0/A0 P0/A1 P0/A2 P1/A0 P1/A1 P1/A2 P2/A0 P2/A1 P2/A2 10.2.3. Altitude diving The atmospheric pressure is lower at high altitudes than at sea level. After traveling to a higher altitude, you will have additional nitrogen in your body, compared to the equilibrium situation at the original altitude.
  • Page 110 Before high-altitude diving, the instrument must be set to the Altitude Adjustment mode to adjust the calculations for the new altitude. The maximum partial pressures of nitro- gen allowed by the mathematical model of the dive computer are reduced according to the lower ambient pressure.
  • Page 111 The selected O % on the alternative display • OLF% alternative display for either CNS% or OTU% (whichever is larger) • Audible alarms are given and the OLF value starts to blink when the 80% and • 100% limits are exceeded. In dive planning, the maximum depth according to the O % and maximum PO •...
  • Page 112 11. INTELLECTUAL PROPERTY 11.1. Trademark Suunto is a registered trademark of Suunto Oy. 11.2. Copyright © Suunto Oy 08/2011. All rights reserved. 11.3. Patent notice Patents have been issued or applied for one or several features of this product.
  • Page 113 The CE mark is used to mark conformity with the European Union EMC directive 89/336/EEC. 12.2. EN 13319 EN 13319 is a European diving depth gauge standard. Suunto dive computers are designed to comply with this standard. 12.3. EN 250 / FIOH...
  • Page 114 13. SUUNTO LIMITED WARRANTY Suunto warrants that during the Warranty Period Suunto or a Suunto Authorized Service Center (hereinafter Service Center) will, at its sole discretion, remedy defects in materials or workmanship free of charge either by a) repairing, or b) replacing, or c) refunding, subject to the terms and conditions of this Limited Warranty.
  • Page 115 Suunto does not warrant that the operation of the Product will be uninterrupted or error free, or that the Product will work in combination with any hardware or software provided by a third party.
  • Page 116 14. DISPOSAL OF THE DEVICE Please dispose of the device in an appropriate way, treating it as electronic waste. Do not throw it in the garbage. If you wish, you may return the device to your nearest Suunto representative.
  • Page 117 GLOSSARY Altitude dive A dive made at an elevation greater than 300 m/1000 ft above sea level. Ascent rate The speed at which the diver ascends toward the surface. ASC RATE Abbreviation for ascent rate. Ascent time The minimum amount of time needed to reach the surface on a decom- pression stop dive.
  • Page 118 Decompression range On a decompression stop dive, the depth range between the floor and the ceiling within which a diver must stop for some time during ascent. Decompression illness Any of a variety of maladies resulting either directly or indirectly from the formation of nitrogen bubbles in tissues or body fluids, as a result of inad- equately controlled decompression.
  • Page 119 Used to measure the whole-body-toxicity. Oxygen limit fraction A term used by Suunto for the values displayed in the oxygen toxicity bar graph. The value is either the CNS% or the OTU%. Oxygen percentage or oxygen fraction in the breathing gas. Standard air has 21% oxygen.
  • Page 120 Abbreviation for oxygen partial pressure. RGBM Abbreviation for Reduced Gradient Bubble Model. Reduced Gradient Bubble Model Modern algorithm for tracking both dissolved and free gas in divers. Repetitive dive Any dive whose decompression time limits are affected by residual nitro- gen absorbed during previous dives.
