OVER THE RANGE MICROWAVE
CONTEMPORARY
MOH30SB1
USER GUIDE
US CA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOH30SB1 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher & Paykel MOH30SB1

Summary of Contents for Fisher & Paykel MOH30SB1

  • Page 1 OVER THE RANGE MICROWAVE CONTEMPORARY MOH30SB1 USER GUIDE US CA...

  • Page 2: Important Safety Instructions

    SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! FOR YOUR SAFETY, THE INFORMATION IN THIS MANUAL MUST BE FOLLOWED TO MINIMIZE THE RISK OF FIRE OR EXPLOSION OR TO PREVENT PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. WARNING indicates a potentially hazardous situation which, if not avoided, could ●...

  • Page 3: Safety And Warnings

    SAFETY AND WARNINGS utensils, or food in the microwave when not in use. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling ● point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present.
  • Page 4 INTRODUCTION Read this User Guide and always save it for reference. A good microwave cookbook is a valuable asset. Check it for microwave cooking principles, techniques, hints, and recipes. NEVER use the microwave oven without the turntable and support nor turn the turntable over so that a large dish could be placed in the microwave oven.
  • Page 5 OVERVIEW Vent openings Waveguide cover DO NOT REMOVE Safety interlock system Window Turntable Control panel Surface lights Grease filters Bottom View PRODUCT FEATURES Sensor cooking 10 variable power levels Add 30 seconds and express cooking Exhaust fan with two speeds Task lighting Child lock Turntable...

  • Page 6: Control Panel

    CONTROL PANEL 3 4 5 !2 !3 !4 !5 !6 ITEM DESCRIPTION Light Press to turn on/off the light underneath your microwave. SENSOR COOKING Detects the humidity released and adjusts the cooking time based on the type and amount of food cooking. Popcorn Press to cook popcorn.

  • Page 7: Cookware And Cooking Materials

    COOKWARE AND COOKING MATERIALS Warning: Personal Injury Hazard. Tightly-closed containers could explode. Closed containers should be opened and plastic pouches should be pierced before cooking. Cookware and other materials must fit on the turntable. Always use oven mitts or pot holders because cookware may become hot.
  • Page 8 COOKWARE AND COOKING MATERIALS Materials to be avoided MATERIAL REMARKS Aluminum tray May cause arcing. Use a microwave-safe dish instead. Food carton with metal May cause arcing. Use a microwave-safe dish instead. handle Metal or metal trimmed Metal shields the food from microwave energy. The metal utensils trim may cause arcing.

  • Page 9: Installing The Turntable

    INSTALLING THE TURNTABLE Never place the glass tray upside down. The glass tray should never be restricted. Both the glass tray and turntable ring must always be used during cooking. Always place all food and containers of food on the glass tray for cooking. If the glass tray or turntable ring cracks or breaks, contact your nearest authorized service center.

  • Page 10: Cooking Guide

    COOKING GUIDE Storage temperature Foods taken from the freezer or refrigerator take longer to cook than the same foods would at room temperature. Size Small pieces of food cook faster than large ones. Pieces similar in size and shape will cook more evenly when cooked together.

  • Page 11: Using Your Microwave

    USING YOUR MICROWAVE 1. Press , then use the number pad to enter the cooking time that you want. TIME COOK 2. If required, press , then enter the desired power level (1-10). By default, your POWER LEVEL microwave cooks at 100% power. Press while cooking to check the power.
  • Page 12 COOKING WITH MULTIPLE COOKING STAGES 1. Press , then use the number pad to enter the cooking time that you want. TIME COOK 2. Press , then enter the power level that you want (1-10) for the first stage. POWER LEVEL The power level is shown on the display.

  • Page 13: Cooking With The Sensor

    COOKING WITH THE SENSOR Sensor cooking detects the humidity released by your cooking food and adjusts the cooking time based on the type and amount of food cooking. 1. Press , then press . Your microwave automatically sets the cook time. SENSOR REHEAT START 2.

  • Page 14: Using Additional Functions

    USING ADDITIONAL FUNCTIONS VEGETABLE The vegetable sensor feature cooks from one to four cups of fresh vegetables (when starting at room temperature). 1. Press repeatedly to select the number of cups: VEGETABLE SERVINGS PRESS VEGETABLE BUTTON 1 cup Once 2 cups 2 times 3 cups 3 times...
  • Page 15 USING ADDITIONAL FUNCTIONS DEFROST 1. Press repeatedly to select DEFROST MEAT POULTRY FISH 2. Press START 3. Use the number pad to enter the weight of the item to be defrosted (in pounds). You may enter any weight from 0.1 to 6.0 lbs. 4.
  • Page 16 USING ADDITIONAL FUNCTIONS CLOCK 1. Press CLOCK. 2. Use the number pad to enter the current time (1:00–12:59). 3. Press to confirm setting. START Note: You can use the timer while the microwave is cooking. TIMER 1. In standby mode, press TIMER.

  • Page 17: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Exterior The outside surface is pre-coated steel and plastic. Clean the outside with mild soap and water, then rinse and dry with a soft cloth. Do not use any type of household or abrasive cleaner. Door Wipe the window on both sides with a damp cloth to remove any spills or spatters. Metal parts will be easier to maintain if wiped frequently with a damp cloth.
  • Page 18 CLEANING AND MAINTENANCE Exhaust filters The exhaust filters should be removed and cleaned about once a month. CAUTION : Do not operate the oven hood without the filters properly in place. 1. To remove the exhaust filters, slide the filter toward the back of the microwave, then pull it downward while sliding it out of the side slot.
  • Page 19 CLEANING AND MAINTENANCE Replacing the charcoal filter The charcoal filter is used in non-vented, recirculated installations. The filter should be changed every 6 to 12 months depending on use. 1. Unplug the microwave oven or turn off power at the main circuit breaker.
  • Page 20 CLEANING AND MAINTENANCE Surface light (external) The exhaust filters should be removed and cleaned about once a month. CAUTION : Do not operate the oven hood without the filters properly in place. 1. Unplug the microwave oven or turn off power at the main circuit breaker.
  • Page 21 CLEANING AND MAINTENANCE Surface light (internal) The exhaust filters should be removed and cleaned about once a month. CAUTION : Do not operate the oven hood without the filters properly in place. 1. Unplug the microwave oven or turn off power at the main circuit breaker.

  • Page 22: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Microwave will not The electrical cord is not plugged in. Plug in the electrical cord. start The door is open. Close the door and try again. The wrong operation is set. Check the instructions and try again. Arcing or sparking in You are attempting to use incorrect Use only microwave-safe materials.

  • Page 23: Specifications

    SPECIFICATIONS Rated voltage 120 VAC, 60HZ Rated input power 1500 W Rated output power 1000 W Microwave capacity 1.6 cu ft Turntable diameter 13.5” (345mm) External dim (WxHxD) 29 7/8” x 16 1/2" x 15 9/16" (759mm x 419mm x 395mm) Internal dim (WxHxD) 20 1/4”...
  • Page 24 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2024. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
