S H E N Z H E N K H J S E M I CO N D U C TO R L I G H T I N G C O.,L T D
Opera on & Maintenance Manual
KGoldenFrog Series-NV2.0
Important informa on:
These instruc ons contain safety informa on, read and follow them carefully. KHJ will not accept any responsibility
for injury, damage or loss which may occur due to incorrect installa on, opera on or maintenance
Advertisement
Related Manuals for KHJ KGoldenFrog NV2.0
Summary of Contents for KHJ KGoldenFrog NV2.0
- Page 1 KGoldenFrog Series-NV2.0 Important informa on: These instruc ons contain safety informa on, read and follow them carefully. KHJ will not accept any responsibility for injury, damage or loss which may occur due to incorrect installa on, opera on or maintenance...
- Page 2 Product Important Informa on EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, Standards IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8 CE, RoHS Cer ficate Ambient Temp -20℃ ≤ Ta ≤ +55℃ Ingress Protec on IP54 (IEC)EN 60529 Cable Entry...
- Page 3 North American Protec on Techniques 3.1 Tools ·4 mm and 5 mm flat blade screwdriver, large cross head screwdriver and inner hexagon counter wrench, suitable spanners for installing cable gland, pliers, knife, wire stripper and cu er. 3.2 Moun ng ·Luminaire should be installed where access for maintenance is prac cal and in accordance with ligh ng design informa on.
- Page 4 05. Charge Display ·Main power indicator light: green LED on. · Charging indicator light: red LED on, and will be off when the ba ery is fullly charged. · Malfunc on indicator light: yellow LED flashes at a frequency of 1Hz to indicate the ba ery is faulty. Yellow LED flashes at a frequency of 2Hz to indicate the load light source is faulty.
- Page 5 Entries into enclosures torque of locking cable introduc on device 35 N.M~40 N.M. · Suitable cable glands or plugs · If using cable gland and stopping plug of KHJ, please refer to below table for cable spec (including but not limited to): Suitable Cable(mm) Type φ8-φ12...
- Page 6 ·6.1.2 Pendant mount(unit:mm) ·6.1.3 Pipe Mount(unit:mm) 6.2 Electrical Principles and Connec ons In addi on to referring to the relevant contents of this manual, the cer fied personnel who have obtained the corresponding cer ficate according to (IEC)EN60079-14 shall strictly comply with the requirements of (IEC)EN60079-14 when installing luminaire.
- Page 7 07.Repairs Maintenance Visual tests and checks should be carried out at intervals described by the appropriate regula ons, (IEC)EN 60079-17,and should include the following(including but not limited to). · Check for mechanical damage/corrosion. · Check connec ons, fixings, glands and plugs. ·...
- Page 8 12. Optional Parts Installation accessories Part No. Picture Material Weight(Kg) Remark WS-PS SUS304 Wall Mount Bracket SM-PS Stainless Steel Steel chain Pendant Mount PCR-F-N Pipe connector SUS304 Pipe mount PCR-F-M...
- Page 9 Contact Web: www.khjled.com SHENZHEN KHJ SEMICONDUCTOR LIGHTING CO., LTD. ----------------------------------------------------------------------------------------------------------------------------------------------------------- Address: 4-5 Floor, Building 1,Chuangxin industrial park,Xintian community,Guanlan,Longhua new district, Shenzhen ,China. Tel: +86-755-82949977 Fax: +86-755-82949800 E-mail: khjledsales@khj.cn Web: www.khjled.com...
