S H E N Z H E N K H J S E M I CO N D U C TO R L I G H T I N G C O.,L T D
Opera on & Maintenance Manual
Tank Series-NV3.2
Important informa on:
These instruc ons contain safety informa on, read and follow them carefully. KHJ will not accept any responsibility
for injury, damage or loss which may occur due to incorrect installa on, opera on or maintenance
Advertisement
Related Manuals for KHJ Tank NV3.2 Series
Summary of Contents for KHJ Tank NV3.2 Series
- Page 1 Tank Series-NV3.2 Important informa on: These instruc ons contain safety informa on, read and follow them carefully. KHJ will not accept any responsibility for injury, damage or loss which may occur due to incorrect installa on, opera on or maintenance...
- Page 2 Product Important Informa on EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, Standards IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8 CE, RoHS Cer ficate Ambient Temp -40℃ ≤ Ta ≤ +55℃ Ingress Protec on IP66 Cable Entry...
- Page 3 03. General ·These instruc ons should be read fully and carefully before a emp ng to install the luminaire. For details of servicing opera ons, opening etc.see sec on 5. · Copies of these instruc ons should be held in a safe place for future reference. It is the responsibility of the installer to ensure that the apparatus selected is fit for it is intended purpose and that the installa on, opera on and maintenance of the apparatus complies with applicable regula ons, standards or codes of prac ce.
- Page 4 ！ Isolate mains before Install in a well Do not con nually removing cover ven lated area stare at lamp 05.Emergency Opera on 5.1 General descrip on of opera on ·Connect the lead wire of B in the terminal box and then connect to AC power supply to start emergency func on. ·...
- Page 5 (unit:mm) 360°ROTATION(EVERY15° IS A ROTATION ANGLE), φ M10 ANCHOR BOLT (PROVIDED BY THE CUSTOMER) SBT-TK-SUS316 90~130 φ φ Stanchion mount / Wall mount 6.2 Two lamps (unit:mm) 358~366 2-R10 φ 2-R10 φ φ M10 ANCHOR BOLT (PROVIDED BY THE CUSTOMER) BR-TK-SUS316 Ceiling mount (unit:mm)
- Page 6 Entries into enclosures torque of locking cable introduc on device 35 N.M~40 N.M. · Select the cable glands or plug t · If useing cable gland and stopping plug of KHJ, please refer to below table for cable spec (including but not limited to): Outer diameter(mm) Type φ...
- Page 7 6.1 Installa on decomposi on It is the responsibility of the installer to ensure that the apparatus selected is fit for it is intended purpose and that the installa on, opera on and maintenance of the apparatus complies with applicable regula ons, standards or codes of prac ce. Please refer to the following installa on drawing for different installa on methods.
- Page 8 Light Body Light LED- LED PCBA LED+ Power supply Cavity Light Body Driver- LED Driver 160-240W Driver+ LED- LED PCBA Earth LED+ Earth Light Body Light LED- ight LED L LED+ Power supplyCavity Light Body Driver- LED Driver 160-240W Driver+ LED- ight LED L...
- Page 9 6.2.2 Electrical Principles for emergency luminaires Light Light Body Power supply Cavity LED- Driver- LED Driver LED L ight 80-150W Driver+ LED+ Earth Light Body Bat- Bat+ Bat+ Bat- LED+ LI-O LOUT LED- LED+ LED- LED L ight Bat- Emergency device Bat+ Indicator+ Indicator+...
- Page 10 09. Disposal of Material General Disposal of the luminaire as waste should be carried out in accordance with na onal regula ons. Any disposal must sa sfy the requirements of the WEEE direc ve [2012/19/EU] and therefore must not be treated as commercial waste.
- Page 11 13. Optional Parts Installa on Part No. Picture Material Weight(Kg) Remark accessories Single lamp Two lamps Ceiling bracket BR-TK-SUS316 SUS316 Four lamps Stanchion bracket SBT-TK-SUS316 SUS316 SBT-TK-2-SUS316 SUS316 Stanchion bracket SBT-TK-4-G Q235 Stanchion bracket...
- Page 12 Contact Web: www.khjled.com SHENZHEN KHJ SEMICONDUCTOR LIGHTING CO., LTD. ----------------------------------------------------------------------------------------------------------------------------------------------------------- Address: 4-5 Floor, Building 1,Chuangxin industrial park,Xintian community,Guanlan,Longhua new district, Shenzhen ,China. Tel: +86-755-82949977 Fax: +86-755-82949800 E-mail: khjledsales@khj.cn Web: www.khjled.com...
