Audi A3
Audi A3 Sportback
Quick reference guide
Dear Audi Driver,
This quick reference guide gives you a brief introduction
to the main features and controls of your vehicle.
However, it cannot replace the Owner's Manual and the
other manuals supplied with the vehicle; these contain
important information and safety warnings.
We wish you safe and enjoyable motoring
with your Audi.
AUDI AG
4
Locking and unlocking
the vehicle
3
The central locking system locks
2
and unlocks all the doors, the tail-
gate and the tank flap. It can be
1
operated with the remote control
or by turning the key in the lock.
Remote control keys
Press the appropriate button for about 1 second.
e
Unlocking button: Open one of the doors within
about 60 seconds, otherwise the vehicle will lock
itself again automatically.
r
Unlocking button for tailgate
t
Locking button: The turn signals flash once to
confirm that the doors and tailgate are properly
closed and locked.
u
Folding out the master key: Press the release
button.
Folding away the master key: Press the button
and fold the key away.
Note: Press and hold the unlocking button on the
remote control to open all the windows automatically.
Press and hold the locking button to close all the
windows and the sun roof.
WARNING!
The doors and windows cannot be opened from
inside the vehicle if it has been locked from the
outside.
Anti-theft alarm
The alarm system is automatically set when you lock the car, and switched off when you unlock the car with the
remote control. If you unlock the vehicle by inserting the key in the driver's door, the ignition must be switched on
within 15 seconds, otherwise the alarm will be triggered.
Page 1
Sun roof
2
The ignition must be
1
switched on to open and
close the sun roof.
To tilt open: Briefly press/
3
pull the control while it is
t
in position
in order to tilt the roof open/closed.
Press or pull the control and hold it to make the roof
tilt up or down to the desired position.
Comfort setting (for less wind noise): Turn the control
e
until it engages at position
.
r
To open: Turn the control to position
and hold it there.
To close: Turn the control until it engages at position
open sky sun roof
The ignition must be
1
switched on to open
and close the sun roof.
To tilt open: Briefly press
2
e
rear end of switch (marked
).
Comfort setting (for less wind noise): Briefly press rear
e
end of switch (marked
) TWICE.
To open/close the sun roof: Press rear end of switch
r
(open) or front end of switch
(close) until the open
sky sun roof is fully open/closed or has reached the
desired position.
t
.
e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A3 SPORTBACK and is the answer not in the manual?

Questions and answers

Summary of Contents for Audi A3 SPORTBACK

  • Page 1 Dear Audi Driver, This quick reference guide gives you a brief introduction to the main features and controls of your vehicle. However, it cannot replace the Owner’s Manual and the other manuals supplied with the vehicle; these contain important information and safety warnings.
  • Page 2: Adjusting Front Seats

    Adjusting front seats Adjusting head restraints Moving seat backwards or Raising head restraint: Take hold of the sides of the head forwards restraint with both hands and move it up as required. Lift the lever and move the seat into the desired position. Then Lowering head restraint: Press the button on the side of the release the lever and move the head restraint and move the head restraint as required.
  • Page 3: Filling The Tank

    AUDI AG reserves the right to alter any part of the vehicle, its equipment and technical specifications. No legal commitment can be implied by the information, illustrations or descriptions in this publication. No part of this publication may be reprinted, reproduced or translated without the written permission of AUDI AG. All rights under the laws of copy- right are expressly reserved by AUDI AG.
  • Page 4: Warning And Indicator Lamps

    9 ..Control lever for windscreen wipers/ 25 ...Bonnet release lever washer and on-board computer 18 ...Cigarette lighter/socket Please read Owner’s Manual. Further information for these items is given on the following pages. Audi A3/A3 Sportback Kurzanleitung englisch 5.07 281.562.755.20 Page 4...
  • Page 5 [4] Light switch AUTO Sensor-controlled activation/deactivation. Side lights Dipped beam/main beam headlights In fog, turn switch to dipped headlights position and then pull out to 1 stop ( front fog lights) or to 2 stop ( front and rear fog lights). [2] Electric adjuster for exterior mirrors Selector knob: Left exterior mirror...
  • Page 6 [17] Selector lever for automatic gearbox Selector lever positions Parking lock Reverse gear Neutral Drive Sport To move the selector lever out of position P or N, or into position P or R, press the interlock button on the selector lever handle and the brake pedal simultaneously.
