- Page 1 Audi A3 • A3 Sportback Audi S3 Quick reference guide...
-
Page 2: Fuel Tank Flap
Fuel tank flap To open: Press the left side of the flap. To close: Press the tank flap until you hear it click into place. Warning triangle The compartment for the warning triangle is located in the luggage compartment under the floor panel (on vehicles with four- wheel drive) or below the tailgate opening. - Page 3 You will find everything you need to know about the radio, CD, navigation, TV and telephone functions in the Operating Manual for your sound system or navigation system. We wish you safe and enjoyable motoring with your new Audi. AUDI AG Welcome...
-
Page 4: Controls And Displays
Controls and displays Electric windows To set the desired position: Press/pull to the first stop and hold. „One-touch“ function: Press/pull briefly to the second stop. Adjuster for exterior mirrors Turn the adjuster for: Door handle and Left exterior mirror central locking switch Exterior mirror heating Right exterior mirror Exterior mirror... - Page 5 Steering wheel position adjuster Controls on multi-function steering wheel Turn signal and main beam lever Instruments and warning/ Switches and warning indicator lamps lamps for: Windscreen wipers/washer and buttons for on-board computer Ignition lock Sound system or navigation system Storage tray Air conditioner Front passenger’s seat heating...
-
Page 6: Seat Adjustment
Sitting position Sit in a normal upright position and do not sit too close to the steering wheel. If necessary, also adjust the position of the steering wheel. Seat adjustment Electric seat adjustment To adjust seat height and move seat backwards or forwards: Front of seat cushion up/down Rear of seat cushion up/down Seat up/down... -
Page 7: Starting The Engine
Starting the engine Switching on the ignition/starting the engine Insert the key into the ignition lock. To switch on the ignition: Turn the key to position . The glow plugs on diesel engines start preheating in this position. To start the engine (on vehicles with manual gearbox): Press the clutch and turn the key to position the engine starts. -
Page 8: Switches For Air Conditioner
Switches for air conditioner Control on left: Temperature selection for left side Control on right: Temperature selection for right side Automatic mode AUTO Set the desired temperature and press the button. Blower speed (switches in the middle) Air recirculation Circulates and filters the air in the interior of the vehicle ECON mode ECON Activates/deactivates air cooling... -
Page 9: Cruise Control System
open sky sun roof Comfort position: Briefly press rear end of switch twice. To open/close: Press rear end of switch (open) or front end of switch (close) until the open sky sun roof is fully open/ closed or has reached the desired position. To tilt open/close: Briefly press rear or front end of switch Cruise control system... -
Page 10: Navigation System Plus
Audi Navigation System plus Components Driver information system Multi-function steering wheel Scroll the left thumbwheel to select a menu item in the driver information system. Press the thumbwheel to confirm the selection. Press the MODE button to switch between the active audio source and the navigation and telephone functions. - Page 11 Display Function selector buttons Press one of the buttons (e.g. RADIO) to activate the desired mode. ON/OFF button To switch on: Press briefly. To adjust volume: Turn. To mute: Press briefly. To switch off: Press and hold. Control buttons To activate one of the functions shown in the four corners of the display, press the control button for that corner of the display.
- Page 12 Press the RADIO function selector button. Press the control button for ”Memory”. The control button corresponds to the top left-hand corner of the display. Turn the rotary pushbutton and select the desired station. Turn the rotary pushbutton and select the desired memory position. Press the rotary pushbutton to confirm.
- Page 13 Press the NAV function selector button. MÜN MÜNCH-LEU… MÜNCHAUR… MÜNCHBERG MÜNCHEBERG LIST Repeat the above step to enter the remaining letters of the destination town until the name of the desired town appears on the display. Germany Turn the rotary pushbutton and select ”Town/ZIP”.
-
Page 14: Bluetooth Connection
Switch on the ignition, navigation system and mobile phone. On your mobile phone, select the menu that looks for Bluetooth devices (e.g. ”Hands-free”). On the mobile phone, select ”Audi UHV” and confirm. Enter the PIN ”1234” on your mobile phone. Infotainment Bluetooth ©... -
Page 15: Warning And Indicator Lamps
No part of this publication may be reprinted, reproduced or translated without the written permission of AUDI AG. All rights under the laws of copyright are expressly reserved by AUDI AG. Subject to alter ation and amendment. Concept and layout: Pfriemer GmbH. Printed in Germany. - Page 16 Audi A3 • A3 Sportback Audi S3 Kurzanleitung englisch 11.07 282.562.755.20...
