- Page 1 USER MANUAL Venice XL Manager ViP art. SHMAN010W, SHMAN010WA Maxi Manager with Android TM art. 20003300W...
- Page 2 • any purpose other than the intended use, • failure to observe the indications and warnings contained in this Manual / Instruction sheet. Comelit Group S.p.A. reserves the right to change the information provided in this Manual / Instruction Sheet at any time and without prior notice.
- Page 3 Table of contents DESCRIPTION OF ART. SHMAN010W/SHMAN010WA ....4 SCENARIOS ............... 15 Description ...................15 DESCRIPTION OF art. 20003300W ..........5 Function keys .................5 Instant ................15 Show soft-touch keys ..............5 Scheduled ..............15 LED meanings ................5 Conditioned ..............15 CONFIGURATION ................6 Create a new scenario ..............16 USING THE INTERFACE ..............
- Page 4 Venice XL ViP System Manager, 10”. Touch screen with ViP system video entry, integrated management of home automation and VEDO intruder alarm systems. For home automation management, the system must include art. 20003150 – Comelit Hub. The system manager can be used to control lights, blinds, automated openings and zone-based temperature regulation with custom schedules, as well as managing irrigation and displaying electricity, water, gas consumption, etc..., plus managing load disconnection, anti-intrusion system commands and viewing cameras on the IP network.
- Page 5 7” system manager based on the Android operating system, used to manage video entry, home automation and the VEDO anti-intrusion system. For home automation management, the system must include art. 20003150 – Comelit Hub. Flush-mounted (using optional box art. 6817) or surface-mounted (with optional bracket art.
- Page 6 Select the network connection mode for Comelit Hub 20003150 (Ethernet or Wi-Fi) • Press SCAN to search the network for Comelit Hub 20003150 to be paired with the home automation system manager, otherwise Date and time enter the ViP address manually •...
- Page 7 If there is more than one SHMAN010W/SHMAN010WA/20003300W in the Comelit Hub 20003150 project: f Select the configuration to be assigned to the system manager, then press OK » Wait for the connection confirmation message Home automation Setup Home Automation Setup...
- Page 8 Press to return to the previous screen the lock-release on receipt of a call from an external unit. • SILENT MODE AND DOOR OPENING ON CALL: COMELIT APP activates both functions. f While third-party Apps are open, press to return to the...
- Page 9 FUNCTIONS HOME HOME PAGE The functions home page allows you to: • quickly access all available functions • instantly activate scenarios • quickly access new scenario setup (see paragraph "Create a new WIDGET HOME scenario" The widget home page o ers quick access to the most frequently used commands and displays notifications in the memory.
- Page 10 Menu reorganisation f Press and hold the button to move it to the desired position (function not available in ViP Manager) VIDEO DOOR ENTRY SYSTEMS CAMERAS In the door entry system/cameras section, the following functions are available: self activation of an external unit, intercom call, call to a switchboard, camera switch-on.
- Page 11 Managing directories Functions available if enabled via Settings_Advanced_Access_ViP Directory_Enable directory modification. Deleting an entry in the directory Adding an entry to the directory f Press (only with the widget home) f Choose VIDEO DOOR ENTRY SYSTEMS / CAMERA / LOCK- RELEASE / ACTUATORS and access the desired directory 1.
- Page 12 ANTI-INTRUSION Burglar alarm scenarios configured using Safe Manager. Activations The directory shows a list of burglar alarm activation scenarios configured on the alarm control panel. f Press a scenario in the list to enable it. P1 and P2, configured via Safe Manager, are partial burglar alarm activations in a specific area.
- Page 13 Burglar alarm Events The directory shows the events stored in the memory of the alarm control √ Alarm in progress. panel by dividing them into: • event memory: lists all events that occurred in the control panel The alarm in progress screen shows the intrusion site, the event details and recordings, plus alarm commands.
- Page 14 CONSUMPTION View consumption graph Consumi 1. Press the desired element to display the consumption graph. This menu can be used to monitor consumption for the managed modules by means of icons and graphs. View Consumption / production comparison graph. View economic consumption. View energy consumption.
- Page 15 View economic consumption summary SCENARIOS With the scenario function, automatic functions can be controlled by activating them manually or scheduling them, or even when certain predefined conditions occur. The scenarios are divided into 3 pages, depending on the di erent types. Instant scenarios Scheduled scenarios Conditioned scenarios...
- Page 16 Temperature reading for the room 20,4° WHAT Humidity reading for the room f Select a function from the available options, configured in Comelit Hub. This may be a door entry system, home automation or alarm action. Device status / Setpoint To delete: 60°...
- Page 17 1. Selected device 2. Operating mode: temperature/humidity 3. Cursor for temperature setpoint setting 4. Indication showing device operating due to setpoint being reached 5. Temperature setpoint set 6. Setpoint setting commands 7. Temperature reading for the room 8. Edit name and icon Humidity management 9.
- Page 18 Manual mode Switch from humidifying to dehumidifying (if enabled) In this mode the current settings remain active until the next time they are humidifier in operation changed manually by the user. humidifier standby mode dehumidifier in operation dehumidifier standby mode Party mode (cocktail glass): temporary forcing of the humidity setpoint for a short period (hours) Holiday mode (suitcase): temporary forcing of the...
- Page 19 3. Define the scheduling start and end time, then press Climate Scheduling f Press the scheduling icon to set the time slots used by the device when set in automatic mode. Programming should cover a full 24-hour period. Any hours not programmed by the user will be set by the system automatically! 1.
- Page 20 Delete schedule Party/Holiday Automatic/manual mode can be paused for a specific period of time The default schedule cannot be deleted. by selecting a di erent setpoint and a timer from the Party and Holiday menus. 1. Select Party to set a forcing lasting a few hours throughout the day;...
- Page 21 Edit name/icon LIGHTS / OTHER This menu is used to edit the name of the output and to select an alternative icon from the suggested options. 1. Press the icon to access the configuration page. 2. Press the name to display the alphanumeric keypad and edit. 1.
- Page 22 Edit name/icon Scheduling Room Lighting and Other Schedules can be created to include all the outputs of a specific room, or 1. Select the desired output and press to display the name/icon each individual output can be scheduled. editing options. New Scheduling Room Lights and More 1.
- Page 23 DIMMABLE LIGHTS Dimmable lights are lights with adjustable intensity. 6. Enable scheduling using the cursor. f Press to confirm. f Press to cancel. CANCEL The percentage value refers to the set light intensity, taking 100 as the maximum intensity value. TIMED OUTPUTS f Select the desired output to access the brightness control screen.
- Page 24 RGB LIGHTS RGB lights are lights with adjustable intensity and chromatic value. From this window, you can trigger individual outputs and create schedules for the whole room. Paragraph "Scheduling Room Lighting and Other". f Select an output. f Select the desired shade from the colour chart. f On selecting the output, you can access the edit name/icon menu, create and edit schedules, trigger the output and, if applicable, control 1.
- Page 25 PREFERRED POSITION Example of operation Options available with art. SHMAN010W/SHMAN010WA/20003300W used in conjunction with art. 20004606. It can be used to store a fixed intermediate position percentage on the preferred position key. By pressing the button, the shutter/Venetian blind will position itself at the set closing percentage.
- Page 26 RULES Rules configured previously on Comelit Hub can be enabled/disabled. For more information see paragraph "Edit name/icon". The icon indicates a timed output. For more information see paragraph "Timed outputs".
- Page 27 Deleting a video message ACTUATORS LOCK-RELEASE The list of actuators/lock-release commands is available in this section. f Touch the desired element to activate it. f Press and hold the video recording. f Press f Press to confirm. Editing/adding an entry to the directory Function available enabled...
- Page 28 SETTINGS Device Language Used to set the device language. Used to set the date and time shown on the device: Date and Time Activate “Automatically set Date & Time” and select your time zone to automatically update the date and time via Internet. Deactivate “Automatically set Date &...
- Page 29 System Changing parameters may lead to malfunctions in the alarm system. Please contact a Alarm control panel qualified technician. This menu allows the user to manage some of the alarm system options for activation/deactivation purposes. f Enter the alarm password to access the area. •...
- Page 30 Protection The protection menu allows you to: • Change the user password (default 111111). We recommend changing the default password to increase the security level. • Change the installer password (default 1961). We recommend changing the default password to increase the security level. •...
- Page 31 Reset - EXTERNAL UNITS Speaker amplifier Reset - INTERNAL UNITS Audio normalisation Reset - CONCIERGE Reset - CAMERAS Home Automation Setup Reset - COMELIT HUB AGENTID Enable Reset - User password Comelit Hub connection Wi-Fi - Ethernet ViP address Comelit Hub ViP address...
- Page 32 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
