00 MAINTENANCE AND GENERAL INFORMATION

00 DANGER OF POISONING IF OIL IS INGESTED/ABSORBED THROUGH THE SKIN

Danger of poisoning!

Ingesting oil or absorbing through the skin may cause poisoning!

Possible symptoms are:

Headaches



Dizziness



Stomach aches



Vomiting



Diarrhoea



Cramps/fits



Unconsciousness



Protective measures/rules of conduct:

Pour oil only into appropriately marked containers



Do not pour oil into drinking vessels (drinks bottles, glasses, cups or mugs)



Observe country-specific safety regulations



First aid measures:

Do not induce vomiting.



If the person affected is still conscious, he/she must rinse out their mouth with water, drink plenty of water and

consult a doctor immediately.

If the person affected is unconscious, do not administer anything by mouth, place the person in the recovery

position and seek immediate medical attention.

00 RISK OF INJURY IF OIL COMES INTO CONTACT WITH EYES AND SKIN

Danger of injury!

Contact with eyes or skin may result in injury!

Possible symptoms are:

2007 BMW X3

2007 BMW X3

MAINTENANCE Maintenance & OE General Information - X3

MAINTENANCE Maintenance & OE General Information - X3

MAINTENANCE

Maintenance & OE General Information - X3
