- Page 1 OD784100TX Delaney Outdoor Sofa Assembly Instructions For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Page 1...
- Page 2 OD784100TX - Delaney Outdoor Sofa Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 OD784100TX - Delaney Outdoor Sofa Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 OD784100TX - Delaney Outdoor Sofa Assembly Instructions Figure 1 Attache the Left Leg Frame (A) and Right Leg Frame (B) into the Back Frame (C). Using the Long F-Bolt (2) and the Long Sleeve Nut (3) Then tighten all bolts by Allen Wrench (8) Page 4...
- Page 5 OD784100TX - Delaney Outdoor Sofa Assembly Instructions Figure 2 Attach the Support Frame (F) into Assembly Frame. Using the Long F-Screw (1). Then Tighten all F-Screws by Allen Wrench. Page 5...
- Page 6 OD784100TX - Delaney Outdoor Sofa Assembly Instructions Figure 3 Attach the left - right Seat Frame (E) into the middle Back Frame (D). Using the short F-Bolt (7), short Sleeve Nut (6). Then tighten all F- Bolts by Allen Wrench. Page 6...
- Page 7 OD784100TX - Delaney Outdoor Sofa Assembly Instructions Figure 4 Insert the Assembly Frame ( Figure 3) into the Assembly Frame ( Figure 2). Using the short F-Screw (4) then tighten them by Allen Wrench. Using the Wood Screw (5) then tighten them by Screwdriver. Page 7...
- Page 8 If damages or missing parts are not reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
- Page 9 OD784200TX Delaney Outdoor Ottoman Assembly Instructions For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Page 1...
- Page 10 OD784200TX - Delaney Outdoor Ottoman Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 11 OD784200TX - Delaney Outdoor Ottoman Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 12 OD784200TX - Delaney Outdoor Ottoman Assembly Instructions Figure 1 Attach Leg (B) onto the Frame (A) using Hex-Bolts (1), Spring washers (2), and washers (3). Turn Hex-Bolts (1) by hand, then, tighten with wrench (4) Page 4...
- Page 13 OD784200TX - Delaney Outdoor Ottoman Assembly Instructions Figure 2 Turn the ottoman over the ottoman is ready to use. Page 5...
- Page 14 If damages or missing parts are not reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
