Summary of Contents for Southern Enterprises Lucia
- Page 1 OD428800TX Lucia Outdoor Serving Cart Assembly Instructions For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Page 1...
- Page 2 OD428800TX - Lucia Outdoor Serving Cart Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 OD428800TX - Lucia Outdoor Serving Cart Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 OD428800TX - Lucia Outdoor Serving Cart Assembly Instructions Figure 1 Caution (!): Make sure the larger hole on the wheels are facing outwards. Attach the two Wheels (E) to Support Piece (11), using Largest Washer (9) Long Bolt Large Washer (10), Medium Washer (8) and Big Lock Nut (5). Tighten by using Allen Wrench (14) and Wrench (13) at the same time as shown.
- Page 5 OD428800TX - Lucia Outdoor Serving Cart Assembly Instructions Figure 2 Attach Short Leg Frame (A) into the assembled Frame. Insert Small Washer (7) between the two bars. Then use Smallest washer (6), small Lock Nut (4) and Medium Bolt (2).
- Page 6 OD428800TX - Lucia Outdoor Serving Cart Assembly Instructions Figure 3 Insert the Lower Shelf Frame (D) into the Assembled Frame using the Medium Washer (8), Smallest Washer (6), and Short Bolt (1). Then use Allen Wrench (14) to tighten. Page 6...
- Page 7 OD428800TX - Lucia Outdoor Serving Cart Assembly Instructions Figure 4 Insert the upper Shelf Frame (C) into the Assembled Frame using the Medium Washer (8), Smallest Washer (6),and Short Bolt (1) Then, use Allen Wrench (14) to tighten. Page 7...
- Page 8 If damages or missing parts are not reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
