- Page 1 User Manual User Manual Product Name: AVL2 Series Hotel Card Lock System(P Type) Model ALVBP / ALV2P Version 2.0 March 27, 2023 MIWA LOCK CO., LTD. MIWA LOCK CO.,LTD. 1/13...
- Page 2 1. Introduction 1.1. ALVBP/ALV2P Hotel Card Lock System This ALVBP and, ALV2P Hotel Card Lock is based on Contactless Smart Card "Mifare" and Bluetooth Low Energy with smartphone. The authentication key to Mifare card or smartphone is issued by specific issuing unit.
- Page 3 2. Outline of the Unit 2.1. Cards The ALVBP and ALV2P Hotel Card Lock is used as a card key reader for the contactless IC card Mifare. (1) The Mifare card is issued by special issuing machine, so that card data are protected sturdy.
- Page 4 User Manual (3) Unlocking will be done only when the input data set up beforehand in the ALV2P/ALVBP Hotel Card Lock (room number and time, etc) and the data in the card(BLE) key are compared and matched. (4) When a re-issued card (BLE) key is used to the lock, it becomes no longer possible to use the old card(BLE).
- Page 5 (6) The buzzer can be set in the “On” or “Off” position from the data input unit. Table 2.1: Alarm sound Conditions Alarm sound Initial setting Pi… Card (BLE) Key Verification OK Pi, pi… Card (BLE) Key Verification NG Pi, pi, pi… Low Battery Power MIWA LOCK CO.,LTD. 5/13...
- Page 6 * Unlocking of the “double locking” becomes effective with Guest Card, Master Card, and Submaster Card depending on the lock settings. (3) If a card that cannot open the double locked door is used, the Verification NG Lamp will light up red. MIWA LOCK CO.,LTD. 6/13...
- Page 7 (1) The door will unlock simply by turning the lever handle from inside of the room even in a state of double lock. (2) When the door is unlocked using the lever handle from inside the room, it will automatically lock again once the door has opened and closed. MIWA LOCK CO.,LTD. 7/13...
- Page 8 ※Use the batteries to supply power from the outside. 3.4. Environment Specifications Operating temperature: 0˚C to +40˚C Environmental conditions (without condensation) Range of humidity: 35 to 85% RH Installation Keep out of wind and rain and away from direct Sunlight Dust Normal office amounts MIWA LOCK CO.,LTD. 8/13...
- Page 9 (1) The ALVBP/ALV2P Hotel Card Lock functions by inputting lock-setting data Lock-setting data includes the hotel code, room number, and time (clock), and the ALVBP/ALV2P Hotel Card Lock validates the card key if the lock setting data in the card and the ALVBP/ALV2P Hotel Card Lock are matched.
- Page 10 (7) When leaving the room, simply turning the lever handle will unlock the door. This is the same even when the door is double locked (→Anti-panic mechanism). (8) Room entering history and lock status information are recorded on the Master Card and Submaster Card (→Audit trail function). MIWA LOCK CO.,LTD. 10/13...
- Page 11 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines as this equipment has very low levels of RF energy. MIWA LOCK CO.,LTD. 11/13...
- Page 12 Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’ISDE puisque cet appareil a une niveau tres bas d'energie RF. MIWA LOCK CO.,LTD. 12/13...
- Page 13 User Manual Labeling MIWA LOCK ALVBP/ALV2P Hotel Card Lock is labeled as below. ALVBP FCC ID: VBU–V2VBP23 IC: 21683–V2VBP23 HVIN:VBP100 Contains FCC ID: RYYEYSHCN (Model ALVBP only) Contains IC: 4389B-EYSHCN (Model ALVBP only) ALV2P FCC ID: VBU–V2VBP23 IC: 21683–V2VBP23 HVIN: V2P100 MIWA LOCK CO.,LTD.
