- Page 1 User Manual User Manual Product Name Hotel Card Lock Model ALVBP / ALV2P type Version 1.0 July 24, 2018 MIWA LOCK CO., LTD. MIWA LOCK CO.,LTD. 1/13...
- Page 2 1. Introduction 1.1. ALVBP/ALV2P Hotel Card Lock This ALVBP and ALV2P Hotel Card Lock is based on Contactless Smart Card "Mifare" and Bluetooth Low Energy with smartphone. The authentication key to Mifare card or smartphone is issued by specific issuing unit.
- Page 3 2. Outline of the Unit 2.1. Cards The ALVBP and ALV2P Hotel Card Lock is used as a card key reader for the contactless IC card Mifare. (1) The Mifare card is issued by special issuing machine, so that card data are protected sturdy.
- Page 4 User Manual (3) Unlocking will be done only when the input data set up beforehand in the ALV2P/ALVBP Hotel Card Lock(room number and time, etc) and the data in the card(BLE) key are compared and matched. (4) When a re-issued card(BLE) key is used to the lock, it becomes no longer possible to use the old card(BLE).
- Page 5 (6) The buzzer can be set in the “On” or “Off” position from the data input unit. Table 2.1: Alarm sound Conditions Alarm sound Initial setting Pi… Card(BLE) Key Verification OK Pi, pi… Card(BLE) Key Verification NG Pi, pi, pi… Low Battery Power MIWA LOCK CO.,LTD. 5/13...
- Page 6 * Unlocking of the “double locking” becomes effective with Guest Card, Master Card, and Submaster Card depending on the lock settings. (3) If a card that cannot open the double locked door is used, the Verification NG Lamp will light up red. MIWA LOCK CO.,LTD. 6/13...
- Page 7 (1) The door will unlock simply by turning the lever handle from inside of the room even in a state of double lock. (2) When the door is unlocked using the lever handle from inside the room, it will automatically lock again once the door has opened and closed. MIWA LOCK CO.,LTD. 7/13...
- Page 8 User Manual 3. General Specifications 3.1. Name Product Name: ALV2P / ALVBP type Hotel Card Lock Product Number: Cylinder type : ALV◎□△○※☆-1 Cylinder less type : ALV◎□△○※☆-3 ◎ = 2/B (Card type / Card and BLE Type) □ = U/E (Lock case type) △...
-
Page 9: Environment Specifications
User Manual 3.4. Environment Specifications Operating temperature: 0˚C to +40˚C Environmental conditions (without condensation) Range of humidity: 35 to 85% RH Installation Keep out of wind and rain and away from direct Sunlight Dust Normal office amounts MIWA LOCK CO.,LTD. 9/13... - Page 10 (1) The ALVBP/ALV2P Hotel Card Lock functions by inputting lock-setting data Lock-setting data includes the hotel code, room number, and time (clock), and the ALVBP/ALV2P Hotel Card Lock validates the card key if the lock setting data in the card and the ALVBP/ALV2P Hotel Card Lock are matched.
- Page 11 (7) When leaving the room, simply turning the lever handle will unlock the door. This is the same even when the door is double locked (→Anti-panic mechanism). (8) Room entering history and lock status information are recorded on the Master Card and Submaster Card (→Audit trail function). MIWA LOCK CO.,LTD. 11/13...
-
Page 12: Regulatory Compliance
This unit complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This unit may not cause harmful interference, and (2) This unit must accept any interference received, including interference that may cause undesired operation. MIWA LOCK CO.,LTD. 12/13... - Page 13 Any changes or modifications not expressly approved by the party responsible for product compliance could void the user's authority to operate the unit. Labeling MIWA LOCK ALVBP/ALV2P Hotel Card Lock is labeled as below. FCC ID: VBU –ALVBP2P IC: 21683 –ALVBP2P Contains FCC ID: VPYLBZY (ALVBP type only) Contains IC: 772C –LBZY...
