[ III Specifications ]

[1] Specifications

III Specifications
1. Specifications
Model name
Power source
*1
Cooling capacity
*1
Heating capacity
Power consumption
Current
External finish
Dimension
Net weight
Heat exchanger
Fan
Motor
Air filter
Water piping
diameter
Drain pipe dimension
Noise level (Lo-Mid-Hi)
*1 <Cooling> Indoor temperature: 27°CDB/19°CWB (81°FDB/66°FWB Outdoor temperature: 35°CDB (95°FDB)
<Heating> Indoor temperature: 20°CDB (68°FDB) Outdoor temperature: 7°CDB/6°CWB (45°FDB/43°FWB)
*2 The values in ( ) show the height of unit with leg.
*3 The external static pressure is set to 10Pa at factory shipment.
*4 The noise level in operation is measured at 1.5 m apart from the front side and the bottom side of the unit in anechoic room.
(Noise meter A-scale value) Connect the duct of 1 m in length to the air outlet.
HWE22200
Cooling
Heating
Cooling
Heating
*2
Height
Width
Depth
Type x Quantity
Airflow rate
(Lo-Mid-Hi)
*3
External static pressure
Type
Output
Inlet
Outlet
PFFY-
WL20VCM-A
~ 220-240V 50Hz/60Hz
2.2
kW
2.5
0.022
kW
0.022
0.25
A
0.25
mm
kg 18
Cross fin (Aluminum fin and copper tube)
3
m /min 5.0-6.0-7.0
Pa
kW
mm
I.D.
mm
I.D.
mm
dB (A) 21-23-26
- 3 -
PFFY-
WL25VCM-A WL32VCM-A
2.8
3.2
0.029
0.029
0.33
0.33
Galvanized steel plate
615 (690)
700
200
18
Sirocco fan x 2
5.5-7.0-8.5 6.5-7.5-9.0
0/10/40/60
DC motor
0.096
PP honeycomb fabric.
20
20
32 (1-1/4 inch)
22-26-30 25-28-32
PFFY-
3.6
4.0
0.035
0.035
0.38
0.38
18.5
